6. The object holder system

6.1. Overview

OBSERVE THE SAFETY INSTRUCTIONS!
The extensive object holder system of the ALS 2 allows you to securely fasten and insert jaw models, partial models,
tooth stump models, Triple Tray® impressions and occlusion models.
1. Object holder: in this case the model with knurled screw for single jaw models
2. Base plate with non-slip rubber mat and Multisplit base for object holder, adapter plates and Multisplit mounting
plates
MULTISPLIT BASE PLATE
1. Contact points for object holders and adapter plates ("Ovals")
2. Contact points for Multisplit mounting plates ("Corners")
3. Magnetic adhesive disk for mounting object holders, adapter plates and Multisplit mounting plates
1 2
2 1
3
