6. Disassembling and
assembling of the
flush valve
14 14
Disassembling and assembling APP 11-13 and APP 16-22
1. Unscrew the flushing valve counter
clockwise by using the pin wrench.
3. Put a small amount of lubrication on the
thread on the plug. Screw it into the port
flange. Tighten with a torque of 30 Nm +/-
3 Nm.
180R9228 / 521B1181 / DKCFN.PI.013.A2.02 / 10.2013
2. Remove the o-rings (green and black).
If necessary change the valve cone, spring
and plug.
It is important that if the spring is changed
it is located like on the picture.
Carefully use a screwdriver. The end of the
spring must be against the shoulder of the
valve cone.
