Summary of Contents for Black Box LPH3061A
- Page 1 STEP X - Name of Step QUICK START GUIDE LPH3061A INDUSTRIAL POE SWITCH 24/7 TECHNICAL SUPPORT AT 877.877.2269 OR VISIT BLACKBOX.COM...
- Page 2 STEP 1 - Package Includes WHAT’S INCLUDED • (1) LPH3061A INDUSTRIAL SWITCH • (2) WALLMOUNTING BRACKETS WITH SCREWS • (1) DIN RAIL MOUNTING BRACKET WITH SCREWS • THIS QUICK START GUIDE...
- Page 3 STEP 2 - LPH3061A Hardware Overview TABLE 1. LPH3061A COMPONENTS NUMBER DESCRIPTION 3, 4, 5 6-pin terminal block for power SFP cage Power 1 LED Power 2 LED Power Fail LED Link/Activity LED Speed LED (5) RJ-45 connectors...
- Page 4 STEP 2 - Install the SFP Choose a compatible SFP from Table 2 TABLE 2. COMPATIBLE SFPS and snap it into place in the SFP cage on the switch. PRODUCT DESCRIPTION CODE LFP401 SFP/155 Ext. Diag., MM 2-km, LC NOTE: The SFPs are ordered separately. LFP402 SFP/155 Ext.
- Page 5 STEP 3 - Connect the Power POWER CONNECTION STEPS The LPH3061A switch supports dual 48 VDC power inputs and changes relay status when the power fails. 1. Insert the positive and negative wires into the V+ and V- contacts on the terminal block connector.
- Page 6 STEP 4A - DIN Rail Mounting INSTALLING THE DIN RAIL KIT Attach the DIN rail bracket to the DIN rail using the included screws. See Figure A. REMOVING THE DIN RAIL KIT Remove the screws from the DIN rail. 2. Lift the switch up and off from the DIN rail. See Figure B.
- Page 7 STEP 4B - Wallmounting WALLMOUNTING STEPS Using the included screws, attach the wallmount brackets to the switch. 2. With the brackets attached, hang the switch on the nails on the wall.
- Page 8 STEP X - Name of Step COPYRIGHT 2017 BLACK BOX CORPORATION. ALL RIGHTS RESERVED.
