MAGNETIC OBJECTS
Four magnetic points are placed on the top of the object holder. Each of the magnets measures: 10.0  × 3.0 H mm.
The adhesive force depends on the opposite pole and the environmental conditions and must therefore be checked
on a case-by-case basis.
Magnetic points
• Place a magnetic object on the plate so that it is held by the magnetic points.
• If the object does not cover the area between the magnetic points, you can enlarge the area with magnetic
plates or magnetic tape (available as office supplies).
The adhesive effect depends on the individual magnetization of the object and the inserted magnetic plates.
NON-MAGNETIC OBJECTS
Adhesive glue pads are necessary to fasten non-magnetic objects. Two packs of adhesive pads are included in the
scope of delivery. You can purchase replacements from office suppliers if required.
• Cover the topside of the plate with adhesive pads. Different numbers of adhesive pads may be needed,
depending on the size, weight and shape of the object. Knead several adhesive pads together and shape e.g.
a plate or a pillow.
• Place the object with the underside on the adhesive pads.
• Align the front / main side of the object with the single magnetic point (1).
• Press the object firmly.
The object is placed properly if it does not protrude beyond the magnetic points.
• Tilt the object holder carefully to the right and left.
The object is placed correctly when it does not slip.
• If the object does slip, use more adhesive pads or alternatively test another object holder.
