Kuryakyn 8637 Quick Manual

f o r k b r a c e a n d d u S t c o v e r S
f o r g l 1 8 0 0
fItS: all '01-uP gl1800 (ex. aIrbag modelS)
PartS Included
1 Gold Wing Fork Brace
1 Right Side Fork Brace Cover
1 Left Side Fork Brace Cover
2 Lower Filler Fork Brace Covers
2 Alcohol Pads
1 Installation Instructions
Please read and understand entire instructions before starting installation.
thank you for chooSIng küryakyn!
In order to Protect you and otherS from PoSSIble Injury
and/or ProPerty damage or loSS, PleaSe Pay cloSe attentIon
to all InStructIonS, warnIngS, cautIonS and attentIon noteS
regardIng the uSe and care of thIS Product.
CAUTION! This indication alerts you to the fact that ignoring the contents described herein
can result in potential injury or material damage.
ATTENTION! This indication alerts you to the fact that ignoring the contents described herein
may negatively affect product performance and functionality.
toolS SuggeSted
Set of hex wrenches, warm soapy water and clean rag.
StrIctly obServe the followIng guIdelIneS In order to uSe the
Product ProPerly and avoId PotentIally dangerouS accIdentS.
Procedure
SteP 1
Read and understand all steps in the instructions before starting the installation.
Park the motorcycle on a hard, level surface and turn off the ignition.
note: Before starting installation, place the
motorcycle on the center stand on a
hard level surface.
SteP 2 Remove the front fender by
removing the 4 setting bolts and two
rubber washers on the lower setting
bolts as shown. See FIG. 1.
SteP 3
Remove the fork cover by removing
the two bolts and trim clip shown.
The cover, bolts and trim clip will not
be re-installed. See FIG. 2.
-cont.-
8637-12GL-1008
8 6 3 7
FIG. 1
