PowerTac E5 Generation IV User Manual

INTRODUCTION
The E5 generation IV high-power LED ashlight is designed speci cally to be the ultimate Every Day Carrying (EDC) and tactical light. It is built with cutting-edge technology,
unparalleled performance, exceptional craftsmanship, and unbeatable reliability. It comes with a user-friendly interface for simple operation and multi-functions for di erent
situations. It is perfectly engineered to be extremely portable and powerful. It delivers on design, performance, quality and reliability. Making it the preferred choice by many
professionals and ideal for military, law enforcement, adventurists, hunters, and search and rescue.
USAGE INSTRUCTIONS
1. To install battery: Unscrew tail cap. Insert positive end of the battery
towards LED. Tighten the tail cap till it's completely closed.
2. To turn the light ON: Push the back switch to click. Once Turned on the
ashlight will access the mode last used. To Turn the Light OFF, push the
back button to click.
3. To switch light levels: Turn the light on and press the side switch (click).
Press side switch again (click) will cycle to next light level.
4. Access the direct to strobe function: Turn light on and hold down side
switch (long click, 0.3 seconds). The light will remain on strobe until you
switch light levels.
5. Toggle Strobe / High Function: Access direct to strobe function; release
side switch; hold down side switch again (long click) and light will toggle
to high mode. Hold down side witch again (long click) and toggle to
strobe again.
Maintenance
Every 3 months, threads should be wiped with a clean cloth followed by a
thin coating of silicon-based lubricant.
LED TYPE: CREE XM-L2 U2 LED
ILLUMINATION FUNCTIONS
Mode: Fire y Low Medium
Output: 2 lm 82 lm 416 lm
Runtime: 706 hrs 15 hrs 3 hrs
Battery: (2) CR123A or (1) 18650 Rechargeable Li-ion.
NOT compatible with RCR123A / 16340
Size: Length:128.5mm
Bezel Diameter: 25.4mm
Body Diameter: 22mm
Weight: 69g (without battery)
HEAD BATTERY TUBE
High Strobe
980 lm 980 lm
1.5 hrs 3 hrs
E5
TACTICAL FLASHLIGHT
USER MANUAL
