- Page 1 TnT300 OWNER’S MANUAL...
-
Page 2: Table Of Contents
• Safe Driving Tips................................9 • Riding Gear................................9 Vin Number Location..............................10 Location of Parts................................11 • Meter & Indicators..............................13 Primary Parts................................15 • Ignition Switch................................15 • Left Handlebar Switch.............................16 • Right Handlebar Switch............................17 • Fuel Tank.................................18 • Rear Shock Absorber...............................19 • Rear Brake Pedal..............................21 TnT300... - Page 3 • How to start the engine............................25 • Smooth Acceleration...............................26 • Changing gears................................27 Inspection & Maintenance............................27 • Maintenance Schedule............................27 • Oil Level & Oil Change.............................31 • Spark Plug................................32 • Catalytic Converter..............................32 • Battery..................................33 • Throttle Cable Adjustment............................36 • Clutch Adjustment..............................37 • Chain Adjustment..............................37 TnT300...
- Page 4 TABLE OF CONTENTS • Brake..................................39 • Air Filter Maintenance............................41 • Bulb Replacement..............................41 • Fuse Replacement..............................42 • Lubrication Points..............................43 • Valve Clearance Adjustment............................43 • Tires..................................43 Storage Guidelines..............................45 Specifications & Technical Parameters........................47 Emissions Control System Warranty...........................48 TnT300...
-
Page 5: Special Warning
Burnt fuses are usually caused by an internal electrical fault or short. If the fuse blows immediately upon replacement, bring the vehicle to an authorized Benelli dealership for inspection and repair. You should only ride the vehicle once repairs have been made. -
Page 6: Preface
Specially trained personnel are available at any authorized Benelli/SSR Dealer to provide you with service, parts and accessories. With the persistent pursuit of quality tenet – “making consumers more satisfied”, the company has been continuously improving both the quality and performance of the product. -
Page 7: Safety Notes
Attention ------------Refers to the explanation as to facilitate maintenance or make clear important notes. SAFETY NOTES Note: For safety purposes, the rider should be fully read and comprehend the safety notes and features outlined in this manual before riding. TnT300... - Page 8 7. Any aftermarket accessories installed shall not affect the safe riding and operation of the motorcycle. Overloading of the electrical system could lead to unsafe operation or damage to the vehicle. 8. DO NOT operate the motorcycle within closed spaces, this could lead to carbon monoxide poisoning and/or death. TnT300...
- Page 9 3. DO NOT wear loose clothing that can become caught in the control levers, pedals or wheels. Any loose items should be secured with a strap or rubber band before riding. TnT300...
- Page 10 The Vehicle Identification Number (VIN) is stamped into the right side of the frame along the steering stem tube. The Engine Number is stamped into the lower crankcase of the engine on the right hand side. Please write these numbers down below for your reference. VIN: Engine Number: TnT300...
- Page 11 PARTS LOCATIONS ① Clutch Lever ② Left Handlebar Switch ③ Combination Meter Assy. ④ Ignition Switch ⑤ Right Handlebar Switch ⑥ Front Brake Lever ⑦ Throttle TnT300...
- Page 12 PARTS LOCATIONS ⑧ Rear Shock Absorber ⑨ Rear Brake Pedal ⑩ Gear Change Lever ⑪ Side Stand ⑫ Fuel Tank TnT300...
-
Page 13: Meter & Indicators
This indicator will light when the left turn signal is activated. 2. RIGHT TURN SIGNAL INDICATOR This indicator will light when the right turn signal is activated. 3. HIGH BEAM INDICATOR This indicator will light when the high beam headlight is activated. TnT300... - Page 14 A and function B buttons are pressed simultaneously, the displaying units of coolant temperature, mileage and speed can be switched between metric and imperial units. 8. TACHOMETER The tachometer indicates the engine’s revolutions per minute. 9. COOLANT TEMPERATURE GAUGE This gauge shows the current vehicle temperature. TnT300...
-
Page 15: Primary Parts
14. FUEL INJECTION TROUBLE INDICATOR This warning light will light up when there is a problem with the fuel injection system. It can be used to perform the self-diagnosis procedure. PRIMARY PARTS IGNITION SWITCH “OFF” position: All electrical circuits are off. TnT300... -
Page 16: Left Handlebar Switch
Turn the switch to the “ “ position, the left turn signal lamp will flash; turn the switch to the “ “ position, the right turn signal lamp will flash. The indicator on the meter will flash accordingly when either switch is activated. TnT300... -
Page 17: Right Handlebar Switch
Caution: During normal operation the engine stop switch should be in the “ “ (run) position. Only use this switch for emergency situations, for example: after and accident or if experiencing ignition switch problems. TnT300... -
Page 18: Fuel Tank
“ (off) position when you need to refuel. Do not forget to lock the fuel tank cap after adding fuel in case of evaporation to the air, which is a waste of energy and would pollute the environment. Don’t use fire when refueling. TnT300... -
Page 19: Rear Shock Absorber
Caution: Rotate this adjusting knob by hand only, and never use too much force, or the rear suspension will be damaged. This will be deemed as abnormal usage, and will not be covered by the warranty. TnT300... -
Page 20: Rear Brake Pedal
Slow down the vehicle when shifting to lower gears. Revving up the engine slightly to shift gears is a smoother way to shift and avoid damaging gears. Caution: When the transmission is in the neutral position, the neutral indicator lamp will turn on. Slowly release the clutch lever to make sure the transmission is in the neutral position before completely releasing it. TnT300... -
Page 21: Tool Kit
Notice: Using lead free gasoline can extend the service life of the spark plugs. Engine Oil Please use a fully synthetic four-stroke engine oil, it should be equal to or higher than API SAE service grade SF. The specification is SJ10W/50. TYPE Fully Synthetic Oil SJ10W-50 pr SN 15W-50 2.8L TnT300... -
Page 22: Break In
It is strongly suggested to use the vehicle very carefully during its break-in period. PRE-RIDE INSPECTIONS Item Check 1) Stable Handlebar 2) Turns Smoothly 3) Not loose or bent 1) Correct adjustment at lever and brake pedal Braking 2) Not spongy feeling TnT300... - Page 23 Correct oil level 1) Appropriate free play in throttle grip Throttle 2) Smooth operation 1) Appropriate free play in clutch lever Clutch 2) Smooth operation, doesn’t stick when returning to closed 1) Appropriate adjustment Drive Chain 2) Appropriate lubrication TnT300...
-
Page 24: How To Start The Engine
Do not rev the vehicle to high engine RPM’s when it is not being ridden, this could cause the engine to overheat and damage it’s internal parts. Warning: Do not start the engine indoors with bad ventilation or without ventilation. Do not leave a started vehicle running when no one else is around. TnT300... -
Page 25: Smooth Acceleration
Notice: It is dangerous to only use either the front brake or rear brake which may cause skidding or loss of control. Be careful and use the brakes properly and evenly when you drive on wet or winding roads. TnT300... -
Page 26: Inspection & Maintenance
Better to consult authorized dealers to do inspection and maintenance for safety’s sake. MAINTENANCE SYMBOLS: I: Inspection: (cleaning, adjustment, replacement) C: Cleaning R: Replacement A: Adjustment L: Lubrication TnT300... -
Page 27: Maintenance Schedule
Throttle Operation Air Filter Per 4000mi: I or R Spark Plug Valve Per 15000mi: I Clearance Engine Oil Per 4000mi: R Engine Oil Per 4000mi: R Filter Fuel Injection Drive Chain Per 500mi: I / L / A Battery TnT300... - Page 28 3000mi 5500mi 8000mi 10500mi 13000mi Brake Pad Wear Brake System Hydraulic Brake System Hoses Replace every two years Hydraulic Brake System Fluid Replace every two years Clutch Engine Mounts Nuts, Bolts, and Fasteners Wheels/Tires Steering Stem Bearings Cooling System TnT300...
-
Page 29: Oil Level & Oil Change
4. Fill the engine with qualified engine oil. 5. Start the engine and allow it to idle for several minutes then turn it off. 6. Make sure the oil level reaches the upper limit mark without any oil leakage. TnT300... -
Page 30: Spark Plug
Since the catalytic converter is very important, a defective catalytic converter will pollute the air and damage the performance of the engine, if a replacement part is needed, please use genuine Benelli parts or entrust your dealership to replace it. -
Page 31: Battery
Place the battery vertically on a horizontal plane and remove the foil sealing tape. b. Remove the electrolyte from the plastic bag. Remove its cover strip and set it aside to use laster as the filling plug for the battery. TnT300... - Page 32 The battery will produce explosive gases when the chemical reaction occurs within it. Keep the battery away from fire, spark and high temperature places. The battery is filled with sulfuric acid (electro- lyte). Electrolyte is poisonous substance. Please keep it out of the reach of children. TnT300...
-
Page 33: Throttle Cable Adjustment
The suggestion made here is for regular maintenance, it’s recommended that the chain adjustment be checked before every ride. Accidents such as the chain detaching or serious damage to the engine can be caused by an exces- sively loose chain. TnT300... -
Page 34: Brake
Don’t forget to check the fluid level in the front & rear brake fluid reservoir. Add the appropriate brake fluid if necessary. Brake pads Check if the front and rear brake pads have been worn to their limits. Replace the brake pads if over the limit. TnT300... -
Page 35: Air Filter Maintenance
4. Immerse the filter element in a foam air filter element oil, after saturation, squeeze out any excess oil. 5. Reinstall the components in the reverse order of disassembly. Caution: Highly flammable liquids like gasoline or organic solvents cannot be used to clean the air filter element. TnT300... -
Page 36: Bulb Replacement
Contact your authorized dealer for repair. Always use fuses of the same specification as indicated. Warning: It is dangerous to use fuses of incorrect specifications, which could result severe failures like melted wires, or fire. TnT300... -
Page 37: Lubrication Points
“Maintenance Schedule”. Adjustment should be performed by professional technicians with the corresponding tools needed. In order to keep the valve clearance in good condition, we strongly recommend you to leave it up to an authorized dealer for this maintenance requirement. TnT300... -
Page 38: Tires
Driving a motorcycle with tires that are excessively worn will reduce the driving stability or even cause a loss of control. When the tire tread of front wheel is less than 1.6mm, and the rear wheel tread is less than 2mm, replacement is strongly recommended. TnT300... -
Page 39: Storage Guidelines
1. Remove the cover and clean the motorcycle. Change the engine oil if you kept your motorcycle in storage for more than four months. 2. Install the battery and charge it as needed. 3. Wash away the anti-rust agent in the fuel tank, and add new petrol into the fuel tank. TnT300... -
Page 40: Specifications & Technical Parameters
Maximum Torque........18.44 ft-lbs/6500r/min High beam indicator lamp..........12V 2W Ignition System Type..............TLI Turning indicator .............12V 3W Compression Ratio..............12:1 Horn Specification.............12V 3A Start Type............Electric Starting CAPACITY Transmission System Fuel Tank (includes reserve tank)........16±0.5L Clutch..............Wet, Multi-disc Fuel Type................. 91 SIX SPEED TRANSMISSION TnT300... -
Page 41: Emissions Control System Warranty
SSR United States Environmental Protection Agency or the California recommends that you retain all receipts covering maintenance Air Resources Board for the periods specified above. on your vehicle, but SSR cannot deny warranty solely for the lack TnT300... - Page 42 A. The liability of SSR under this emission control system war- ranty is limited solely to the remedying of defects in material or workmanship by an authorized SSR’ dealer at its place of busi- ness during customary business hours. TnT300...
- Page 43 However, SSR is not liable for these parts. The owner is responsible for the performance of all required maintenance. Such maintenance may be performed at a service establishment or by any individual. The warranty period begins on the date the motorcycle is delivered to an ultimate purchaser. TnT300...
- Page 44 Benelli Q.J. S.r.l. Strada della Fornace Vecchia 3, 61122 Pesaro - Italy...
