AMETEK Western Research
IPS-4 Analyzer
Fiber Optic UV/VIS Option
General Purpose
User Manual
Process Instruments
455 Corporate Blvd.
PN 403370901, Rev B
Newark, DE 19702

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the IPS-4 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Ametek IPS-4

Summary of Contents for Ametek IPS-4

  • Page 1 AMETEK Western Research IPS-4 Analyzer Fiber Optic UV/VIS Option General Purpose User Manual Process Instruments 455 Corporate Blvd. PN 403370901, Rev B Newark, DE 19702...
  • Page 2 © 20010 AMETEK Process & Analytical Instruments Division This manual is a guide for the use of the IPS-4 (Integrated Process Spectrophometer) Analyzer with Fiber Optic UV/VIS option. Data herein has been verifi ed and validated and is believed adequate for the intended use of this instrument. If the instrument or procedures are used for purposes over and above the capabilities specifi...

  • Page 3: Table Of Contents

    Contents OfficesSALES AND MANUFACTURING: ..............ii Safety Notes ........................viii Electrical Safety ......................viii Grounding ........................viii Personnel and Equipment Safety Information ..............ix Cautions ........................ x Electromagnetic Compatibility (EMC) ............... xii Special Warnings and Information ................xiii Equipment Used in Class I, Division 2 Hazardous Locations ........xiii Warranty and Claims .....................
  • Page 4 Recording Initial Readings ....................22 Analyzer Configuration ....................24 Controller / User Interface ......................1 Introduction to the User Interface Panel ...............2 User Interface Panel Components ..................2 Special Software Characters ....................4 Working From the User Interface Panel – Conditions and Messages ......5 iv | IPS-4 Analyzer...
  • Page 5 Summary of Analyzer Operation ..................6 Working in the Main Menus ...................7 HOME Menu Screen ........................7 Bench ............................7 System Status Messages (HOME Screen) ............8 Alarm and Warning Notifi cation (HOME Screen) ........... 9 ALARMS and WARNINGS Menu Screen ................9 Viewing Current Alarms and Warnings ..............9 Viewing Logged Alarms and Warnings ..............
  • Page 6 Analyzer Reset ........................18 Service & Parts ..........................1 Technical Support ......................1 Returning Equipment .......................2 AMETEK Service & Aftermarket Sales Support ............3 Recommended Spare Parts ....................4 Measuring Cell Assembly Spare Parts ..................4 Optical Bench Assembly Spare Parts ..................4 Spare Analyzer Fuses ......................5 Spare Battery, MCU Board .....................5...
  • Page 7 Analyzer Modbus Interface Parameters ................3 Modbus Address ........................3 Modbus Functions ........................3 Holding Registers ......................4 APPENDIX – DRAWINGS ......................1 Analyzer Light Path Schematic ..................2 Analyzer Mounting Details, Unistruts ................3 Analyzer Overall Component Layout ................4 Detector Interface Board (100-1937) ................5 Detector Board (403378901) ....................6 Display Interface Board (100-1978) .................7 Customer Connection Board (100-1971) ................8 Relay Board (100-1942) ......................9...

  • Page 8: Safety Notes

    Grounding Instrument grounding is mandatory. Performance specifications and safety pro- tection are void if instrument is operated from an improperly grounded power source. CAUTION Verify ground continuity of all equipment before applying power. viii | IPS-4 Analyzer...

  • Page 9: Personnel And Equipment Safety Information

    All safety regulations, standards, and procedures at the analyzer location must be followed. All personnel involved with the installation, start-up, operation, maintenance, service, or troubleshooting of the IPS-4 Analyzer must review and follow these Warnings and Cautions. Warnings Review and follow these Warnings to avoid personal injury or environmental contamination.

  • Page 10: Cautions

    CAUTION light. The window is the flat surface at the end of the narrow glass tube. The lamp assembly is fragile and should be handled with care. x | IPS-4 Analyzer...
  • Page 11 Achtung - Heiße Oberfl äche Environmental Information (WEEE) This AMETEK product contains materials that can be reclaimed and recycled. In some cases the product may contain materials known to be hazardous to the environment or human health. In order to prevent the release of harmful substances into the environment and to conserve our natural resources, AMETEK recommends that you arrange to recycle this product when it reaches its “end of life.”...

  • Page 12: Electromagnetic Compatibility (Emc)

    CAUTION The various configurations of the IPS-4 Analyzer should not produce, or fall vic- tim to, electromagnetic disturbances as specified in the European Union’s EMC Directive (if applicable to your application). Strict compliance to the EMC Direc- tive requires that certain installation techniques and wiring practices are used to prevent or minimize erratic behavior of the Analyzer or its electronic neighbors.

  • Page 13: Special Warnings And Information

    SPECIAL WARNINGS AND INFORMATION Equipment Used in Class I, Division 2 Hazardous Locations Refer to Chapter 2 – Specifications for details about the suitability of this equip- ment in hazardous areas. Explosion Hazard – Substitution of Components May Impair Suitability for hazardous locations.

  • Page 14: Warranty And Claims

    The warranty does not apply to used or secondhand equipment nor extend to anyone other than the original purchaser from us. Should the Buyer’s technical staff require the on-site assistance of AMETEK’s agents or employees for service calls covered by this warranty clause, the Buyer shall pay travel time plus actual travel and living expenses.
  • Page 15 Contents | xv...
  • Page 16 This page intentionally left blank. xvi | IPS-4 Analyzer...

  • Page 17: Overview

    Flow Diagram Figure 1.1 illustrates the flow of information from the DUVV optical bench to the IPS-4 analyzer platform. A single PCB acts as the interface between the optical bench and the MCU board where the signal processing occurs. Overview...

  • Page 18: Calculation Flow (Software Version 3.0)

    STEP 3: Map the transmittance OR absorbance to an analyte value . In this step, the factory established calibration converts either transmit- tance or absorbance information into a value proportional to the analyte of interest. This calibration will be unique for each application. 1-2 | IPS-4 Analyzer...
  • Page 19 STEP 4: Filter output of Step 3 A median filter is applied to the current analyte value reading incorpo- rating the previous analyte value reading The size of the median filter is set in parameter MEDSZ. The median filter is follow by an IIR filter (EQUATION 1.3) weighted by a non-linear function defined by ALPHA and BETA parameters.

  • Page 20: Dispersive Ultraviolet/Visible (Duvv) Spectrometer

    (4) a detector (or sensor) that is sensitive to the wavelength region. The combination of (3) and (4) is also referred to as a spectrograph. Figure 1-2 illustrates the complete optical path from source to detector for the DUVV and optical bench. Figure 1-2. Analyzer light path UV-schematic. 1-4 | IPS-4 Analyzer...

  • Page 21: Uv Specifi Cations

    A xenon flash lamp is utilized as the source for the ultraviolet and visible regions. The collimated beam from the xenon lamp travels through the measuring cell. There are several styles of measuring cells for the IPS-4 (see Figure 5-2). When an application requires sensitivity at shorter wave- lengths, UV-grade fused silica windows are used.

  • Page 22: Electronics

    • Control the sample system including valves, etc. • Calculate the fluid absorbances and concentrations. For external communication, RS232, RS485, and Ethernet ports are avail- able. Analog signals are also available to the customer through configu- rable 0–20 mA or 4–20 mA outputs. 1-6 | IPS-4 Analyzer...

  • Page 23: Classified, Hazardous Area Protection Components And Functions

    Classifi ed, Hazardous Area Protection Components and Functions The General-purpose version of the IPS-4 is designed to be, and complies with requirements for, electrical equipment in Division 2 classified hazard- ous areas. The methods of protection used include type “n” (non-incen- dive) and type “m”...
  • Page 24 This page intentionally left blank 1-8 | IPS-4 Analyzer...

  • Page 25: Specifications

    SPECIFICATIONS Analyzer Specifi cations Analytes Up to eight analytes, depending on the application. Response Linearity +/- 1% of full scale range. Measurement Accuracy +/- 1% or +/- 2% of full scale (typical – application specific). Accuracy is determined by comparing analyzer response to a known standard sample after a calibration has been performed.

  • Page 26: Inputs

    Up to eight (8) relays (NO, contact rating 100 VA, 240 V maximum), which indicate the operational status of the analyzer. Each relay provides one SPST (Form A) dry (potential free) contact. RS485 serial port, isolated. RS232 serial port, non-isolated. Fast Ethernet (IEE802.3). Modbus TCP (Supports single modbus client). 2-2 | IPS-4 Analyzer...

  • Page 27: Air / N Quality Requirements

    Air / N Quality Requirements Air Quality: As per ANSI/ISA-S7.0.01 (1996) Quality Standard for Instrument Air. Nitrogen Quality Use only ultrahigh purity (UHP) Nitrogen. For “application specific” Sample Fluid Flow Rate Application specific. Electrical Requirements Power Consumption < 500 W maximum start-up (from a cold start) with continuous average, depending on ambient temperature.

  • Page 28: Humidity

    530 mm (20.9”), analyzer only Width: 298 mm (11.72”), analyzer only Depth: 260 mm (10.22”), analyzer only Weight: 23.6 kg (52 lb), without Backpan (may vary, depending on system). With Backpan: Approximately 129 kg (285 lb)) 2-4 | IPS-4 Analyzer...

  • Page 29: Approvals And Certifi Cations

    Approvals and Certifi cations The IPS-4 Analyzer is certified with regard to electrical safety for Pollution Degree 2 (normally nonconductive environmental pollution occurs with occasional condensation) and Installation Category II (local level tran- sients, less than those found at power distribution level). Mains supply voltage fluctuations are not to exceed 10 percent of the nominal supply voltage.
  • Page 30 This page intentionally left blank. 2-6 | IPS-4 Analyzer...

  • Page 31: Installation & Start-Up

    INSTALLATION & START-UP The Installation & Start-Up chapter contains information about the fol- lowing topics: • Where to find safety information in this guide before working with the analyzer. • How to store the analyzer before installation. • How to uncrate and inspect the analyzer for damage before installing •...

  • Page 32: Safety Considerations

    All regulatory agency and personnel safety procedures for your jurisdiction must be followed. The IPS-4 Analyzer is certified with regard to electrical safety for Pollution Degree 2 (normally nonconductive environmental pollution WARNING occurs with occasional condensation) and Installation Category II (lo- cal level transients, less than those found at power distribution level).

  • Page 33: Pre-Installation Requirements

    Pre-Installation Requirements Storage Prior to Installation If the analyzer is stored for any period of time prior to installation, it must be housed in a temperature-controlled environment where it is not sub- ject to dripping or splashing liquids, corrosive gases/liquids, high humid- ity, or excessive heat or cold.

  • Page 34: General Installation Information

    • A supply of 1/4” O.D. 316 stainless steel tubing for the Instrument Air (or N ) and Span fluid lines. Length will vary, depending on the distance between the analyzer and the supply source. Supplied by the customer. 3-4 | IPS-4 Analyzer...
  • Page 35 Figure 3-1. Analyzer component layout details, example only. Installation & Start-Up...

  • Page 36: Installing The Mechanical Components

    Information” section of this manual and the Documentation Pack- age shipped with the analyzer. Location and Environment The IPS-4 Analyzer is designed for operation in environments classified “Pollution Degree 2” per IEC 61010, so it must be shielded from conduc- tive pollution and subject to only temporary condensation.
  • Page 37 Figure 3-2. Analyzer mounting details, example only. Figure 3-2 is an example of an analyzer layout. Mounting configu- ration and layout for your analyzer system may vary. Refer to the cus- tomer-specific drawings in the “Supplemental Information” section of NOTE this manual or the Documentation Package shipped with the analyzer.
  • Page 38 The surrounding ambient temperature of the analyzer should be main- tained between -20 °C to +50 °C (-4 °F to +122 °F). If the analyzer system is mounted within an AMETEK-designed shelter, these conditions are taken into consideration in the design of shelter.
  • Page 39 Figure 3-3. Optical Bench Assembly. Installation & Start-Up...

  • Page 40: Installing The Sample System

    “Supplemental Information” section of this manual or the Documentation Package shipped with the analyzer for installation infor- mation. If the Sample Probe/Sample Tap is not supplied by AMETEK, refer to the information and drawings shipped with the probe.

  • Page 41: Connecting I/O Signals, Alarm Relay Contacts, And Ac Power

    Connecting I/O Signals, Alarm Relay Contacts, and AC Power The analog input/output signals, alarm relay contacts, and AC power requirements are specific to each analyzer installation. For AC electrical supply cable and conduit requirements, refer to – and comply with – local wiring regulations and electrical codes for the area.

  • Page 42: Permanent Ethernet Cable Connections (Optional)

    100 m, special requirements may be necessary. Con- tact your network administrator for information. For systems using a permanent Ethernet connection, a ferrite core (Part Number 301-1044, supplied by AMETEK) must be installed on the Ethernet cable (supplied by customer), inside the Electronics NOTE Enclosure.
  • Page 43 Figure 3-4. Terminal Strip TB1 and Customer Connection board (100-1971). Refer to figure 3.1 for location of TB1 termianl strip. NOTE Installation & Start-Up 3-13...

  • Page 44: Start-Up And Verification

    Close the Main AC Power and DC Power fuses. Refer to the Fuse Leg- end (at the back of the Electronics Enclosure) for the location of these fuses. If a power-disconnect switch (breaker) was not installed, main AC power will be applied to the analyzer. 3-14 | IPS-4 Analyzer...
  • Page 45 2. After applying AC main power to the analyzer, the message “System Starting” is displayed momentarily on the top line of the User Inter- face Panel. Following this, the AMETEK Process Instruments start-up screen will appear. This screen also displays the software version.
  • Page 46 SETUP menu screen. Scroll SETUP down to select Current Outputs and press to display the ENTER Current Outputs 1 thru 4 screen. Scroll down to select Current Outputs 1 screen (Figure 3-6). 3-16 | IPS-4 Analyzer...
  • Page 47 Current Out 1 Source Analyte 1 Full 1000.0 Zero Type 4-20 mA Figure 3-6. Over Range Disabled Current Output Setup HOME ALARMS STATUS SETUP screen (Current Out 1). Check the Current Out 1 Source (species), Full (full-scale), and Zero (zero point) settings/values and compare them to the settings/val- ues listed on the analyzer documentation shipped with the ana- lyzer to ensure they correspond.
  • Page 48 Normal operating temperatures are values that are within 5 °C (typi- cal; set point may vary) of the Set Point values. Bench Temperature Heater Temperature Figure 3-8. Active alarms displayed (example), Current Alarms screen. HOME ALARMS STATUS SETUP 3-18 | IPS-4 Analyzer...
  • Page 49 No alarms Figure 3-9. No active alarms, Current Alarms screen. HOME ALARMS STATUS SETUP 10. Zero the analyzer as described under “Manually Zeroing the Analyzer Sample System,” later in this chapter. Record the initial sample response time in a log book, as described under “Recording Initial Readings,”...

  • Page 50: Start-Up Diagnostic Checklist

    (Bench Heater) for proper connection and blown fuse (located at TB1 in Electronics Enclosure). If the temperature zone values still do not increase, take appropriate safety precautions and check for proper wiring connections for the ap- propriate temperature zone wiring. 3-20 | IPS-4 Analyzer...

  • Page 51: Manually Zeroing The Analyzer Sample System

    Purge the sample system with Zero fluid. Purge the measuring Cell for at least 1 minute or until cell as been flushed and the reading has stabilized (which ever is longer). Typically, the IPS-4 Analyzer controls the zero flow rate; no adjust- ments are required. NOTE If the customer provides the sample system zero, run the manual zero at a flow rate of 2.5 L/minute (0.08 scfm).

  • Page 52: Recording Initial Readings

    AMETEK recommends that you observe and record this information every month to obtain a history. From these recordings, you will be able to determine if there are problems with the analyzer, such as increasing sample response.
  • Page 53 Installing the Optical Bench Assembly After the analyzer has been installed, the Optical Bench Assembly can be mounted in the Electronics Enclosure. All electrical connections to the Optical Bench Assembly are made via pre-wired connector plugs (no hard wiring is required). Ensure there is no power being supplied to the analyzer while install- ing the Optical Bench Assembly.
  • Page 54 If necessary, refer to the Parameter List (Factory Settings) sheets to revert the analyzer back to its original settings. 3-24 | IPS-4 Analyzer...

  • Page 55: Controller / User Interface

    CONTROLLER / USER INTERFACE The Controller / User Interface chapter contains information about the following topics: • An introduction to the User Interface Panel, and how to enter com- mands to view various screens. Information about passwords and how to change them is also discussed in this chapter. •...

  • Page 56: Introduction To The User Interface Panel

    The other lines can display the output results (concentrations, temperatures, pressures), alarms (current and historical), system status, system information, and various configurable parameters that allow you to set up the analyzer to perform various functions (calibration, communication, etc.). 4-2 | IPS-4 Analyzer...
  • Page 57 • The Main Keypad allows you to change information from any of the editable parameters. The keypad consists of: Description 0–9 Numeric keys 0–9 are used to enter numerical data or as part of a password. – The minus (‘–’) key can be used as part of a negative number or as part of a password.

  • Page 58: Special Software Characters

    When both of these characters (located in the lower-left corner) are displayed, there are other options to be viewed above and below the items currently being displayed. To scroll through other options, press the arrow key. DOWN 4-4 | IPS-4 Analyzer...

  • Page 59: Working From The User Interface Panel - Conditions And Messages

    Working From the User Interface Panel – Conditions and Messages While working from the User Interface Panel, the following conditions apply: The analyzer is shipped from the factory without a password (security is disabled). Upon powering up the analyzer for the first time, all con- NOTE figurable parameters can be changed until a password is entered in the Change Password function (Login/Set Password screen, SYSTEM...

  • Page 60: Summary Of Analyzer Operation

    The analyzer will leave its normal sequence of states if there is an alarm condition, such as a temperature or pressure out of range, and will return to the first state in the sequence once the offending condition has been cleared (reset). 4-6 | IPS-4 Analyzer...

  • Page 61: Working In The Main Menus

    Working in the Main Menus During normal operation, the concentrations of the analytes can be dis- played on the HOME screen. Other parameters that display real-time sys- tem temperatures or pressures can also be displayed. Up to three analytes or parameters can be displayed on the screen at one time. To view more concentrations or other data, scroll up or down using the DOWN row key.

  • Page 62: System Status Messages (Home Screen)

    Indicates the analyzer is measuring concentration with the zero fluid flushing the sample system. To leave this state, the analyzer must be manually changed to another state from the Calibration screen. Relay contact 8 is closed. 4-8 | IPS-4 Analyzer...

  • Page 63: Alarm And Warning Notifi Cation (Home Screen)

    Alarm and Warning Notifi cation (HOME Screen) When an alarm or warning is set by the analyzer, the message will flash on the HOME screen only. The information on the HOME screen will be replaced by a reverse (white) screen with the alarm name in black text. It will then switch to a black screen with white text and will continue to flash until the alarm conditions that triggered the alarm(s) are reset.
  • Page 64 “Maintenance & Troubleshooting” chapter. NOTE Bench Temperature Figure 4-4. Active alarms displayed, Current Alarms (example screen). HOME ALARMS STATUS SETUP No alarms Figure 4-5. No active alarms, Current Alarms screen. HOME ALARMS STATUS SETUP 4-10 | IPS-4 Analyzer...

  • Page 65: Viewing Logged Alarms And Warnings

    Viewing Logged Alarms and Warnings Alarms that have been reset (no longer active) are stored in the Alarm Log, accessed from the ALARMS screen. Each logged (or historical) alarm – which occupies two lines – includes the time and date it was set and re- set.

  • Page 66: Status Menu Screen

    Automatic Calibration 2 screen. The Calibration Trigger (TIMER-2) must be selected for the countdown time to be displayed. Refer to the section “Calibration Control” in this chapter for descriptions about setting up all Auto-Calibration parameters. 4-12 | IPS-4 Analyzer...

  • Page 67: Setup Menu Screen

    SETUP Menu Screen The SETUP screen (Figure 4-11) provides access to the sub-menu screens containing the functional parameters that control the operation of the analyzer. This screen allows the user to set up certain parameters. The settings for your analyzer have been configured at the factory to meet specified customer requirements.

  • Page 68: Calibration Control Screen

    The two setup screens allow multiple timers to be set. Automatic Calibration 1 Calibration Trigger Timer Mode Zero + Span Timer Interval 0 day Figure 4-14. Unit Calibration Settings Start Time 00:00:00 screen. HOME ALARMS STATUS SETUP 4-14 | IPS-4 Analyzer...
  • Page 69 Calibration Trigger Use this to select how auto-calibration is triggered. Calibration Trigger options include: • Timer Enables the Auto-Calibration timer. The system will automatically Zero and/or Span the analyzer. • Input1 and Input 2 Auto-Calibration will be initiated by a user-supplied contact clo- sure.

  • Page 70: Flush Times

    Defines the duration (seconds) the analyzer will flush the sample sys- tem with Zero fluid during the analyzer’s normal operating sequence. Flush Times Zero 10 sec Span 30 sec Sample 20 sec Figure 4-15. Flush Times Settings screen. HOME ALARMS STATUS SETUP 4-16 | IPS-4 Analyzer...

  • Page 71: Calibration Values

    Span flush time Defines the duration (seconds) the analyzer will flush the sample sys- tem with Span fluid during the analyzer’s normal operating sequence. Sample flush time Defines the duration (seconds) the analyzer will flush the sample sys- tem with sample fluid before it will begin measuring. Calibration Values The Calibration Values screen (Figure 4-16) allows the user to enter the calibration fluid concentration value used for each analyte (Analyte cal...
  • Page 72 “Span Gas Flush” mode. The analyzer span (calibration) is automatically adjusted based on an inte- grated reading during the span calibration. After the span is complete, the analyzer will return to normal operation (Measure mode). 4-18 | IPS-4 Analyzer...

  • Page 73: Manually Starting A Zero Calibration

    Inject Zero fluid This function injects Zero fluid into the sample system to flush the Measuring Cell of light-absorbing compounds. During this operation, the zero solenoid is open and “Zero Hold” is displayed in the Status area of the HOME screen. Note that this mode does not actually Zero the analyzer.

  • Page 74: Relay Setup Screens

    Relay 3 Figure 4-18a. Relay 4 Relay Setup screen. Relay 5 HOME ALARMS STATUS SETUP Relay 1 Function Disable Source None Value Figure 4-18b. Delay 0 Sec Relay Setup screen (Relay 1). HOME ALARMS STATUS SETUP 4-20 | IPS-4 Analyzer...
  • Page 75 Relay 1–8 Function The analyzer can use up to eight relays to indicate the operational sta- tus of the analyzer. Each relay provides one SPST (Form A) dry (poten- tial free) contact. The relays are energized (closed) on start-up. Relay Function options include: Disable Select Disable to turn off the functionality of a relay.
  • Page 76 LEFT the characters to the left of the cursor ( ‘_’ ) if applicable, then use the numeric keys to enter the new value. This works best for drastic changes. 4-22 | IPS-4 Analyzer...

  • Page 77: Current Output Setup Screens

    Current Output Setup Screens The Current Output screens (Figure 4-19a and 4-19b) display current out- put assignments and allows you to set up the parameters for each of the four current outputs. Source Defines the analyte assigned to each analog output. Current Out Source options include: NONE Select NONE if you do not wish to assign an output to a channel.

  • Page 78: Setpoints

    The Setpoints screens (Figure 4-20 thru 4-23) allow you to view config- ured normal operating (factory set) parameters for span, pressure, and temperature low/high limits. Setpoints > Span Limits Pressure Limits Temperature Limits Figure 4-20. Setpoints Screen. HOME ALARMS STATUS SETUP 4-24 | IPS-4 Analyzer...
  • Page 79 Span Limits If Span limits are exceeded, calibration is required. Pressure Limits If pressure limits are exceeded, the system alarm will activate and the ana- lyzer will go into “Not Ready” state. Limits are disabled if set to 0. Temperature Limits If temperature limits are exceeded, the system alarm will activate and the analyzer will go into “Not Ready”...

  • Page 80: Diagnostics Screen

    STATUS SETUP Relay Diagnostics Force relay contacts on or off to test the hardware. Relay Diagnostics Diagnostics State Relay 1 Relay 2 Figure 4-27. Relay 3 Relay 4 Relay Diagnostics Diagnostics Screen. HOME ALARMS STATUS SETUP 4-26 | IPS-4 Analyzer...

  • Page 81: System Settings Screen

    Valve Diagnostics Force valve contacts on or off to test the solenoid valves. Valve Diagnostics Diagnostics State Valve 1 Valve 2 Valve 3 Figure 4-28. Valve 4 Valve Diagnostics Diagnostics Screen. HOME ALARMS STATUS SETUP Lamp Diagnostics Monitor detector operation for a given wavelength. Lamp Diagnostics Wavelength Measurement...

  • Page 82: Login/Set Passwords Screen

    Use this function to enter a password for the first time after installing the analyzer or whenever you are changing the password. The pass- word entered here is the password that must be entered in the Enter 4-28 | IPS-4 Analyzer...
  • Page 83 Password function that will allow you to change the analyzer con- figuration settings. Because the analyzer is shipped from the factory without a password, you must enter a password in the Change Password function before you can change parameter settings. If you attempt to change the password without first entering the password, the message “System Locked”...

  • Page 84: Removing The Password

    Retrieves and restores the original factory-set analyzer configuration settings from the “factory.xml” file. See “Restoring Analyzer Configu- ration Settings” for details about how to restore configuration settings. Backup settings Restore settings Restore factory settings Figure 4-32. Backup/Restore Settings screen. HOME ALARMS STATUS SETUP 4-30 | IPS-4 Analyzer...

  • Page 85: Backing Up Analyzer Confi Guration Settings

    Backing Up Analyzer Confi guration Settings To back up configuration settings: 1. Press the soft key and then use the arrow to scroll down SETUP DOWN until the Backup/Restore sub-menu is selected. Press to view ENTER the Backup/Restore screen. 2. Select Backup settings and press .

  • Page 86: Ethernet Network Screen

    ( ‘.’ ). Use the arrow key as a LEFT back space and to delete numerical characters to the left of the cursor, or arrow key to advance to the right of the cursor. RIGHT 4-32 | IPS-4 Analyzer...
  • Page 87 Ethernet Enable Enabled DHCP Enable Disabled IP Address ##.##.###.# IP Subnet Mask ###.###.#.# Figure 4-36. Gateway ##.##.#.# Ethernet Network MAC address ##-##-##-##-##-## screen. HOME ALARMS STATUS SETUP Ethernet enable Allows the user to enable or disable the Ethernet interface, to allow communication between the analyzer and network.
  • Page 88 Ensure the DHCP server is on the same server as the analyzer. g. Press to back out of this sub-menu. CANCEL 5. Reset the analyzer to allow the changes to take effect. Refer to Page 31 Analyzer Reset instructions in Chapter 5. 4-34 | IPS-4 Analyzer...

  • Page 89: System Screen

    System Screen The System screen (Figure 4-37) allows the user to view and/or set up analyzer system parameters. > Model Name IPS-4 Serial Number 12345678 Software Version 1.10 System Time 15:22:29 System Date 07/11/2005 Figure 4-37. System screen. HOME ALARMS...

  • Page 90: Customization Screen

    Press again to select the language. ENTER Available languages for viewing the software include: - English - German - Russian - French - Spanish 4-36 | IPS-4 Analyzer...

  • Page 91: Modbus Screen

    Menu Home Time This displays and allows you to change the time an inactive menu will display before it returns to the home screen. User Time-Out This displays and allows you to change the inactivity period a user is logged into to the system. Screen Brightness This displays and allows you to change the screen brightness.
  • Page 92 This displays and allows you to change the time out value (duration) that the software will use to attempt to establish communications with the analyzer when using Modbus communications. AMETEK recom- mends a value of 1000 ms. To change these parameters: 1.

  • Page 93: Maintenance & Troubleshooting

    MAINTENANCE & TROUBLESHOOTING The Maintenance & Troubleshooting chapter discusses preventive main- tenance to keep the analyzer system operating at peak efficiency, how to check for plugging in the analyzer sample system, and how to replace internal parts. This chapter also discusses how to view alarm messages to diagnose and troubleshoot problems with the analyzer.

  • Page 94: Maintenance

    Preventive Maintenance To reduce the occurrence of problems with the analyzer, AMETEK recom- mends that you follow the “Analyzer Preventive Maintenance Schedule,” as outlined in the following pages. Since most analyzer problems originate within the sample handling system, the primary objective of the preven- tive maintenance schedule is proper care of the sample system.

  • Page 95: Analyzer Preventive Maintenance Schedule

    Analyzer Preventive Maintenance Schedule Frequency Task As required Clean the Analyzer Cleaning the exterior of the analyzer is required occasionally to re- move dust and other debris. Use a damp cloth to clean the analyz- er’s exterior, including the User Interface Panel screen. Daily Check for Alarms To view alarms, press the...
  • Page 96 Ensure these gaskets are intact. If the seals are damaged, cracked, or show signs of wear, replace them immediately. Contact AMETEK for assistance. Every Six Months Sheltered Systems If your analyzer system is installed in a custom shelter, check the air fi...

  • Page 97: Before Performing Maintenance

    This section discusses the parts that should be changed out and/or cleaned, according to the “Analyzer Preventive Maintenance Schedule.” These descriptions focus on the AMETEK sample system. When replacing parts in the analyzer refer to Figure 5-1 for the location of the main assem- bly.

  • Page 98: Tools, Equipment, And Supplies Required For Maintenance

    Tools, Equipment, and Supplies Required for Maintenance While working on the Cell the following tools, equipment, and supplies are required (supplied by AMETEK only where indicated): • Measuring Cell spare parts. Refer to either the Measuring Cell Manual Supplement or the Custom Spare Parts List (if applicable), located in the “Supplemental Information”...
  • Page 99 Figure 5-1. Analyzer Component Layout details. Actual layout and components may vary. Refer to customer-specific drawings in the “Supplemental Information” tab of this manual or the NOTE Documentation Package shipped with the analyzer. Maintenance & Troubleshooting | 5-7...

  • Page 100: Measuring Cell Preventive Maintenance

    Measuring Cell Windows are found to be damaged (scratched, cracked, or chipped). Replace the o-rings in the Measuring Cell every time this assembly is apart. • Every year as indicated in the “Analyzer Preventive Maintenance Schedule.” 5-8 | IPS-4 Analyzer...

  • Page 101: Xenon Flash Lamp Assembly Replacement

    Xenon Flash Lamp Assembly Replacement The typical life span of the Xenon Flash Lamp is approximately 18–24 months of continuous operation. However, the Xenon Flash Lamp can exhibit signs of degradation after 12–15 months. When the Xenon Flash Lamp requires replacement, the entire assembly (Figure 5-2) is replaced. See Figure 5-1 for the location of this assembly in the Electronics Enclo- sure.

  • Page 102: Replacing The Xenon Flash Lamp Assembly

    8. Take the new Xenon Flash Lamp Assembly (403471901) and, install in reverse order. 9. Connect the DC Power Cable from the Lamp Housing to J2 on the Xenon Lamp board. 10. Take all necessary precautions to safely power up the analyzer and prepare it for operation: 5-10 | IPS-4 Analyzer...
  • Page 103 Do not apply main AC power to the analyzer if the Xenon Flash Lamp Assembly electrical connections have not been made. WARNING General Purpose (GP) Applications: Apply power to the analyzer and its temperature-control zone cir- cuitry by closing the Main AC Power, DC Power, Bench Heater, and Oven Heater (if used) fuses.

  • Page 104: Replacing The Mcu Battery

    2. After the zero is complete, close the Sample Line and then the Vent Line Shut Off valves (in the Oven/Sample System Enclosure) to isolate the analyzer from the sample stream. 3. Power down the analyzer: 5-12 | IPS-4 Analyzer...
  • Page 105 General Purpose (GP) applications: Open the Electronics Enclosure door and disconnect AC power from the analyzer and its temperature-control zone circuitry by opening the Main AC Power, DC Power, Bench Heater, and Oven Heater (if used) fuses. Refer to the Fuse Legend at the back of the Electronics Enclo- sure for the locations of these fuses.

  • Page 106: Troubleshooting And Diagnostics

    If more than six alarms are active, use the arrow keys to scroll through the list. The alarm at the top of the DOWN list is most recent alarm; the alarm at the bottom is the oldest. 5-14 | IPS-4 Analyzer...

  • Page 107: Viewing Historical Alarm Messages

    To view active alarms: 1. Press the soft key to view the ALARMS screen. ALARMS 2. Select Current Alarms and press ENTER If there are active alarms, the alarm descriptions is displayed. No time or date is displayed with active alarms. If there are no active alarms, “No alarms”...

  • Page 108: Alarm Conditions And Corrective Action

    Alarm Conditions and Corrective Action This section lists all of the IPS-4 Analyzer system alarm messages (Condi- tion/Alarm Name), describes what triggers the alarms, and provides action that is required to reset the alarms (Description & Suggested Corrective Ac- tion).
  • Page 109 Enclosure door – for proper connections and inspect it for damage (cuts, nicks, burn marks, etc.). For cable connection locations, refer to the Electronics Enclosure Wiring Diagram in the Appendix. One or both boards may need to be replaced. Contact AMETEK for • assistance.

  • Page 110: Analyzer Reset

    Do not randomly reset the analyzer during normal operation. Typical- ly, a reset is required only when analyzer configuration settings have been restored. In this case the analyzer will reset itself automatically NOTE upon power-up, and will enable the restored settings. 5-18 | IPS-4 Analyzer...
  • Page 111 Figure 5-4. Alarm Reset Switch (S501), Relay board (100-1942). Maintenance & Troubleshooting | 5-19...
  • Page 112 This page intentionally left blank. 5-20 | IPS-4 Analyzer...

  • Page 113: Service & Parts

    SERVICE & PARTS The Service & Parts chapter discusses what to do if you need technical support from AMETEK, or if you are returning parts for service. This chapter also lists the recommended spare parts to have on hand to ensure all consumable and replaceable parts are replaced according to the “Ana-...

  • Page 114: Returning Equipment

    Material Authorization (RMA) number. This will ensure your equip- ment is serviced and returned to you in a prompt and efficient manner. To obtain an RMA number, contact your local or nearest AMETEK Service Center and have the following information available: •...

  • Page 115: Ametek Service & Aftermarket Sales Support

    ASAP plans may be written to provide • START UPS coverage for a single analyzer, or all of the AMETEK Your decision to buy an AMETEK analyzer is greatly process analyzers at your facility.

  • Page 116: Recommended Spare Parts

    Recommended Spare Parts This section lists the spare parts to have on-site for the IPS-4 Analyzer, some that are required as part of as analyzer preventive maintenance (see “Analyzer Preventive Maintenance Schedule” in Chapter 5). Content is subject to change without notice.

  • Page 117: Spare Analyzer Fuses

    NOTE These main analyzer fuses do not need to be changed out at regular intervals, but AMETEK recommends these fuses are available in the event that a replacement fuse is required. Fuses, IPS-4 Analyzer – Recommended Parts to Have On-Site...
  • Page 118 This page intentionally left blank. 6-6 | IPS-4 Analyzer...

  • Page 119: Controller / User Web Interface

    CONTROLLER / USER WEB INTERFACE The Controller / User Web Interface chapter contains information about the following topics: • An introduction to the User Web Interface, and how to access, moni- tor, and control your analyzer through a web interface •...

  • Page 120: Introduction To The Web Interface

    Introduction to the Web Interface Figure 7-1 illustrates the layout of the analyzer Web Interface. To access the IPS-4 analyzer using the Web Interface enter the analyzer’s IP address in the web browser or internet explorer’s web page address box.

  • Page 121: Web Interface Components

    Web Interface Components The Web Interface is divided into six sections. Navigation buttons lo- cated on the left-hand side of the screen are used to view analyzer sta- tus, alarms, trends, and spectra; view and change analyzer settings; and transfer data. The information displayed on the right-hand side varies depending on the selected section.

  • Page 122: Home Menu Screen

    The HOME screen (Figure 7-2) displays the current operational status of the analyzer. Descriptions of these states are described under “System Status Messages (HOME Screen),” in Chapter 4. Analyzer State Analyte Concentration Navigation Buttons Displays Real Time System Temperatures and Pressures Figure 7-2. Home Screen. 7-4 | IPS-4 Analyzer...

  • Page 123: Alarms Menu Screen

    ALARMS Menu Screen The ALARMS screen (Figure 7-3) displays any active analyzer alarm con- dition that has been set by the built-in diagnostics function and a history of alarms and warnings that have been reset (Figure 7-4). The alarms are read-only.

  • Page 124: Logged Alarms And Warnings

    When an alarm or warning is set by the analyzer, the alarm is displayed in the banner accross the top of the screen. Most Current Active Alarm Use Check Boxes to Filter Alarms/Warnings Displayed Click to Show only Log of All Alarms Active Alarms Figure 7-4. Alarm Log Screen. 7-6 | IPS-4 Analyzer...

  • Page 125: Trends Menu Screen

    TRENDS Menu Screen The TRENDS screen (Figure 7-5) displays the trends of selected param- eters in one second, fifteen seconds or one hour intervals. Use this screen to view the most recent data held in short term memory. Data can not be saved.

  • Page 126: Parameters

    • 1 second interval will contain 60 minutes before overwriting • 15 second interval will contain 900 minutes or 15 hours before over- writing • 1 hour interval will contain 3,600 hours or 150 days before overwrit- ing. 7-8 | IPS-4 Analyzer...

  • Page 127: Spectra Menu Screen

    SPECTRA Menu Screen The SPECTRA screen (Figure 7-6) allows the user to temporarily store spectra and compare it to future live spectra readings. Select data source to display Click to Update Chart Click to View Spectra Click to Clear User Data Click to Save User Data Figure 7-6.

  • Page 128: Settings Menu Screen

    Detailed descriptions of each menu item and parameters are described in Chapter 4. The list of available sub-menu items includes: • Calibration Control • Actions • Current Outputs • Relays • Network & Modbus • System & Custom • Analytes • Limits • Diagnostics 7-10 | IPS-4 Analyzer...

  • Page 129: Calibration Settings Screen

    Calibration Settings Screen The CALIBRATION SETTINGS screen (Figure 7-7) displays the avail- able analyzer calibration controls and allows the user to set up and initial- ize the calibration functions. Descriptions of these parameters are de- scribed under “Calibration Settings Screens” in Chapter 4. Use to Set up Calibration View and Modify...

  • Page 130: Actions Screen

    The ACTIONS screen (figure 7-8) allows the user to enter calibration con- centrations and initiate on demand calibration actions. Enter Cal Fluid Concentration Initiate Action View and Modify Settings Click to Save Settings Figure 7-8. Settings Menu Actions Screen. 7-12 | IPS-4 Analyzer...

  • Page 131: Current Output Screen

    Current Output Screen The CURRENT OUTPUT screen (Figure 7-9) displays current output assignments and allows you to set up the parameters for each of the four current outputs. Descriptions of these parameters are described under “Current Output Setup Screens” in Chapter 4. View and Modify Settings Click to Save Settings...

  • Page 132: Relay Setup Screens

    (Relay Function option). Descriptions of these parameters are described under “Relay Setup Screens” in Chapter 4. View and Modify Settings Relay Function Options Click to Save Settings Figure 7-10. Settings Menu Relay Setup Screen. 7-14 | IPS-4 Analyzer...

  • Page 133: Network & Modbus Screen

    Network & Modbus Screen The NETWORK & MODBUS screen (Figure 7-11) allows the user to enter ethernet settings and set up modbus parameters. Ethernet settings Enable the analyzer system to communicate over an Ethernet network for viewing analyzer and stream composition data, viewing analyzer diagnostics, or backing up/restoring analyzer configuration settings.

  • Page 134: System & Customition Screen

    The SYSTEM & CUSTOMIZATION screen (Figure 7-12) allows the user to view and/or setup analyzer system parameters. Use to View System Parameters Customize Display View and Modify Settings Click to Save Settings Figure 7-12. Settings Menu Sytem & Cumstomization Screen. 7-16 | IPS-4 Analyzer...

  • Page 135: Analytes Screen

    Analytes Screen The ANALYTES screen (figure 7-13) allows you to view and modify ana- lyte names and span factor min/max. Use to Use to Change Name Enter Min/Max Values View and Modify Settings Click to Save Settings Figure 7-13. Settings Menu Analyte Screen.

  • Page 136: Limits Screen

    Descriptions of these parameters are described under “Setpoints Screens” in Chapter 4. Use to Change Use to Change Pressure Limits Temperature Limits View and Modify Settings Click to Save Settings Figure 7-14. Settings Menu Limits Screen. 7-18 | IPS-4 Analyzer...

  • Page 137: Diagnostics Screen

    Diagnostics Screen The DIAGNOSTICS screen (Figure 7-15) allows the user to disable normal operations while troubleshooting or setting up external control systems. Descriptions of these parameters are described under “Diagnostics” in Chapter 4. The analyzer should be in normal operations for lamp diagnostics. The lamp does not flash in diagnostics mode.

  • Page 138: Save/Restore Files Screen

    Save/Restore Files Screen The SAVE/RESTORE FILES screen (Figure 7-16) allows you to: • Save IPS-4 software, user configuration settings, and individual files (matrix.xml for example) to your PC. • Restore analyzer configuration parameters to their original factory- shipped settings and upgrade software.

  • Page 139: Modbus Communication Interface

    Remote Terminal Unit (RTU) with the analyzer operating as a slave device. The IPS-4 Analyzer supports RS485 serial communication standards. The physical communication connection between a Model IPS-4 analyzer and a customer DCS\SCADA\PLC\DAS or a general-purpose computer is RS485.

  • Page 140: Confi Guration

    Make sure that you rebooted the analyzer after changing the MBUS- PORT parameter value to 1. NOTE When designing a Modbus RS485 multi-drop communication system with the Model IPS-4 analyzer, the system designer should consider the follow- ing: • Analyzer primary output is moisture concentration and analyzer sta- tus codes.

  • Page 141: Analyzer Modbus Interface Parameters

    Analyzer Modbus Interface Parameters A number of analyzer Modbus interface parameters need to be set up in order to establish communication with the Modbus master. These pa- rameters are accessed via the service port on the analyzer using a service program running on a PC.

  • Page 142: Holding Registers

    PIXELS 1024 char[20] SYSTIME char[20] SYSDATE uint16 ACUNIT char[20] CONCUNIT int16 FLOATFRMT uint16 IDATEFRMT int16 LANGUAGE char[10] PRESUNIT char[10] TEMPUNIT degreeC uint DATAVALID uint16 AUTOCAL int16 CALMODE int16 DMODE int16 MANCMD int16 COMPPT uint SYSALARM1 8-4 | IPS-4 Analyzer...
  • Page 143 Access Data Type Data Size mnemonic Typical value MB Starting Regs MB Reg Size uint SYSALARM2 uint SYSALARM3 uint CONCALARM int16 SYSSTATUS int16 SYSSTATE uint TOTUPTIME uint UPTIME TIMER1 TIMER2 TIMER3 uint MFTIME uint CALTIME uint ZFTIME uint SFTIME int16 ANAHOLD float ANAIN1...
  • Page 144 RELAY6S float RELAY6V uint16 RELAY7 uint16 RELAY7D uint16 RELAY7F char[20] RELAY7NM Relay 7 uint16 RELAY7S float RELAY7V uint16 RELAY8 uint16 RELAY8D uint16 RELAY8F char[20] RELAY8NM Relay 8 uint16 RELAY8S float RELAY8V boolean RELAYENA uint16 VALVE1 8-6 | IPS-4 Analyzer...
  • Page 145 Access Data Type Data Size mnemonic Typical value MB Starting Regs MB Reg Size char[20] VALVE1NM Valve 1 uint16 VALVE2 char[20] VALVE2NM Valve 2 uint16 VALVE3 char[20] VALVE3NM Valve 3 uint16 VALVE4 char[20] VALVE4NM Valve 4 uint16 VALVE5 char[20] VALVE5NM Valve 5 float ACONC1H...
  • Page 146 SAMLIT float SAMLPB float SAMLRTD float SAMLSP 110.00 float SAMLST float VENDEVT int16 VENLAT float VENLDT float VENLHDC 1.00 float VENLIT float VENLPB float VENLRTD float VENLSP float VENLST int16 REMIN1 int16 REMIN2 int16 LAMPM 8-8 | IPS-4 Analyzer...
  • Page 147 Access Data Type Data Size mnemonic Typical value MB Starting Regs MB Reg Size int16 LAMPF int16 FREQ 2000 int16 LAMDF float PRESX1 float PRESXS1 30.00 float PRESXOS1 0.03 float PRESX2 float PRESXS2 float PRESXOS2 float MPRES float APRES int16 VALFAULT int16 HTRFAULT...
  • Page 148 LOGSAVEINT uint SELSPAN char[20] SPANNM1 Span 1 char[20] SPANNM2 Span 2 char[20] SPANNM3 Span 3 char[20] SPANNM4 Span 4 char[20] SPANNM5 Span 5 char[20] SPANNM6 Span 6 char[20] SPANNM7 Span 7 char[20] SPANNM8 Span 8 8-10 | IPS-4 Analyzer...
  • Page 149 Access Data Type Data Size mnemonic Typical value MB Starting Regs MB Reg Size uint SPANMAP1 uint SPANMAP2 uint SPANMAP3 uint SPANMAP4 uint SPANMAP5 uint SPANMAP6 uint SPANMAP7 uint SPANMAP8 char[10] CONCUNIT2 ppmV char[10] CONCUNIT3 ppmV char[10] CONCUNIT4 ppmV char[10] CONCUNIT5 ppmV char[10]...
  • Page 150 1051 int16 STATICPT 1053 float STCELLT 1054 float STCELLP 1056 uint16 ANAOUT1H 1058 uint16 ANAOUT2H 1059 uint16 ANAOUT3H 1060 uint16 ANAOUT4H 1061 uint MINDARK 1062 uint MAXDARK 60000 1064 uint ZEROMININT 1066 float ZERODRIFTMULT 10000000 1068 8-12 | IPS-4 Analyzer...
  • Page 151 Access Data Type Data Size mnemonic Typical value MB Starting Regs MB Reg Size float ALYTE1SPLO 0.85 1070 float ALYTE1SPHI 1.15 1072 float ALYTE2SPLO 0.85 1074 float ALYTE2SPHI 1.15 1076 float ALYTE3SPLO 0.85 1078 float ALYTE3SPHI 1.15 1080 float ALYTE4SPLO 0.85 1082 float...
  • Page 152 TRENDPAR14 1209 int16 TRENDPAR15 1210 int16 TRENDPAR16 1211 int16 TRENDPAR17 1212 int16 TRENDPAR18 1213 int16 TRENDPAR19 1214 int16 TRENDPAR20 1215 int16 TRENDPAR21 1216 int16 TRENDPAR22 1217 int16 TRENDPAR23 1218 int16 TRENDPAR24 1219 float ZEROTOL 1220 8-14 | IPS-4 Analyzer...

  • Page 153: Appendix - Drawings

    APPENDIX – DRAWINGS This Appendix includes many of the drawings that are included in the main body of this manual, plus additional drawings that aren’t. Drawings such as “Analyzer Mounting Details, Unistruts” and “Analyzer Overall Component Layout” are examples only; customer-specific draw- ings for your system are located in the “Supplemental Information”...

  • Page 154: Analyzer Light Path Schematic

    Analyzer Light Path Schematic A-2 | IPS-4 Analyzer...

  • Page 155: Analyzer Mounting Details, Unistruts

    Analyzer Mounting Details, Unistruts Actual layout may vary. Refer to customer-specific drawings in the “Supplemental Information” tab of this manual or the Documentation Package shipped with the analyzer. NOTE Appendix – Drawings...

  • Page 156: Analyzer Overall Component Layout

    Analyzer Overall Component Layout Actual layout may vary. Refer to customer-specific drawings in the “Supplemental Information” section of this manual or the Documen- tation Package shipped with the analyzer. NOTE A-4 | IPS-4 Analyzer...

  • Page 157: Detector Interface Board (100-1937)

    Detector Interface Board (100-1937) Appendix – Drawings...

  • Page 158: Detector Board (403378901)

    Detector Board (403378901) A-6 | IPS-4 Analyzer...

  • Page 159: Display Interface Board (100-1978)

    Display Interface Board (100-1978) Appendix – Drawings...

  • Page 160: Customer Connection Board (100-1971)

    Customer Connection Board (100-1971) A-8 | IPS-4 Analyzer...

  • Page 161: Relay Board (100-1942)

    Relay Board (100-1942) Appendix – Drawings...

  • Page 162: Analog Board (100-1922)

    Analog Board (100-1922) A-10 | IPS-4 Analyzer...

  • Page 163: Mcu Board (100-1914)

    MCU Board (100-1914) Appendix – Drawings A-11...

  • Page 164: Xenon Lamp Board (100-2061)

    Xenon Lamp Board (100-2061) A-12 | IPS-4 Analyzer...

  • Page 165: Electronics Enclosure Wiring Diagram, Sheet 1 Of 3 (Wx-102877)

    Electronics Enclosure Wiring Diagram, Sheet 1 of 3 (WX-102877) Appendix – Drawings A-13...

  • Page 166: Electronics Enclosure Wiring Diagram, Sheet 2 Of 3 (Wx-102877)

    Electronics Enclosure Wiring Diagram, Sheet 2 of 3 (WX-102877) A-14 | IPS-4 Analyzer...

  • Page 167: Electronics Enclosure Wiring Diagram, Sheet 3 Of 3 (Wx-102877)

    Electronics Enclosure Wiring Diagram, Sheet 3 of 3 (WX-102877) Appendix – Drawings A-15...
  • Page 168 This page intentionally left blank. A-16 | IPS-4 Analyzer...

  • Page 169: Supplemental Information

    SUPPLEMENTAL INFORMATION This chapter consists of information that supports the operation of this analyzer. All information in this chapter comprises the Documentation Package. A duplicate of the Documentation Package is also shipped with the analyzer. Information typically included in this chapter includes: •...
  • Page 170 This page intentionally left blank. S-2 | IPS-4 Analyzer...

Table of Contents
