N10 Hardware User Guide
N10 Hardware User Guide
Version 1.7

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the N10 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Neoway N10

Summary of Contents for Neoway N10

  • Page 1 N10 Hardware User Guide N10 Hardware User Guide Version 1.7...
  • Page 2 N10_Hardware_User_Guide Copyright © Neoway Technology Co., Ltd. 2017. All rights reserved. No part of this document may be reproduced or transmitted in any form or by any means without prior written consent of Neoway Technology Co., Ltd. Trademarks is the trademark of Neoway Technology Co., Ltd.
  • Page 3 Corrected the definition of USB pins Shen Tongqiao 2017-09 Corrected the baudrate of the UART interface Shen Tongqiao  V1.7 Corrected the pulses of the RING signal 2017-11  Corrected description of the audio interface  Copyright © Neoway Technology Co., Ltd.

  • Page 4: Table Of Contents

    N10_Hardware_User_Guide Contents About This Document ......................1 1 About N10 ........................... 2 1.1 Overview ............................2 1.2 Block Diagram ........................... 2 1.3 Specifications ............................. 3 2 Pin Description and PCB Foot Print ................5 2.1 Specifications and Pin Definition ....................... 5 2.2 Pin Definition .............................
  • Page 5 Figure 1-1 N10 Block Diagram ....................... 3 Figure 2-1 Top view of N10 module ....................... 5 Figure 2-2 PCB foot print recommended for N10 (unit: mm) .............. 10 Figure 3-1 Current peaks and voltage drops ..................12 Figure 3-2 Capacitors used for the power supply .................. 12 Figure 3-3 Reference design of power supply control ................
  • Page 6 Table of Tables Table 1-1 N10 Specifications ........................3 Table 2-1 N10 specifications ........................5 Table 2-2 N10 Pin definition ........................6 Table 3-1 Power supply and switch interface ..................11 Table 3-2 UART ............................ 20 Table 3-3 USB interface........................22 Table 3-4 DTR and RING pins ......................

  • Page 7: About This Document

    N10_Hardware_User_Guide About This Document This document defines the features, indicators, and test standards of the N10 GPRS module and provides reference for the hardware design. With Neoway_N10_AT_Commands_Mannual, this user guide can help development engineers complete wireless communications application easily. Copyright © Neoway Technology Co., Ltd.

  • Page 8: About N10

    N10 is widely used in industrial and consumer applications. 1.1 Overview The N10 module adopts 64-pin LCC package and its dimensions are 23.5 mm x 17 mm x 2.2 mm, which can meet most customer requirements for space reduction. It has the following hardware resources and...

  • Page 9: Specifications

    N10_Hardware_User_Guide Figure 1-1 N10 Block Diagram GSM850:Uplink 824~849MHz,Downlink 869~894MHz EGSM900:Uplink 880~915MHz,Downlink 925~960MHz DCS1800:Uplink 1710~1785MHz,Downlink 1805~1880MHz PCS1900:Uplink 1850~1910MHz,Downlink 1930~1990MHz RF Front-end-module 26MHz Crystal VBAT RF transceiver Power VRTC Manager Analog Digital ON/OFF Baseband Baseband FLASH Digital Audio Interface Interface 1.3 Specifications...
  • Page 10 3.3 V to 4.3 V (3.9 V is recommended) Peak Current Max 2.0 A Operating Current 11 mA (Idle) < 2.5 mA (on live network)  Current in Sleep Mode < 1.1 mA (through instrument, DRX=9)  Copyright © Neoway Technology Co., Ltd.

  • Page 11: Pin Description And Pcb Foot Print

    Table 2-1 N10 specifications Specifications Dimensions (23.5± 0.1) mm x (17± 0.1) mm x (2.2± 0.2) mm (H x W x D) Weight 1.3 g Package 64-pin LCC Figure 2-1 Top view of N10 module Copyright © Neoway Technology Co., Ltd.

  • Page 12: Pin Definition

    I/PU: indicates digital signal input pins with pull-up DI: indicates digital signal input pins AI: indicates analogy signal input pins DO: indicates digital signal output pins AO: indicates analogy signal output pins Table 2-2 N10 Pin definition Reset Electrical Level Pin Name Function...
  • Page 13 Used for command sending and 2.38<V <2.8 receiving UART data receive I/PU SIM Card 0<V <0.25*VSIM; SIM_CLK SIM card clock Compatible with 1.8/3.0 V SIM 0.75*VSIM<V <VSIM; card SIM_RST SIM card reset 0<V <0.15*VSIM; Copyright © Neoway Technology Co., Ltd.
  • Page 14 Sleep mode control I/PD commands 0<V <0.42; 2.38<V <2.8 ADC Testing 10-bit ADC Detectable voltage range: 0 V to ADC1 2.8 V Analog input GPRS Antenna GPRS_ANT AI/O GPRS antenna interface 50 Ω impedance Copyright © Neoway Technology Co., Ltd.
  • Page 15 IO pins of the module might be damaged if the IO signals are connected to the IO port on the 2.8 V systems. To rectify this issue, take measures to match the level. For details, see the 3.2 UART. Copyright © Neoway Technology Co., Ltd.

  • Page 16: Pcb Foot Print

    N10_Hardware_User_Guide 2.3 PCB Foot Print LCC packaging is adopted to package the pins of the N10 module. Figure 2-2 shows the recommended PCB foot print. Figure 2-2 PCB foot print recommended for N10 (unit: mm) Copyright © Neoway Technology Co., Ltd.

  • Page 17: Interface Design

    VBAT pin can be up to 2 A when the signal is weak and the module works at the maximum transmitting power. The voltage will encounter a drop in such a situation. The module might restart if the voltage drops lower than 3.3 V. Copyright © Neoway Technology Co., Ltd.

  • Page 18: Figure 3-1 Current Peaks And Voltage Drops

    (EMI). Use the EN pin on the LDO or DC/DC chipset to control the switch of the power supply as shown in Figure 3-3. Copyright © Neoway Technology Co., Ltd.

  • Page 19: Figure 3-3 Reference Design Of Power Supply Control

    GPRS, power off/on can rectify the module exceptions. In Figure 3-4, the module is powered on when GPRS_EN is set to high level. Figure 3-4 Reference design of power supply controlled by p-MOSFET Copyright © Neoway Technology Co., Ltd.
  • Page 20 The inductor used in Reference Design (b), should be a power inductor and have a very low resistance. 10 μH with average current ability greater than 1.2 A and low DC resistance is recommended. Copyright © Neoway Technology Co., Ltd.

  • Page 21: Vio28

    Never use a diode to make the drop voltage between a higher input and module power. Otherwise, Neoway will not provide warranty for product issues caused by this. In this situation, the diode will obviously decrease the module performances, or result in unexpected restarts, due to the forward voltage of diode will vary greatly in different temperature and current.

  • Page 22: Power-On/Off Control And Procedure

    If the module adopts a fixed baudrate, an unsolicited message ( ) will be sent to \r\nMODEM:STARTUP\r\n host through UART port, indicating that the module is initialized and the UART can respond to the AT commands. Copyright © Neoway Technology Co., Ltd.

  • Page 23: Figure 3-7 Power-On Procedure

    While the module is on, pull the ON/OFF pin to ground for at least 500 ms and then release, the module will try to detach to network and normally 2 seconds later it will shut down. Another approach to turn off the module is using AT commands. For details, please refer to Neoway_N10_AT_Commands_Manual. Copyright © Neoway Technology Co., Ltd.

  • Page 24: Figure 3-8 Power-Off Procedure

    The module keeps monitoring the voltage at VBAT. When it is lower than 3.3 V, the module shuts down automatically. Power-On/Off Control Figure 3-9 shows a reference circuit for ON/OFF control with inverted control logic. Figure 3-9 Reference circuit for power-on/off control ON/OFF GPRS Module Copyright © Neoway Technology Co., Ltd.

  • Page 25: Reset

    RESET is a soft reset pin, but the RESET pin does not work when the module program runs off. If 3.3 V IO system is used, separate it by adding a triode. Please refer to Figure 3-11. Copyright © Neoway Technology Co., Ltd.

  • Page 26: Uart

    UART is used for AT command sending, data sending/receiving, firmware upgrading, etc. Figure 3-12 shows the signal connection between the module (DCE) and the terminal (DTE). Figure 3-12 Signal connection between DCE and DTE Client MCU_TXD MCU_RXD MCU_CTS MCU_RTS Copyright © Neoway Technology Co., Ltd.

  • Page 27: Figure 3-13 Recommended Level Shifting Circuit 1

    N10_Hardware_User_Guide The UART of N10 works at 2.8 V CMOS logic level. The voltages for input high level should not exceed 3.1 V. UART supports baud rates of 9600, 14400, 19200, 38400, 57600, 115200 bit/s, and the default rate is 115200 bit/s.

  • Page 28: Usb

    3.3 USB Table 3-3 USB interface Signal Function Remarks VBUS USB voltage check 4.3 V < VBUS < 7 V, typical value: 5 V USB_DM interface differential data line USB_DP Copyright © Neoway Technology Co., Ltd.

  • Page 29: Dtr And Ring

    N10_Hardware_User_Guide The USB interface of N10 module can be used to download software. Before that, connect USB interface to a computer and then power on the module. Figure 3-15 shows the recommended connection between the module and a computer. Figure 3-15 USB circuit Connect a 1 μF filter capacitor in parallel to VBUS and place it as close to the pin as possible.

  • Page 30: Ring Signal

    RING pin outputs 30 ms low pulses at 5s period. After the call is answered, the high level restores. Figure 3-16 RING indicator for incoming call 30 ms 30 ms SMS: Upon receipt of SMS, the module outputs a 35 ms low pulse.  Figure 3-17 RING indicator for SMS 35 ms Copyright © Neoway Technology Co., Ltd.

  • Page 31: Sim Card

    SIM card power supply output N10 supports 3.0 V and 1.8 V SIM cards. VSIM supplies power for SIM card with 30 mA. SIM_IO is internally pulled up by a resistor. Add a 10 kΩ pullup resistor externally to VSIM if the trace is long.

  • Page 32: Light

    The LIGHT pin can output a 4 mA of current and 2.8 V of voltage, therefore the LED can be directly connected to this pin with a resistor in series. For better luminance, drive the LED with a transistor. Copyright © Neoway Technology Co., Ltd.

  • Page 33: Audio

    MIC_N Negative electrode of MIC N10 supports one input and output interface for audio. Audio volume can be adjusted via AT commands. For details, see Neo_N10_AT_Commands_Mannual. Figure 3-21 shows a reference audio interface design. The peak voltage routed to MIC should not exceed 200 mV AC.

  • Page 34: Figure 3-21 Reference Design Of Mic Differential Connections

    In above figures, the audio input circuits are designed to meet the requirements for small audio signal, far away from interference source and masking PCB routing by ground. The maximum output power of SPK is 800 mW@8Ω. Copyright © Neoway Technology Co., Ltd.

  • Page 35: Rf Design And Pcb Layout

    VSWR requirement is met, just use a 100 pF capacitor for C1 and leave L1, L2 un-installed. Avoid any other traces crossing the antenna trace on neighboring layer. Figure 3-24 Reference design for antenna interface GPRS_ANT GPRS Module Copyright © Neoway Technology Co., Ltd.

  • Page 36: Recommended Rf Connection

    3.8.2 Recommended RF Connection If RF cables are used for connections, the GSC RF connector MM9329-2700RA1 from Murata is recommended. Figure 3-26 shows the encapsulation specifications. Copyright © Neoway Technology Co., Ltd.

  • Page 37: Figure 3-26 Encapsulation Specifications Of Murata Rf Connector

    RF cable can also be connected to the module by soldering. In this manner, ensure proper soldering in case of damage that lowers RF performance. Figure 3-27 shows the pictures of these two connections. Figure 3-27 RF connections Copyright © Neoway Technology Co., Ltd.

  • Page 38: Electric Features And Reliability

    If LDO or DC-DC is used to supply power for the module, ensure that it output at least 2 A current. 4.2 Temperature Table 4-2 Temperature Feature Module Status Minimum Value Typical Value Maximum Value Working -40 ° C 25 ° C 85 ° C Storage -45 ° C 90 ° C Copyright © Neoway Technology Co., Ltd.

  • Page 39: Current

    126mA GSM850 435 mA EGSM900 397 mA 4TX, 1RX (4Up/1Down) DCS1800 268 mA PCS1900 242 mA GPRS class 12 GSM850 184 mA EGSM900 170 mA 1TX, 4RX (1Up/4Down) DCS1800 122 mA PCS1900 117 mA Copyright © Neoway Technology Co., Ltd.

  • Page 40: Esd Protection

    Cover ± 8 kV ± 15 kV RXD/TXD ± 4 kV ± 8 kV ± 4 kV ± 8 kV MIC/SPK ± 4 kV ± 8 kV Others ± 4 kV ± 8 kV Copyright © Neoway Technology Co., Ltd.

  • Page 41: Rf Features

    17 dBm ± 3 dBm 15 dBm ± 3 dBm 13 dBm ± 5 dBm 11 dBm ± 5 dBm 9 dBm ± 5 dBm 7 dBm ± 5 dBm 5 dBm ± 5 dBm Copyright © Neoway Technology Co., Ltd.

  • Page 42: Receiving Sensitivity

    <-108 dBm DCS1800&PCS1900 <-108 dBm The data in the above tables is obtained by connecting the module to RF test instrument (e.g. CMU200, CWM500, or Agilent8960) in lab tests. It is for reference only. Copyright © Neoway Technology Co., Ltd.

  • Page 43: Mounting The Module Onto The Application Board

    N10_Hardware_User_Guide 6 Mounting the Module onto the Application Board N10 module is compatible with industrial standard reflow profile for lead-free SMT process. The reflow profile is process dependent, so the following recommendation is just a starting point guideline: Only one flow is supported.

  • Page 44: Package

    N10_Hardware_User_Guide 7 Package N10 modules are packed in real with sealed bags for delivery to guarantee a long shelf life. Follow same package of the modules again in case of opened for any reasons. If exposed to air for more than 48 hours at conditions not worse than 30° C/60% RH, a baking procedure should be done before SMT.

  • Page 45: Abbreviations

    Electronic Static Discharge European Telecommunication Standard FDMA Frequency Division Multiple Access Full Rate GPRS General Packet Radio Service Global Standard for Mobile Communications Half Rate Integrated Circuit IMEI International Mobile Equipment Identity Liquid Crystal Display Copyright © Neoway Technology Co., Ltd.
  • Page 46 Read-only Memory Root Mean Square Real Time Clock Subscriber Identification Module Short Message Service SRAM Static Random Access Memory Terminal adapter TDMA Time Division Multiple Access UART Universal asynchronous receiver-transmitter VSWR Voltage Standing Wave Ratio Copyright © Neoway Technology Co., Ltd.
