Three Phase Power Unit; Motor Operating Data Table - Three Phase; Overhead Switch; Drum Switch - Rotary Sprinter SPO15 Installation Instructions Manual

MOTOR OPERATING DATA TABLE - THREE PHASE

LINE VOLTAGE RUNNING MOTOR VOLTAGE RANGE
208-240V 50/60Hz.
400V 50Hz.
440-480V 50/60Hz.
575V 60Hz.
NOTES:
1. Unit not suitable for use in unusual conditions. Contact Ro-
tary for moisture and dust environment duty unit.
2. Control Box must be field mounted to power unit.
3. Motor rotation is counter clockwise from top of motor.
3 Phase
Supply
L3
T3 T9
L2
T2 T8
L1
T1 T7
208-240V
50/60Hz. 3Ø

Three Phase Power Unit

197-253V
360-440V
396V-528V
518V-632V
L1 1
L2 3
L3 5
PE

OVERHEAD SWITCH

(WHERE APPLICABLE)
T6 L3
T3
T5 L2 T2
T4
L1 T1
440-480V 50/60 Hz. 3Ø
400V 50 Hz. 3Ø
FOR 3 Ø POWER
UNITS: Attach Box using
M5 x 10 PHMS, Plated
1
2
5
4
7
6
DRUM
SWITCH
T9 T6
T8 T5
T7 T4
9
2
6
MOTOR
8
V2
W1
T3
V1 T2
U2
W2 U1 T1
575V 60 Hz. 3Ø
Fig. 17
