PowerTac WARRIOR-G4FL User Manual

USAGE INSTRUCTIONS
1. To install battery: Unscrew tail cap. Insert positive end of the battery
towards LED. Tighten the tail cap till it's completely closed.
2. To turn the light ON: Push the back switch to click. Once Turned on the
ashlight will access the mode last used. To Turn the Light OFF, push the
back button to click.
3. To switch light levels: Turn the light on and press the side switch (click).
Press side switch again (click) will cycle to next light level.
4. Access the direct to strobe function: When the light is o , hold down the
side switch or turn light on and hold down side switch (long click, 0.3
seconds). The light will remain on strobe until you switch light levels
using the side button.
RECHARGE INSTRUCTIONS
MAGNETIC CHARGING:
1. plug in the usb charging cable to power source
2. Attach magnetic end of charging cable to mangetic charge port
3. The status indicator will turn "RED" to indicate charging mode.
4. When charging is complete the indicator light will change from "RED"
to "BLUE"
MICRO USB CHARGING:
1. Using a blunt pointed object (IE: Ball-Point pen tip) , carefully insert
under rubber portion of magnetic charge port and lift up to remove
the magnetic charge port component.
2. Once exposing the waterproof micro usb charge port insert a standard
micro usb charging cable to begin charging.
3. Charging indicator will function exactly the same as if using the
magnetic option.
LED Type: Cree XHP70 White LED
Battery: (1) 18650 HIGH DISCHARGE Rechargeable Li-ion or (2) CR123A
NOT compatible with RCR123A / 16340
Size: Length:151.9 mm
Bezel Diameter: 36.5mm
Body Diameter: 25.4mm
Weight: 152g (without battery)
Illumination:
Firefly Low Medium High
0.72 Lumens 95 Lumens 333 Lumens 1430 Lumens
60 days 15 hrs 5.06 hrs 1.23 hrs
HEAD
Turbo Strobe
4200 Lumens 830 Lumens
1.23 hrs 3.05 hrs
BATTERY TUBE
WARRIOR-G4FL
RECHARGEABLE FLASHLIGHT
USER MANUAL
