PowerTac PATROLMAN LE-10X User Manual

USAGE INSTRUCTIONS
• On / O Function: Press power switch
• Change Modes: Rotate the rotatry selector switch
LOW BATTERY INDICATOR
• 30% depleted the power switch will turn "RED"
• 10% depleted the power switch will FLASH "RED"
CHARGING INSTRUCTIONS
• Plug AC charger into power supply.
• Attach magnetic end of charging cable to the charging port on ashlight. (once
attached the Battery Indicator will turn "RED"
• When charging is complete, the indicator will change from "RED" to "BLUE"
FEATURES & SPECIFICATIONS
• 3 Di erent brightnes modes in each size con guration
• Machined from aircraft grade aluminum with type III
anodized nish
• XTreme Knurling of exterior body for comfortable and
secure grip
• Digital circuit-control technology monitors light output
for consistent operation
• Precision engineered optical lens produces focused and
proportioned light
• Battery polarity protection
Speci cations:
LED Type: CREE XHP70 White LED
Battery: Custom 2 Cell 32650 (6500 mAh)
Rechargeable Li-Ion
Size: Length: 121.5 mm
Body Diameter: 14.5 mm
Weight: 30g (without battery)
Illumination Functions:
Low Medium High
Output 155 Lumens 610 Lumens 4200 Lumens
Runtime 56 hrs 13hrs 3.78 hrs
Power Switch /
Low Battery Indicator
Charge Port
PATROLMAN
Strobe S.O.S.
1820 Lumens 1820 Lumens
6.4 hrs 6.4 hrs
LE-10X
Rotary Selector Switch
USER MANUAL
