Metro 130 - Metro 130 Tunnel
Instructions for installation
Please retain this document carefully
95900502UK Install_UK.indd 1
95900502UK Install_UK.indd 1
(GB / IE)
U K
11-07-2008 10:51:12
11-07-2008 10:51:12

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Metro 130 and is the answer not in the manual?

Questions and answers

Related Manuals for Dru Metro 130

Summary of Contents for Dru Metro 130

  • Page 1 Metro 130 - Metro 130 Tunnel Instructions for installation (GB / IE) Please retain this document carefully 95900502UK Install_UK.indd 1 95900502UK Install_UK.indd 1 11-07-2008 10:51:12 11-07-2008 10:51:12...

  • Page 2: Table Of Contents

    Spare parts Foreword As manufacturer of gas heating appliances, DRU develops and produces products to meet the highest possible quality, performance and safety requirements. As a result of which the user is able to enjoy using your appliance for years to come.

  • Page 3: Introduction

    The appliance is available in two models, the Metro 130 and the Metro 130 Tunnel. The Metro 130 is a ‘standard’ gas fi re and should always be installed against a wall. The Metro 199 Tunnel is just that, a ‘tunnel fi re’ with both a front and back window.

  • Page 4: Instructions

    Annex 1 / Table 4 specifi es the components you should have once everything has been unpacked. ➠ Contact DRU Service if after unpacking the appliance you do not have all the components; ➠ Dispose of the packaging in an appropriate manner.

  • Page 5: Positioning The Appliance

    - Allow for the depth of the appliance (see Fig. 2 (Metro 130: minimum of 410 mm; Metro 130 Tunnel: minimum of 450 mm); - Allow for the build-in height; this will depend on the height of the adjustable feet (see Fig.

  • Page 6: Flue Gas Discharge / Combustion Air Supply System

    N.B. - Only use the concentric system supplied by DRU (Ø100 / Ø150 mm). This system was tested in combination with the appliance; DRU cannot guarantee a proper and safe operation of other systems and cannot accept liability for these systems;...
  • Page 7 13 0 - E T R O I N S T R U C T I O N F O R I N S TA L L AT I O N When using this application, you must remove the air inlet guides and change the primary aeration (see section 6.8).
  • Page 8 13 0 - E T R O I N S T R U C T I O N F O R I N S TA L L AT I O N 6.5.3 Application with roof duct 6.5.3.1 Construction of concentric system with roof duct The concentric system with roof duct has to comply with the following conditions ➠...
  • Page 9 13 0 - E T R O I N S T R U C T I O N F O R I N S TA L L AT I O N Table 1: Conditions for adjusting the equipment with roof ducts G20 / G25 total number of total number of meters of vertical and/or sloping pipe lengths...

  • Page 10: Building The Chimney Breast

    - protecting the gas control block and hoses from cement and plaster. !Tip The vents should preferably be created in both sides of the chimney breast: you could use DRU ventilation elements. ➠ Check that the concentric system has been installed correctly;...

  • Page 11: Adjusting The Appliance

    13 0 - E T R O I N S T R U C T I O N F O R I N S TA L L AT I O N !Tip - If the chimney breast is brick, the inner frame can be cemented in during building; - For a chimney breast of any other material, glue/cement the inner frame in place or fi t it with four countersunk screws.
  • Page 12 13 0 - E T R O I N S T R U C T I O N F O R I N S TA L L AT I O N Photo 4 Photo 5 Photo 6a Photo 6b Photo 7 Photo 8 95900502UK Install_UK.indd 12 95900502UK Install_UK.indd 12...
  • Page 13 13 0 - E T R O I N S T R U C T I O N F O R I N S TA L L AT I O N Photo 9 Photo 10 ➠ Fig. 7 Adjust the distance of the damper using the template provided (see - use the template to adjust to 47 mm;...

  • Page 14: Arranging The Logs / Pebbles

    13 0 - E T R O I N S T R U C T I O N F O R I N S TA L L AT I O N Fig. 10a Fig. 10b Fig. 10c Fig. 10d Fig. 11 ➠...

  • Page 15: Glass Window

    13 0 - E T R O I N S T R U C T I O N F O R I N S TA L L AT I O N Photo Photo Photo 12 Photo 13 6.9.2 Pebblestone set The pebblestone set consists of naturally coloured vermiculite;...
  • Page 16 13 0 - E T R O I N S T R U C T I O N F O R I N S TA L L AT I O N Photo 17 Photo 14 Photo 18 Photo 15 Photo 19 Photo 16 Photo 20 6.10.1 Removing the glass window...

  • Page 17: Wireless Remote Control

    13 0 - E T R O I N S T R U C T I O N F O R I N S TA L L AT I O N Photo 21 Photo 22 Wireless remote control See Chapter 4 of the User Manual, ‘Remote Control’, for details of how to operate the system. The remote system consists of a remote control system and a receiver.

  • Page 18: Final Inspection

    13 0 - E T R O I N S T R U C T I O N F O R I N S TA L L AT I O N Photo 26 Photo 27 Photo 28 Final inspection To ensure the appliance is working correctly and safely, check the following before use: 8.1 Gastightness N.B.

  • Page 19: Maintenance

    13 0 - E T R O I N S T R U C T I O N F O R I N S TA L L AT I O N Maintenance The appliance should be inspected, cleaned and if necessary repaired by a qualifi ed installer with professional expe- rience of decorative gas fi...

  • Page 20: Troubleshooting

    13 0 - E T R O I N S T R U C T I O N F O R I N S TA L L AT I O N 11. Troubleshooting A number of faults which could occur, their possible causes and solutions are shown in the table below: Table 3: Troubleshooting Problem Possible cause...
  • Page 21 13 0 - E T R O I N S T R U C T I O N F O R I N S TA L L AT I O N D. One continuous 5 second bleep 1. Loose wiring 1.

  • Page 22: Annex 1 Components Supplied

    Penlight battery (AA type) 923100 Pressure coupling 15 mm x G3/8” 149234 Annex 2 Technical data The technical data for the Metro 130/ Metro 130 Tunnel are given in the table below. Table 5: Technical data Type C11/C31 Gas type...
  • Page 23 13 0 - E T R O I N S T R U C T I O N F O R I N S TA L L AT I O N 95900502UK Install_UK.indd 23 95900502UK Install_UK.indd 23 11-07-2008 10:53:19 11-07-2008 10:53:19...
  • Page 24 DRU Verwarming B.V. The Netherlands Postbus 1021, NL-6920 BA Duiven Ratio 8, NL-6921 RW Duiven 95900502UK Install_UK.indd 24 95900502UK Install_UK.indd 24 11-07-2008 10:53:19 11-07-2008 10:53:19...
