PowerTac E9R User Manual

INTRODUCTION
The Powertac E9R is extremely powerful and compact. Second to none for its tactical applications; Featuring one handed operation to control four brightness levels and a direct
to strobe function. Using the latest CREE XM-L2 U3 LED to produce a maximum of 1020 Lumens. The E9R is machined from aircraft grade aluminum, which makes it lightweight
and durable. Having an IPX-6 waterproof rating gives you peace of mind when using in inclement weather. Able to be submersible up to 2 meters makes a perfect t for law
enforcement, outdoor enthusiasts, hunters, and EDC. The included tactical holster is perfect for law enforcement, security guards, and soldiers alike. With the ability to mount the
E9R on any weapon platform, it elevates the light's tactical functionality. Disrupting vision with every push of the button when set on high or strobe. The advantage de nitely
goes to the person who wields the E9R.
USAGE INSTRUCTIONS
1. To install battery: Unscrew tail cap. Insert positive end of the battery
towards LED. Tighten the tail cap till it's completely closed.
2. To turn the light ON: Push the back switch to click. Once Turned on the
ashlight will access the mode last used. To Turn the Light OFF, push the
back button to click.
3. To switch light levels: Turn the light on and press the side switch (click).
Press side switch again (click) will cycle to next light level.
4. Access the direct to strobe function: When the light is o , hold down the
side switch or turn light on and hold down side switch (long click, 0.3
seconds). The light will remain on strobe until you switch light levels.
5. Toggle Strobe / High Function: Access direct to strobe function; release
side switch; hold down side switch again (long click) and light will toggle
to high mode. Hold down side witch again (long click) and toggle to
strobe again.
Maintenance
Every 3 months, threads should be wiped with a clean cloth followed by a
thin coating of silicon-based lubricant.
LED TYPE: CREE XM-L2 U3 LED
ILLUMINATION FUNCTIONS
Mode: Fire y Low Medium
Output: 1 lm 150 lm 415 lm
Runtime: 305 hrs 13.6 hrs 5.3 hrs
Battery: (2) CR123A or (1) 18650 Rechargeable Li-ion.
or (2) RCR123A / 16340
Size:
Length: 140mm
Bezel Diameter: 25.4mm
Body Diameter: 23mm
Weight: 82.7g (without battery)
HEAD BATTERY TUBE
High Strobe
1020 lm 1020 lm
2.4 hrs 5 hrs
E9R
RECHARGEABLE
TACTICAL FLASHLIGHT
USER MANUAL
