- Page 1 Metro 130 - Metro 130 Tunnel G31 - propane Instructions for installation (GB / IE) Please retain this document carefully...
-
Page 2: Table Of Contents
Spare parts Foreword As manufacturer of gas heating appliances, DRU develops and produces products to meet the highest possible quality, performance and safety requirements. As a result of which the user is able to enjoy using your appliance for years to come. -
Page 3: Introduction
The appliance is available in two models, the Metro 130 and the Metro 130 Tunnel. This version of the Metro 130 and the Metro 130 tunnel is suitable for use with propane. The safe operation of the appliances is guaranteed by the use of a second thermocouple fitted to the main burner. -
Page 4: Instructions
➠ Annex 1 / Table 4 specifies the components you should have once everything has been unpacked. Contact DRU Service if after unpacking the appliance you do not have all the components; ➠ Dispose of the packaging in an appropriate manner. -
Page 5: Positioning The Appliance
- Allow for the depth of the appliance (see Fig. 2 !N.B. (Metro 130: minimum of 410 mm; Metro 130 Tunnel: minimum of 450 mm); - Allow for the build-in height; this will depend on the height of the adjustable feet (see Fig. 1 Move the appliance into its intended position. -
Page 6: Flue Gas Discharge / Combustion Air Supply System
The passage to the outside can be made with a wall duct (see section 6.5.2) or with a roof duct (see section 6.5.3). If necessary, you can also use an existing discharge channel (see section 6.5.4). - Only use the concentric system supplied by DRU (Ø100 / Ø150 mm). This system was tested in combination with the N.B. - Page 7 1 3 0 - e t r o i n s t r u c t i o n f o r i n s ta l l at i o n Connect the concentric pipe sections and the bend(s); ➠...
- Page 8 130 - e t r o i n s t r u c t i o n f o r i n s ta l l at i o n Examples To clarify, we will give 2 examples to determine the allowability of a concentric system and the conditions for setting the appliance.
-
Page 9: Building The Chimney Breast
- the size of the glass window so that it can be fitted/removed once the chimney breast has been built; - protecting the gas control block and hoses from cement and plaster. The vents should preferably be created in both sides of the chimney breast: you could use DRU ventilation elements. !Tip Check that the concentric system has been installed correctly;... -
Page 10: Installing The Control Box
130 - e t r o i n s t r u c t i o n f o r i n s ta l l at i o n 6.7 Installing the control box The control box is to be installed as low as possible. The control box contains various components such as the type plate, the gas control block, and the receiver for the remote control. -
Page 11: Arranging The Logs / Pebbles
1 3 0 - e t r o i n s t r u c t i o n f o r i n s ta l l at i o n 6.8.2 Air inlet guides (L) The air inlet guides (L) are located at the bottom (side) of the tray around the burner. Remove them as follows;... - Page 12 130 - e t r o i n s t r u c t i o n f o r i n s ta l l at i o n Photo 4 Photo 5 Photo 6a Photo 6b Photo 7 Photo 8...
- Page 13 1 3 0 - e t r o i n s t r u c t i o n f o r i n s ta l l at i o n Photo 9a Photo 9b Photo 10a Photo 10b 6.9.1 Logs The log set consists of vermiculite (see Photo...
- Page 14 130 - e t r o i n s t r u c t i o n f o r i n s ta l l at i o n Foto 14a Foto 17a Foto 17b Foto 14b Foto 17c Foto 17d Foto 15 Foto 16...
-
Page 15: Glass Window
1 3 0 - e t r o i n s t r u c t i o n f o r i n s ta l l at i o n Foto 18 Foto 19 The burn marks on the branches will help you identify them. !Tip Arrange branches A-E around the (main) burner (see Photos 6a and 6b... -
Page 16: Wireless Remote Control
130 - e t r o i n s t r u c t i o n f o r i n s ta l l at i o n - Make sure you hold the upper handgrip firmly. If you let go of the handgrip then the glass frame could fall inwards !N.B. -
Page 17: Final Inspection
1 3 0 - e t r o i n s t r u c t i o n f o r i n s ta l l at i o n Photo 21 Photo 22 - connect the adapter to the receiver (see , arrow C);... -
Page 18: Flame Effect
130 - e t r o i n s t r u c t i o n f o r i n s ta l l at i o n Photo 26 Photo 27 Photo 28 a) If not, the ignition wire is probably touching something metal; b) If it does, there is probably air in the pipes. -
Page 19: Completion
1 3 0 - e t r o i n s t r u c t i o n f o r i n s ta l l at i o n If necessary, place back the wood set / pebblestone set correctly; see section 6.9. N.B. -
Page 20: Troubleshooting
130 - e t r o i n s t r u c t i o n f o r i n s ta l l at i o n 11. Troubleshooting A number of faults which could occur, their possible causes and solutions are shown in the table below: Table 3: Troubleshooting Problem Possible cause... - Page 21 1 3 0 - e t r o i n s t r u c t i o n f o r i n s ta l l at i o n Table 3: Troubleshooting Problem Possible cause Solution E. No pilot 1.
- Page 22 130 - e t r o i n s t r u c t i o n f o r i n s ta l l at i o n Table 3: Troubleshooting Problem Possible cause Solution J. Main burner ignites, but goes 1.
-
Page 23: Annex 1 Components Supplied
Penlight battery (AA type) 923100 Pressure coupling 15 mm x G3/8” 149234 Annex 2 Technical data The technical data for the Metro 130/ Metro 130 Tunnel are given in the table below. Table 5: Technical data Country Pre-pressure in mbar Type... - Page 24 130 - e t r o i n s t r u c t i o n f o r i n s ta l l at i o n DRu Verwarming B.V. The Netherlands Postbus 1021, NL-6920 BA Duiven...
