- Page 1 8FX Family 8-bit Microcontroller BGM Adaptor MB2146-07-E User Manual Doc. No. 002-04814 Rev. *A Cypress Semiconductor 198 Champion Court San Jose, CA 95134-1709 Phone (USA): 800.858.1810 Phone (Intnl): +1 408.943.2600 www.cypress.com...
- Page 2 Cypress is not liable, in whole or in part, and you shall and hereby do release Cypress from any claim, damage, or other liability arising from or related to all Unintended Uses of Cypress products.
-
Page 3: Table Of Contents
How to Upgrade BGMA FW ..........................17 Flash USB Direct Programmer........................17 Additional Information ............................19 Revision History ................................20 Revision History ..............................20 Document Revision History ............................. 20 New 8FX Family BGM Adaptor MB2146-07-E User Manual, Doc. No. 002-04814 Rev. *A... -
Page 4: Checking The Delivered Product
Before using the product, make sure that the package contains the following items: BGM adaptor *: USB cable (1.0m): Hardcopy (China RoHS report) *:Referred to as the adaptor. New 8FX Family BGM Adaptor MB2146-07-E User Manual, Doc. No. 002-04814 Rev. *A... -
Page 5: Introduction
MB2146-08-E and similar to MB2146-08-E in appearance. MB2146-07-E has inherited all functions of MB2146-08-E. It is updated to compatible with the new 0.18um MCU and obtain a better performance and new functions. This user manual is applicable to all series of Cypress 8-bit microcontroller except MB95F200 and MB95F210 series. -
Page 6: Block Diagram
Figure 3-1 shows the block diagram of MB2146-07-E Figure 3-1: Block Diagram Gates circuit Debug PC USB interface Target USB socket interface Power test Switcher MB2146-07-E New 8FX Family BGM Adaptor MB2146-07-E User Manual, Doc. No. 002-04814 Rev. *A... -
Page 7: Interface Introduction
4.1 MB2146-07-E Appearance Figure 4-1 shows the BGMA appearance Figure 4-1. BGMA Appearance Mode key User interface connector Interface cable Status LED Power LED Power key USB connector New 8FX Family BGM Adaptor MB2146-07-E User Manual, Doc. No. 002-04814 Rev. *A... -
Page 8: Bgma Usb Interface
Connected to the MCU Vss pin. BGMA→MCU RSTIN Tool reset output BDSU, Initialization of users logic Connected to user System reset BGMA←MCU RSTOUT User System reset output circuit New 8FX Family BGM Adaptor MB2146-07-E User Manual, Doc. No. 002-04814 Rev. *A... - Page 9 1 line UART BGMA→MCU The BGMA can read the LPC MCU status by command. For detailed command please refer to “18um LPC MCU BGMA FW External Specification” New 8FX Family BGM Adaptor MB2146-07-E User Manual, Doc. No. 002-04814 Rev. *A...
-
Page 10: Feature List
5. Feature List This chapter describes the BGMA feature. The MB2146-07-E BGMA is updated from MB2146-08-E. Following items describe the updated feature. Dedicate for 2 0.18um MCU Baud rate(max): 0.35um---125K(uploading), 1 0.18um---500K, 2 0.18um---1M Baud rate selection between 500K and 1M in 2 0.18um... - Page 11 Twinkling Logging data record time is over 255*(8k-9) *1: for 3.3V power MCU, the power range is 1.8~3.6V For 5V power MCU, the power range is 2.4~5.5V New 8FX Family BGM Adaptor MB2146-07-E User Manual, Doc. No. 002-04814 Rev. *A...
-
Page 12: Performance Description
If user wants to upgrade the BGMA code when starting debugging, check Monitor Program Auto-load in Setup Wizard Dialog Box, as shown in Figure 6-1. Figure 6-1. Monitor Program Auto-load New 8FX Family BGM Adaptor MB2146-07-E User Manual, Doc. No. 002-04814 Rev. *A... - Page 13 In this dialog box, user can select LPC MCU external clock value in Frequency(main) Field, and enable or disable clock up in Response Speed Optimization Field. Figure 6-3. Clock Setting New 8FX Family BGM Adaptor MB2146-07-E User Manual, Doc. No. 002-04814 Rev. *A...
- Page 14 This dialog box is used to select the start debug uploading function. If the dialog box is selected, the Softune will read all MCU flash data to Softune. Figure 6-5. Flash Synchronization New 8FX Family BGM Adaptor MB2146-07-E User Manual, Doc. No. 002-04814 Rev. *A...
-
Page 15: Ram Monitor Performance
Right click the blank area in Ram Monitor window Selecting Monitoring from shortcut menu will enable RAM monitor, as shown In Figure 6-7. Figure 6-7. RAM Monitor New 8FX Family BGM Adaptor MB2146-07-E User Manual, Doc. No. 002-04814 Rev. *A... - Page 16 When all RAMs are selected, user can click „OK‟ key to ensure those settings and close the window. After that, user can monitor all selected RAMs in RAM monitor window, as shown in Figure 6-9. Figure 6-9. RAM Monitor Status New 8FX Family BGM Adaptor MB2146-07-E User Manual, Doc. No. 002-04814 Rev. *A...
-
Page 17: How To Upgrade Bgma Fw
When OK key appears, press OK key, refer to Figure 6-3 Press Erase key, When OK key appears, press OK key Press Open key to select Hex File New 8FX Family BGM Adaptor MB2146-07-E User Manual, Doc. No. 002-04814 Rev. *A... - Page 18 14. Power off BGMA, switch „S2‟ to „NOR‟ Figure 7-2 shows the OK key Figure 7-2. Selectable OK Key Figure 7-3 shows the complete OK key Figure 7-3. OK Key New 8FX Family BGM Adaptor MB2146-07-E User Manual, Doc. No. 002-04814 Rev. *A...
-
Page 19: Additional Information
8. Additional Information For more Information on MB2146-07-E (BGM adapter)and monitor program, Please visit our website: http://www.cypress.com/documentation/development-kitsboards/mb2146-07-e http://www.cypress.com/documentation/software-and-drivers/monitor-program Please contact your local support team for any technical question. New 8FX Family BGM Adaptor MB2146-07-E User Manual, Doc. No. 002-04814 Rev. *A... -
Page 20: Revision History
Revision Issue Date ECN# Origin of Description of Change Change 04/01/2015 HUAL Migrated to Cypress and assigned Document number 002-04814 06/14/2016 5264449 HUAL Migrated to Cypress format New 8FX Family BGM Adaptor MB2146-07-E User Manual, Doc. No. 002-04814 Rev. *A...
