- Page 1 TNT249S USER’S MANUAL...
-
Page 2: Table Of Contents
Safety Driving Rules ....................................Protection Clothes ..................................... Serial Number ........................................Location of Parts ....................................... Meter & Indicator ......................................Primary Parts ........................................Key switch ........................................Left Handle ........................................Right Handle ......................................... Fuel Tank ........................................Rear Shock Absorber ....................................Rear Brake Pedal ......................................TNT249S... - Page 3 How to start the engine ..................................Smooth launching ....................................To change gear ......................................Inspection& Maintenance ..................................Maintenance Schedule ..................................Oil Level & Oil Change ................................... Spark plug ........................................Catalytic Converter....................................Battery .......................................... Throttle Cable Adjustment ................................... Clutch Adjustment ....................................Chain Adjustment ....................................TNT249S...
- Page 4 CONTENTS Brake ..........................................Maintenance of Air Filter..................................Bulb Replacement ...................................... Fuse Replacement ...................................... Lubrication points ...................................... Adjustment of Valve Clearance ................................Tire ........................................... Storage Guideline ......................................Speci cation & Technical Parameter ................................. TNT249S...
-
Page 5: Serial Number
Vehicle identi cation number (VIN) (IF EQUIPPED)is printed on the right side of the head tube. The engine number is printed on lower part of the right case of engine crank case. Please write down the numbers for your reference. VIN: Engine Number: TNT249S... -
Page 6: Location Of Parts
LOCATION OF PARTS Left view Right view Clutch lever Throttle grip Front brake lever Left handle switch Rear shock absorber ABS switch(if equipped) Rear brake pedal Meter Key switch Shift pedal Meter function button Side stand Right handle switch Tank TNT249S... -
Page 7: Meter & Indicator
LOCATION OF PARTS Meter & Indicator Daytime mode TNT249S... - Page 8 LOCATION OF PARTS Night mode TNT249S...
- Page 9 When the pointer is in between C and H, the temperature is a speci c period. normal. It should stop to check the water tank if the pointer is higher than H level. TNT249S...
-
Page 11: Primary Parts
”（O ) position: All the circuits are o . Note： Do not turn your key to lock the vehicle while driving which is not necessary and is also apt to cause accident. Press the key in a proper force. TNT249S... -
Page 12: Left Handle
When passing other vehicles, press this button so the high beams of the headlamp would ash to alarm the vehicles in front of you. Alarm： Turn on the direction signal lamps in time when changing the driveway or turning a direction and turn o the lamps. TNT249S... - Page 15 PRIMARY PARTS To apply the brake effectively, use the front brake lever and rear brake pedal simultaneously in the same • . manner as conventional vehicle brake system TNT249S...
-
Page 17: Right Handle
In ODO mode, turn o the key. To adjust the clock, turn on the key switch and immediately long press the set button, when released, the hour digit will start ashing on the meter. Short press the set button to change the number, or long-press to move the ashing digit TNT249S... -
Page 18: Fuel Tank
" (O ) position when you need to refuel. Do not forget to lock the fuel tank cover after adding the fuel in case of evaporation to the air, which is waste of energy and would pollute the environment. Don't use re when refueling. TNT249S... -
Page 19: Rear Shock Absorber
2. Turn the adjust knob in opposite direction, and count for clicking sound. The total adjustable range is 66 clicks from the zero point, in normal riding, the setting should be 5~10 clicks according to the road condition and rider's preference. TNT249S... -
Page 20: Rear Brake Pedal
This motorcycle is equipped with six-speed SHIFT PEDAL constant mesh gearbox. Caution: When the transmission is on neutral position, the indicator lamp would turn on. Slowly release the clutch lever to make sure the transmission is on the neutral position. TNT249S... -
Page 21: Tool Bag
It is a must to use lead free gasoline. Use gasoline contains octane number more than 92. Notice： Use lead free gasoline can extend the working life of spark plug. Engine Oil Type Full synthetic oil SL10W-50 JASO MA2 Capacity 3.2L±0.1L TNT249S... -
Page 22: Running In
INSPECTION BEFORE DRIVING Please check on the following contents which are very important before driving, Content Comments 1) Stable 2) Turn smoothly Handlebar 3) No sliding or loose 1）Right clearance of the lever and brake pedal Braking 2）No sponge feeling TNT249S... - Page 23 Engine Oil Correct oil level Correct oil level 1）Appropriate free play in clutch lever Throttle 2）Smooth operation 1）Appropriate free play in throttle cable Clutch 2）Smooth operation, no stuck when returning to full close position 1）Appropriate tightness Driving Chain 2）Appropriate lubrication TNT249S...
-
Page 24: How To Start The Engine
Do not run the engine in high speed when you do not drive the motorcycle, or it will become overheating and damage its inner parts. Warning: Do not start the engine indoor with bad ventilation or without ventilation. Do not leave a starting motorcycle when no one else is around. TNT249S... -
Page 25: Smooth Launching
When drive on uphill road, motorcycle will slow down and seem to be lack of power. Switch to low gears so that engine can generate normal power. Shift the gear swiftly to prevent motorcycle from losing speed. Turn to low speed gears in order to brake when driving on downhill slope. Don't over rev the engine. Brake usage and stopping TNT249S... - Page 26 Shift to neutral position before starting the engine. Turn the power key to the position " " to stop the engine. Remove ignition key from the switch after locking for security reason. TNT249S...
-
Page 27: Inspection& Maintenance
Better to consult authorized dealers to do inspection and maintenance for safety's sake. MAINTENANCE SCHEDULE: TNT249S... -
Page 28: Oil Level & Oil Change
Oil Change & Oil Filter Replacing 1. Take down the oil lter with the special tool and oil drain bolt before oil draining. 2. Replace the oil lter with a new one if needed. TNT249S... -
Page 29: Spark Plug
Do not Screw the spark plug too tight to avoid damaging the threads of cylinder cover. Don't let the foreign objects fall into the engine through spark plug hole during dismounting. CATALYTIC CONVERTER In order to meet the requirements of environmental emission, the mu er of the motorcycle is equipped with catalytic converter. TNT249S... -
Page 30: Battery
It is not necessary to re ll electrolyte in the future. If you have to take out the battery for inspection, please follow these steps： a. Shut o power switch of the motorcycle; 12V8Ah（YTX9-BS） b. Remove the seat cushion; MF (Maintenance Free) Battery TNT249S... - Page 31 Connect the wire polarities correctly. Positive wire (red) shall be connected with the positive terminal（＋）; and negative wire（black）to the negative terminal（－）. Tighten terminal bolts. Clean frequently the erosive substances on the terminals with a wire brush while in use. Please operate according to the following requirements while lling electrolyte into the maintenance-free battery: TNT249S...
- Page 32 (The electrolyte cannot be taken down now). e. When the electrolyte has completely owed through, tap the container bottom several times to drain residual electrolyte; and then slowly pull out the electrolyte container. TNT249S...
-
Page 33: Throttle Cable Adjustment
The battery is lled with sulfuric acid (electrolyte). Electrolyte is poisonous substance. Please keep it out of reach of children. THROTTLE CABLE ADJUSTMENT 1. Screw o the lock nut. 2. Turn the adjustor to make the cable clearance within10-20mm. 3. Retighten the lock nut after adjustment of cable clearance. TNT249S... -
Page 34: Clutch Adjustment
10~20mm. Make regular adjustment of the chain according to your driving condition. Warning： Suggestions here are for regular maintenance schedule it's recommended for inspection and adjustment of the chain before each driving. Accident as chain detaching or serious damage on engine can be caused by excessively slack chain. TNT249S... - Page 35 (2) Damaged roller (3) Rusty chain link (4) Twisted or snarled link (5) Excessive free play (6) Loose chain The sprocket is probably damaged, if any above-mentioned problems on the chain are found. Check the following items for sprocket: TNT249S...
-
Page 36: Brake
Don't forget to check the amount level in the front brake uid reservoir. Add appropriate brake uid if necessary. Brake pads Check the front and rear wheel brake pads whether have been worn to limits. Change the pads if over the limit. TNT249S... - Page 37 3. Check the feedback feeling on brake lever 4. Check abrasion condition of the front and rear wheel brake pads Rear Brake To adjust the stroke of rear brake pedal, screw or turn the adjusting bolt of rear brake, the free play be adjusted to 20~30mm. TNT249S...
-
Page 38: Maintenance Of Air Filter
Those highly ammable liquid like gasoline and organic solvent cannot be used for cleaning the lter element. BULB REPLACEMENT Replacing of Head Lamp Bulb Take o the cover, replace the old bulb with the same speci cation one, and nally set up in the reversed orders. TNT249S... -
Page 39: Fuse Replacement
Contact with the authorized dealer for proper repairing. FUEL FUEL Use the fuses for the same speci cation as indicated. PUMP PUMP Warning: It's dangerous to use other speci cations of fuse, which would result severe failures ABS fuse like burning, ring. TNT249S... -
Page 40: Lubrication Points
Side stand and its spring Throttle cable Pivot of front brake lever Pivot of clutch lever ADJUSTMENT OF VALVE CLEARANCE Check and adjust the valve clearance when the engine is cold. The Standard Valve Clearance: Intake Valve: 0.15-0.19mm, Exhaust Valve: 0.20-0.25mm TNT249S... -
Page 41: Tire
However, too high pressure will reduce the contact area between tire and ground, thus causing slipping or even getting out of control. Tire pressure should be kept in the standard range. Adjust the tire pressure under a "cold" condition. Front Wheel 190kpa Rear Wheel 210kpa TNT249S... -
Page 42: Storage Guideline
6. In ate tire to the required pressure. Put the motorcycle on a block to make two tires o the ground. 7. Cover the motorcycle (no plastic or coating material) and keep it in the place with consistent temperature and low humidity. Do not keep your motorcycle under direct sunlight. TNT249S... - Page 43 1. Take o the cover and clean the motorcycle. Change engine oil if you keep your motorcycle for more than four months. 2. Install the battery and do charging as needed. 3. Wash away the anti-rust agent in fuel tank, and add new petrol into fuel tank. TNT249S...
- Page 44 High beam indicator lamp...........12V 2W Maximum Torque........21.2N.m/9000r/min Turning indicator ............12V 3W Ignition System Type..............TLI Horn Speci cation............12V 3A Compression Ratio..............12:1 CAPACITY Start Type............Electric Starting Fuel Tank (include reserve tank)......16±0.5L Transmission System............Chain Fuel Type..............92 & above Clutch..............Wet multi-plate TNT249S...
