CDP
Figure 2: Final switch bus position.
2.1.1. INVERTER CONNECTION
Figure 3 shows the connection between the CDP and a single inverter.
Connect the end bus terminal to the IN and OUT terminals.
Figure 3: Connection between a CDP and a single Fronius inverter.
The master / slave selector must be in the Master position (Figure 4).
Figure 4: Master / Slave selector.
8
