4. Installation

NOTE: CAT1 flow input interfaces with magnetic type pickup coils
and contact closure only. If another type of coil is required, refer to
CAT 2 and CAT3 models.
4-1

Typical Connections

Loop powered with MAG Coil Installation
-
-
Dip Switch Settings
1
SW1
DC
+
POWER
SUPPLY
A B
Mag Pickup Coil
+
LOAD
PCA180
1
SW2
Installation
DC+
N/C
SIG+
SIG-
ANLG
N/C
N/C
N/C
N/C
N/C
PCA183
1
SW1
HP-310
11
