2 Introduction
1-1

Model Number Designation

ENCLOSURE STYLE
LINEARIZED ANALOG OUTPUT
INPUT POWER
SPECIAL FEATURES
ENCLOSURE STYLE
MODEL CAT1-(
( A )
OPTION
(1) GENERAL PURPOSE.
2.6"L X 2.6"H X 2.6"W MINIMUM MOUNTING SPACE.
(D) 2" LONG DIN RAIL MOUNT SINGLE UNIT.
UP TO 20 CAT1 UNITS CAN BE MOUNTED ON A SINGLE RAIL.
ADD 2" PER UNIT.
(3/O) MEETS CLASS 1, DIV. 1 AND 2, GROUPS C, D
(3B/O) MEETS CLASS I, DIV. 1 AND 2, GROUPS A, B, C, D
(3B/O-ATEX) EExd II C ENCLOSURE. ATEX-APPROVED 3/4" FNPT
HP-310
MODEL CAT1-(
A
)-( )-( )-(
CLASS II, GROUPS E, F, G
CLASS III
NEMA 4X WITH 'O' RING
CERTIFIED CSA, UL
BODY KILARK #GECCT-3, STOCK #200-0945
FLAT COVER, STOCK #200-0533, KILARK #GECBC
CLASS 1, ZONES 1 AND 2, GROUPS IIB + H2, IIA
CLASS II, DIV. 1 AND 2, GROUPS E, F, G
CLASS III
NEMA 3, 4, 7 (B, C, D), 9 (E, F, G)
CERTIFIED CENELEC, CSA, UL, FM
BODY KILARK #HKB, STOCK #200-0406
FLAT COVER , STOCK #200-0773, KILARK #HKB-B.
CABLE ENTRIES.
A
)-(
)
B C D
)-( )-( )
