2. Quick Start Guide

Insert Battery
1
Please fully charge the battery before powering on the gimbal for
the first time.
Remove the bottom cap, insert a 26650 battery and
then replace the cap.
Insert RX0 Camera
To install RX0 camera, please change RX0 camera connection kit.
*RX0 camera connection kit is optional.
Replacement steps
（1）Loose and take down the original fixed plate of the gimbal
（2）Install RX0 adapter plate and tighten the
（3）Insert the set screw
（4）Place the camera and tighten the set screw
2
screw
1
of the camera from the bottom of RX0 adapter plate
3
Insert Camera
2
Please install the camera before powering on the gimbal.
When not in use, turn off the gimbal and then remove the camera.
Take the Gopro HERO 5 camera for example.
Install the camera on retainer plate,then fix the camera with
retainer bar and screw.
Option 1
1-Normal Position 1-Normal Position
* It is suggested to turn on the camera before installation for normal position.
RX0 Adapter
2
Option 2
2-Reverse Position 2-Reverse Position
3
Plate
1
2
