Messages

Commands Supported By Communications Messages
Command Description/Allowed Data/Response
Tag Number
DN
FC Linearization
K Factor Decimal Point Location
KD
AK Average K Factor
Number Points in the Table
NP
Appendix B
"0" to "99999999"
"TAG NUM = (DATA)"
The first three digits are the units code for total. Changing
these digits will change the TU settings.
"0" = Average K factor
"1" = Linearization table
"F C METHOD = AVG" for Average K factor
or
"F C METHOD = LIN" for Linearization table
"0" for 00000000.
"1" for 0000000.0 and all K Factors are less than
9999999.9, otherwise not allowed
"2" for 000000.00and all K Factors are less than 999999.99,
otherwise not allowed
"3" for 00000.000 and all K Factors are less than
99999.999, otherwise not allowed
"K-FAC DECL=(DATA)"
"0.001" to
"99999.999" if KD = 3
"999999.99" if KD = 2
"9999999.9" if KD = 1
" 99999999" if KD = 0
"AVG KFAC =(DATA)"
"2" to "20"
"NUM PTS =(DATA)"
–
Communications 17
HP-310
