  • Page 1 TNT 15...

  • Page 2: Introduction

    WARNING INTRODUCTION Please read this manual carefully and completely Welcome to the world of motorcycling! before operating this vehicle. As the owner, you are benefiting from the vast experi- ence and newest technology regarding the design IMPORTANT MANUAL and manufacture of high-quality products, which have INFORMATION earned us a reputation for dependability.

  • Page 3: Table Of Contents

    INTRODUCTION ● Engine break-in Safety information ● Parking PERIODIC MAINTENANCE AND ● Safe-riding ADJUSTMENT ● Further safe-riding points DESCRIPTION ● Periodic maintenance chart ● Left view ● Checking the spark plug ● Right view ● Engine oil ● Controls and instruments ●...

  • Page 4: Safety Information

    ● This vehicle is designed to carry the operator and SAFETY INFORMATION a passenger. ● The failure of motorists to detect and recognize Be a Responsible Owner vehicles in traffic is the predominating cause of automobile/vehicle accidents. Many accidents have As the vehicle's owner, you are responsible for the been caused by an automobile driver who did not safe and proper operation of your vehicle.
  • Page 5 thoroughly familiar with the vehicle and all of its con- the result of head injuries. The use of a safety helmet trols. is the most critical factor in the prevention or reduc- ● Many accidents have been caused by error of the tion of head injuries.

  • Page 6: Further Safe-Riding Points

    or smell any engine exhaust. Deadly levels of carbon ● Railroad crossings, streetcar rails, iron plates on monoxide can collect rapidly and you can quickly be road construction sites,and manhole covers become overcome and unable to save yourself. Also, deadly extremely slippery when wet.

  • Page 7: Description

    DESCRIPTION Left view km/h Right view Clutch lever 8 Kick start lever Left handle switch 9 Rear brake pedal Meter Fuel tank switch Key switch Shift pedal Main stand Right handle switch Side stand Throttle grip Front brake lever...

  • Page 8: Controls And Instruments

    INSTRUMENT AND CONTROL CONSUMER INFORMATION FUNCTIONS ● The vehicle identifi- Key Switch cation number ① is stamped on the right “ ” （Off） position: side steering head All the circuits are off. tube. ● The engine serial “ ” （On） position: number ②...

  • Page 9: Meter & Indicator

    Meter & Indicator km/h TRIP 1. TURNING INDICATOR 3. HIGH BEAM INDICATOR LAMP When the high beam lamp of the headlamp turns on, the high beam indicator lamp would be on. 2. TURNING INDICATOR...
  • Page 10 4. NEUTRAL INDICATOR LAMP 7. TACHOMETER When the transmission is in the neutral, the green Tachometer indicates the revolution per minute of engine. indicator lamp would be on. 8. SPEEDOMETER 5. FUNCTION BUTTON A Speedometer shows the running speed, hours/kilometers. Short press the button to switch between trip and 9.

  • Page 11: Handlebar

    HANDLEBAR Dimmer switch LEFT HANDLE Turn the switch to " " position, the high beam of headlamp turn on and the indicator lamp on the meter would also turn on; turn the switch to " " position, the low beam of headlamp turn on. Direction indicator lamp switch Turn the switch to "...

  • Page 12: Fuel Tank Switch & Fuel Tank

    Front brake lever Engine stop switch Pull the brake lever properly to use the front brake. When the switch is on " " position and the power is on, the engine runs. Throttle grip When the switch is on " "...

  • Page 13: Rear Shock Absorber

    (Reserve) position WARNING When the fuel switch is on " " (Reserve) position, Do not over fill the fuel tank. Do not make fuel fuel would supply from reserve level. splashes on hot engine. Please stop the engine and turn the ignition key to "...

  • Page 14: Rear Brake Pedal

    REAR BRAKE PEDAL and road conditions. Adjust when vehicle it is stable on the main stand or side stand, turn the preload Step the rear brake pedal to brake the rear wheel. ring to the place required. Brake light will turn on while rear brake is in use. SOFTER SOFTER STIFFER...

  • Page 15: Pre-Operation Checks

    PRE-OPERATION CHECKS ITEM CHECKS Disc brake • Check operation. Inspect your vehicle each time you use it to make ( If equipped ) • If soft or spongy, have dealer bleed sure the vehicle is in safe operating condition. hydraulic system. Always follow the inspection and maintenance pro- •...

  • Page 16: Operation And Important Riding Points

    OPERATION AND IMPORTANT ITEM CHECKS RIDING POINTS Wheels and tires • Check for damage. • Check tire condition and tread depth. STARTING THE ENGINE • Check air pressure. 1. Check whether the fuel switch handle is on " " Brake levers •...

  • Page 17: Acceleration And Deceleration

    ACCELERATION AND DECELERATION WARNING The speed can be adjusted by opening and closing It is dangerous only to use either the front brake the throttle. To increase the speed, turn the throttle or rear brake which may cause skid or lose grip in direction (a).

  • Page 18: Parking

    vehicle owner/operator. The most important points of range. It is strongly suggested to use the vehicle vehicle inspection, adjustment, and lubrication are very carefully during its running in period; also the explained on the following pages. The intervals given rider has to be familiar to the performance. in the periodic maintenance and lubrication chart should be simply considered as a general guide under normal riding conditions.

  • Page 19: Periodic Maintenance Chart

    PERIODIC MAINTENANCE CHART ODOMETER READING ITEM CHECKS 1000Km 4000Km 7000Km 10000Km 13000Km 16000Km 3 months 6 months 9 months 1 year 15 months ● ● Fuel line • Check fuel hoses for cracks or crack ● ● Spark plug • Check condition. Clean and regap. ●...
  • Page 20 ODOMETER READING ITEM CHECKS 1000Km 4000Km 7000Km 10000Km 13000Km 16000Km 3 months 6 months 9 months 1 year 15 months ● ● ● ● ● ● Rear brake lever • Lubricate with silicone grease. pivot shaft ● ● ● ● ●...

  • Page 21: Checking The Spark Plug

    CHECKING THE SPARK PLUG The spark plug is an important engine component, which should be checked periodically, preferably by a dealer. Since heat and deposits will cause any Type spark plug to slowly erode, it should be removed and DR8EA checked in accordance with the periodic mainte- nance.
  • Page 22 2. Start the engine, warm it up for several minutes, NOTICE and then turn it off. 3. Wait a few minutes until the oil settles, remove The engine oil should be between the minimum the oil filler cap,wipe the dipstick clean, insert it back and maximum level marks.

  • Page 23: Idle Speed

    IDLE SPEED AIR FILTER Good carburetion is the key of engine performance. The air filter element should be replaced and should Keep the original condition of the carburetor, as set be cleaned at the intervals specified in the periodic in the factory. Pay attention to these two items for maintenance and lubrication chart.

  • Page 24: Checking The Throttle Cable Free Play

    CHECKING THE THROTTLE CABLE CHECKING THE FRONT BRAKE LEVER AND FREE PLAY REAR BRAKE PEDAL FREE PLAY For the brake lever and brake pedal free play, please The throttle cable free play should measure 3.0–5.0 refer to the following parameters as shown. Periodi- mm at the throttle grip.

  • Page 25: Checking The Drum Limit

    CHECK THE DRUM LIMIT Check if braking function is excellent, and if the limit index extension line is within the allowable Adjustment Nut range, as shown in Figure A. ● Turn the adjustment nut on brake arm of rear 3. If the limit index extension line is beyond the wheels to adjust the free play of rear brake .

  • Page 26: Checking The Battery

    BRAKE FLUID (IF EQUIPPED) CHECKING THE BATTERY The vehicle uses the disc brake . Adjustment is finished before delivery. Contact dealer if any prob- Ask the dealer to add electrolyte for normal battery. lem. Have a dealer charge the battery as soon as pos- sible if it seems to have discharged.

  • Page 27: Replacing The Fuses And Bulbs

    REPLACING THE FUSES AND BULBS If a fuse or bulb for the individual circuits is blown, Horn 12V 3A replace it as follows. Headlight bulb 12V 35W/35W 1. Turn the key to “OFF” and turn off the electrical Turn light 12V 10W circuit in question.

  • Page 28: Storage

    dard range. Adjust the tire pressure under a "cold" 2. Lubricate drive chain. condition. 3. Drain fuel in fuel tank and carburetor out. Install the fuel tank cover again. 4. Detach the spark plug and add one teaspoon of TIRE INFORMATION (15~20cm ) clean engine oil to cylinder.

  • Page 29: Specification

    SPECIFICATION Ignition System Type ............... Size and Weight ............. Compression Ratio 9.27:1 Length ................2105mm Tire .................. Width 795mm Front tire ................ 90/90-17 ................Height 1055mm Rear tire 120/80-17 ............................... Wheelbase 1340mm Fuel Dry Weight ................129kg Fuel Tank (include reserve tank) ..........
  • Page 30 Details described or illustrated in this booklet may differ from the vehicle's actual specification as purchased, the accessories fitted or the national-market specification. No claims will be asserted as a result of such discrepancies. Dimensions, weights, fuel consumption and performance data are quoted to the customary tolerances.
