Thank you for purchasing Erica Synths Pico Series module!
With Pico Series we challenged ourselves – can we make ANY
superior functionality synth module 3HP wide and affordable?
Yes, we can.
Erica Pico VC EG is versatile looping AD/ASR envelope generator
with voltage control over attack and decay times. It has
automatic Trigger/Gate detection, as well as "drone mode" –
at full CW setting of the Decay knob, the envelope is full open.
In the LOOP mode you can retrigger envelopes for even more
interesting modulations.
AD/ASR envelope
Automatic Trigger/Gate detection
Manual and voltage control over Attack and Decay time
Manual trigger button
Input protection against overvoltage
Protection against reverse PSU connection
Output amplitude
Attack time
Decay time
CV level (full span)
Power consumption
Module width
Module depth
PICO
VC EG
0V - 10V
5ms – 1s
5ms – 50s
-5V - +5V
+17mA, -13mA
3HP
35mm
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Erica Synths PICO VC EG
Summary of Contents for Erica Synths PICO VC EG
- Page 1 3HP wide and affordable? Yes, we can. Erica Pico VC EG is versatile looping AD/ASR envelope generator with voltage control over attack and decay times. It has automatic Trigger/Gate detection, as well as “drone mode” –...
- Page 2 PICO VC EG VC EG This knob sets Attack time. The incoming CV is added to the knob setting. ATTACK This knob sets Decay time. The incoming CV is added to the knob setting. DECAY Select between looping mode and LOOP M.TR triggered mode! In looping mode, when CV is applied to attack and/or decay...
- Page 3 Erica Synths. Water is lethal for most of the electric devices, unless they are made waterproof. This Erica Synths module is NOT intended for use in a humid or wet environment. No liquids or other conducting substances must get into the module.
