PowerTac Scholar User Manual

INTRODUCTION
The Scholar Pen light is the perfect companion to any
o cer or executive. Available in two versions, An
Aircraft Aluminum Body and a Stainless Steel Body.
Both feature a 140 Lumen light on it's rear with easy
strobe access and non evasive crown providing just the
right amount of texture for your thumb to grip in self
defense situations. The Scholar does not look like a
Tactical Pen but outperforms the best of them. Choose
the version that is best for your lifestyle Lightweight
(Aluminum Version), Weighted (Stainless Steel Version)
, Both are ridged enough to puncture.
Stylish and functional with a ne tip gel ink well ,
providing a smooth writing experience.
LED Type: CREE XP-G2 (White)
Battery: AAA - Alkaline, NiMh
(Batteries NOT included)
Size: Length: 153 mm
Body Diameter: 14.5 mm
Weight: 35g - Aluminum (without battery)
80g - Stainless Steel (without battery)
ILLUMINATION FUNCTIONS
Mode: Fire y High Strobe
Output: 3 lm 140 lm 140 lm
Runtime: 33 hrs 0.6 hrs 1.2 hrs
* Above test are performed with PANASONIC
1000mAh Ni-MH AAA Battery in PowerTac Lab.
USAGE INSTRUCTIONS
1. Battery Installation:
1. Loosen the ashlight head (1) from the battery tube.
2. Insert 1 AAA Battery into the battery tube (2) with the
(+) toward the led end (1).
3. Tighten the ashlight head (1) securely to battery
tube (2).
2. Operation:
1. On / O : Short click the button on the side of the
head will activate the light. Short click again will
deactivate the light.
2. Stobe: When the light
is on ; long click the
side button. Repeat
will return light to
high setting.
When the light is o : Long click to activate stobe.
3. Operate Pen Component:
1. Rotate the pen head (4) counter clockwise to
extend ink tip.
2. Rotate Clockwise to retract ink tip
4. Change Ink Cartridge:
1. Loosen (3) from (2) as shown below.
2. Use a small screwdriver to carefully loosen the pen
re ll.
3. Remove used ink cartridge and replace with new ink.
4. Carefully tighten cartridge and re-assemble.
SCHOLAR
TACTICAL FLASHLIGHT PEN
140 MAX LUMENS
USER MANUAL
