Commissioning
• This product should be connected to the fittings that
are being powered in parallel configuration. The
diagram below shows example fittings connected in
the correct configuration.
• Pay particular attention to the number of units
being fitted and the total wattage of these units. We
recommend a maximum load of 10W for the LED
Driver.
240V
+
Constant Voltage
~
_
LED Driver
50Hz
• Always switch off or disconnect from the mains when
cleaning the product.
• We recommend cleaning with a soft dry cloth. Never
Recycling advice
Waste electrical products should not be disposed of with household waste. Please recycle where facilities
exist. Check with your Local Authority or retailer for recycling advice.
Safety information
• This system contains non-replaceable parts and
cannot be serviced. If damage occurs the part should
be scrapped.
www.saxbylighting.com
43810 - LED Driver.indd 1-2
• Run the cable to the first LED fitting. Using an
appropriate terminal block (not supplied) then connect
the fitting(s) in the configuration shown.
• Replace fuse or circuit breaker and switch on. Your
LED driver is now ready for use.
Fitting
Fitting
Fitting
+ _
+ _
+ _
use scourers, abrasives or chemical cleaners.
• Do not allow moisture to come into contact with
electric parts.
• For your safety, always switch off the supply before
cleaning.
Iss.1 09052012
Saxby Lighting Ltd. BH23 3PE
Instruction leaflet
LED Driver Constant Voltage
43810
11/05/2012 10:28:27
