INSTALLATION GUIDE
Exit Device Operators
Generation E-730/630/750/79E/RT Series
630 Series
750 Series
79E/RT Series
E-730 Series

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the E-730 Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Kaba E-730 Series

  • Page 1 INSTALLATION GUIDE Exit Device Operators Generation E-730/630/750/79E/RT Series 630 Series 750 Series 79E/RT Series E-730 Series...
  • Page 2: Table Of Contents

    10. How to Change Lock Cylinders ................16 © 2016 Kaba Ilco, Inc. All trademarks and registered trademarks are the property of their respective owners. E-730/630/750/79E/ RT Series Installation Guide - PK3677_T_04_16...
  • Page 3 Checklist for precision Exit Devices 21/22/FL21/FL22 VON DUPRIN 98/99EO-F/9827/9927 EO-F/9875/9975/9847/9947 E0-F DETEX 10/F10/20/F20/V40 ** DORMA 9100/9300/9400/F9100/F9300/F9400 ARROW S1908/S3908/S1708/S1808/S3708/S3788/S3808/S3888 YALE 7100/7160/7170 HAGER 4500 S-SCREW SARGENT 8710 S-COVER S-SUPPORT Mechanical Override Models ONLY ** Dorma 9300/9400 Series are Panic Hardware only (not fire rated) Dorma F9300/F9400 Series are Fire Rated Hardware Each Generation E-730/630/750/79E lockset includes: Mechanical Override Models ONLY:...
  • Page 4: Bintroduction And Disclaimers

    Caution: Wear safety glasses when making the holes. the steps described. Kaba Ilco is not responsible for damage or malfunction due to incorrect installation, that may arise.
  • Page 5: Dinstall The Lock And The Exit Device

    INSTALL THE LOCK AND THE EXIT DEVICE 1 Install the Mortise (if applicable) For mortise exit devices, install the mortise according to the manufacturer’s instructions . 2 Install the Outside Lever Access Hole Assemble the lever on the outside housing, in The lever is field reversible.
  • Page 6: Install The Lock And Exit Device On The Door

    INSTALL THE LOCK AND THE EXIT DEVICE 4 Install Lock & Exit Device on the door Fig. 3 4.1 Insert the slotted end of the spindle (D) into the outside Spindle Position Fig. 4 housing until it locks, at the correct position for the exit device (see Fig.4).
  • Page 7: Install The Lock And Exit Device With Messenger/Bluetooth On The Door

    INSTALL THE LOCK AND THE EXIT DEVICE (Continued) 5 Install Lock & Exit Device with messenger/Bluetooth on the door Fig. 5 S-SUPPORT Fig. 7 S-COVER S-COVER S-SCREW S-SCREW S-SUPPORT 5.1 Insert the slotted end of the spindle (D) into the outside housing until it locks, at the correct position for the exit device (see Fig.6).
  • Page 8: Etest The Operation Of The E-730/750/79E Lock

    Kaba pattern of access to the door as before. This step...
  • Page 9: Goperating The Emergency Override

    OPERATING THE EMERGENCY OVERRIDE For RT lock series, please refer to system 6000 manual. For multihousing refer to RezShield manual. If the lock will not respond to any keycard (including the Emergency keycard), there are four options that should be attempted to open the door. In order, they are: 1.
  • Page 10: Htest The Operation Of The 630 Lock

    TEST THE OPERATION OF THE 630 LOCK (For 730/750/79E lock go to Section E) 3 Electronic Caution! Perform the following procedures in order, with the door OPEN unless other- wise indicated. A Programming 1 Panic Bar Program the lock with at least one user, using the Oracode Maintenance Unit.
  • Page 11: Installing The Mechanical Override

    INSTALLATION OF THE MECHANICAL OVERRIDE Parts and Tools List Tools Required: (U) Cylinder (provided with lock) or equivalent Small flat scewdriver (less that 1/8”) Diagram of lock: (A) Lock housing (E) Drive tube (I) Cap (B) Inside drive hub (F) Lever catch (J) Cylinder (C) Nylon washer (G) Countersink...
  • Page 12: Upon Unpacking The Lock

    1 Upon unpacking, the lock housing with mechanical override should look like the diagram below with: (A) The small indents on the cross of the over- Important: Assemble the lever, cylinder and ride shaft in line horizontally lock components before affixing the entire (B) The nylon washer and the spring washer unit to the door.
  • Page 13: Preparing The Lever Handle And Cylinder For Installation

    3 Preparing the Lever Handle and 4 Steps to attach the lever handle Cylinder for Installation to the lock housing NOTE: THE POSITION OF THE KEY IS VERY IMPORTANT 3. Insert the cylinder into the lever handle (see Fig.3) 6. Right-handed Lever handle: Turn the key Fig.
  • Page 14: Attaching The Lever Handle To The Lock

    5 Attaching the Lever Handle to the Lock (with the key as shown in Fig . 6 & Fig . 7) 7. Fit the lever handle onto the drive tube. It If it is not possible to turn the key counter- should rest approximately 1/16”...
  • Page 15: Verify The Attachment Of The Lever Handle

    6 Verify the Attachment of the Lever 8 Test the Mechanical Override Handle Function Very Important: To verify that the lever *This test can only be performed when handle has been correctly attached to the lock is not affixed to the door. the housing: 16.
  • Page 16: Cover The Keyhole And Cylinder With Cap

    8 Test the Mechanical Override 10 How to Change Lock Cylinders Function (Continued) 23a. Loosen the set screw (01) to free the lever using Allen Key (P1) (Approx. 1/4 turn). Verify the functionality of the override Fig. 16A after the lock is installed on the door: (01) (P1) 19.
  • Page 17 10 How to Change Lock Cylinders Important: The Key Override itself does not retract the latch or deadbolt. Do not use too much force when turning the key as this may damage the unit. To retract the latch, turn the 31.
  • Page 18 • Consult the dealer or an experienced radio/TV tech- nician for help. Statement according to FCC part 15.21 Modifications not expressly approved by Kaba Ilco could void the user’s authority to operate the equip- ment. Statement according to FCC part 15.19 This device complies with part 15 of the FCC rules and Industry Canada ICES-003.
  • Page 19 E-730/630/750/79E/RT Series Installation Guide - PK3677_T_04_16...
  • Page 20 Kaba Customer Services & Support ILCO: 1.877.468.3555 / + 1.514.340.9025 Saflok: 1.800.999.6213 / + 1.248.837.3700 General Information: www.kabalodging.com Online Consumable Orders: www.ilcostore.com www.saflokstore.com To access all of our easy steps, please visit our Support Website: PK3677_T_04_16 www.kabalodgingsupport.com...
