Hubbell GAI-TRONICS SP2 Instruction Manual

Poe handset/speaker amplifier station
Hide thumbs Also See for GAI-TRONICS SP2:
Table of Contents

Advertisement

Quick Links

Download this manual
SP2 POE Handset/Speaker
Confidentiality Notice .....................................................................................................................1
General Information .......................................................................................................................1
Product Overview ................................................................................................................................... 1
Features .................................................................................................................................................... 2
Options ..................................................................................................................................................... 2
Installation ......................................................................................................................................3
Important Safety Instructions................................................................................................................ 3
Mount the Enclosure ............................................................................................................................... 4
Cable Entries ........................................................................................................................................... 4
Open the Station ...................................................................................................................................... 5
Field Wiring and Configuration ............................................................................................................ 5
Station Ground ...................................................................................................................................... 5
Termination PCBA Connections .......................................................................................................... 6
Direct Speaker Connection and Jumper Settings .............................................................................. 6
RTU Inputs ........................................................................................................................................ 8
RTU Output ...................................................................................................................................... 8
Main PCBA-600-Ohm Audio I/O with Control ................................................................................. 9
POE Interface PCBA .......................................................................................................................... 10
Settings and Adjustments ..............................................................................................................11
Open the Station .................................................................................................................................... 11
Main PCBA Configuration .................................................................................................................. 12
Write Protect (EEPROM) Jumper ....................................................................................................... 12
WDOG Enable (Watchdog) Jumper ................................................................................................... 12
Boot Enable Jumper ............................................................................................................................ 12
Reset Switch ........................................................................................................................................ 12
Speaker and 600-ohm Audio Output Volume ..................................................................................... 13
Receiver Volume ................................................................................................................................ 13
Group and Station Number Selector Switches .................................................................................... 13
Main PCBA Indicators ......................................................................................................................... 14
Power LED .......................................................................................................................................... 14
Heartbeat LED .................................................................................................................................... 14
Ethernet Connection LEDs ................................................................................................................. 14
Five Configurable LEDs ..................................................................................................................... 14
Install the Front Cover ......................................................................................................................... 14
GAI-TRONICS 3030 KUTZTOWN RD. READING, PA 19605 USA
610-777-1374 ◼ 800-492-1212 ◼ Fax: 610-796-5954
V
ISIT WWW
G A I - T R O N I C S
A H U B B E L L C O M P A N Y
Amplifier Station
T
A B L E O F
.
-
.
GAI
TRONICS
COM FOR PRODUCT LITERATURE AND MANUALS
®
C
O N T E N T S
Pub. 42004-788L2A

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GAI-TRONICS SP2 and is the answer not in the manual?

Questions and answers

Related Manuals for Hubbell GAI-TRONICS SP2

Summary of Contents for Hubbell GAI-TRONICS SP2

  • Page 1: Table Of Contents

    Pub. 42004-788L2A G A I - T R O N I C S ® A H U B B E L L C O M P A N Y SP2 POE Handset/Speaker Amplifier Station A B L E O F O N T E N T S Confidentiality Notice ........................1 General Information ........................1...
  • Page 2 Table of Contents Pub. 42004-788L2A Programming ..........................14 Operation ............................14 Standard Handset Paging ........................14 Party Line Communication ........................15 All-Call Button Use ..........................15 Alternate-Page Destination Switch Use ....................16 Headset Use............................16 Maintenance ..........................17 Troubleshooting ............................ 17 Service ..............................18 Replacement Parts ..........................

  • Page 3: Confidentiality Notice

    GAI-Tronics Corporation and may not be reproduced in any form without express written permission from GAI-Tronics. General Information Product Overview The GAI-Tronics SP2 POE station is part of a modular industrial multicast VoIP (Voice over Internet Protocol) communication system. The standard SP2 POE configuration is an indoor, multi- party, handset/speaker amplifier station using POE (Power over Ethernet) with RTU control.

  • Page 4: Features

    Pub. 42004-788L2A SP2 POE Handset/Speaker Amplifier Station Page 2 of 19 Features • flexible and highly configurable SMART technology featuring Ambient Level Sensing (ALS), real time self-diagnostics, and available remote monitoring • real-time operation providing instantaneous page and party line communication •...

  • Page 5: Installation

    Pub. 42004-788L2A SP2 POE Handset/Speaker Amplifier Station Page 3 of 19 Installation Important Safety Instructions • Read, follow, and retain instructions—All safety and operating instructions should be read and followed before operating the unit. Retain instructions for future reference. • Heed warnings—Adhere to all warnings on the unit and in the operating instructions.

  • Page 6: Mount The Enclosure

    Pub. 42004-788L2A SP2 POE Handset/Speaker Amplifier Station Page 4 of 19 Mount the Enclosure Mount the enclosure using the four 0.312- inch (8 mm) diameter holes located on the mounting flanges with ¼-inch (M6) hardware. The suggested mounting height for all station enclosures is 48 inches (1219 mm) to the center of the bottom mounting holes of the enclosure.

  • Page 7: Open The Station

    Pub. 42004-788L2A SP2 POE Handset/Speaker Amplifier Station Page 5 of 19 Open the Station Complete the following steps to open the station: 1. Remove the four screws from the front panel and turn it to the left to expose the interior surfaces. 2.

  • Page 8: Termination Pcba Connections

    Pub. 42004-788L2A SP2 POE Handset/Speaker Amplifier Station Page 6 of 19 Termination PCBA Connections Install all connections as indicated in the following sections: Figure 4. SP2 Standard Termination PCBA Direct Speaker Connection and Jumper Settings Terminal block TB1 provides termination for the station’s 8 or 16-ohm remote speaker(s). 1.
  • Page 9 Pub. 42004-788L2A SP2 POE Handset/Speaker Amplifier Station Page 7 of 19 Table 1. Direct Speaker Connections—TB1 Label Description TB1-1 Parallel/S A Series—Output PEAKER ⏚ TB1-2 Earth Reference TB1-3 − Parallel/S A Series—Output PEAKER TB1-4 Parallel/S B Series—Output PEAKER ⏚ TB1-5 Earth Reference TB1-6 −...

  • Page 10: Rtu Inputs

    Pub. 42004-788L2A SP2 POE Handset/Speaker Amplifier Station Page 8 of 19 RTU Inputs The standard termination PCBA contains two unsupervised auxiliary RTU inputs. Terminate these inputs at terminal block TB2 (see Figure 4). 1. Pull the RTU Input cable(s) into the enclosure. 2.

  • Page 11: Main Pcba-600-Ohm Audio I/O With Control

    Pub. 42004-788L2A SP2 POE Handset/Speaker Amplifier Station Page 9 of 19 Figure 6. RTU Output Wiring—TB2 Main PCBA—600-Ohm Audio I/O with Control SP2 stations provide a 600-ohm audio input to facilitate broadcasting line level audio over the page line. A control input exists that requires a normally open dry contact closure to enable the station to broadcast the 600-ohm input audio.

  • Page 12: Poe Interface Pcba

    Pub. 42004-788L2A SP2 POE Handset/Speaker Amplifier Station Page 10 of 19 Figure 7. SP2 Main PCBA (POE) POE Interface PCBA Terminate the Ethernet cable to terminal block TB1 on the POE Interface PCBA (see Figure 8). The POE interface PCBA is mounted on top of the main PCBA: 1.

  • Page 13: Settings And Adjustments

    Pub. 42004-788L2A SP2 POE Handset/Speaker Amplifier Station Page 11 of 19 Table 5. Ethernet Connection—TB1 Label Description DC− TB1-1 Negative dc voltage TB1-2 DC− Negative dc voltage TB1-3 RX− Data Receive − TB1-4 Positive dc voltage TB1-5 Positive dc voltage TB1-6 Data Receive + TB1-7...

  • Page 14: Main Pcba Configuration

    Pub. 42004-788L2A SP2 POE Handset/Speaker Amplifier Station Page 12 of 19 Main PCBA Configuration Refer to Figure 10 for the switch, jumper, and LED locations on the Main PCBA. Figure 10. Main PCBA (Front and Rear Views) Write Protect (EEPROM) Jumper : This jumper should not be changed in the field.

  • Page 15: Speaker And 600-Ohm Audio Output Volume

    Pub. 42004-788L2A SP2 POE Handset/Speaker Amplifier Station Page 13 of 19 Speaker and 600-ohm Audio Output Volume The speaker volume potentiometer, R36, adjusts the signal level to the speaker from the page line. When 600-ohm audio is also connected, R36 will adjust the volume for both. The volume for the 600-ohm audio must be configured via the CLI (Command Line Interface) when only the 600-ohm audio output is utilized.

  • Page 16: Main Pcba Indicators

    Pub. 42004-788L2A SP2 POE Handset/Speaker Amplifier Station Page 14 of 19 Main PCBA Indicators Power LED The Power LED located on the Main PCBA illuminates when power is applied to the station indicating the main board power supply is operational (see Figure 10). Heartbeat LED The Heartbeat LED located on the Main PCBA flashes after the microprocessor is operational (see Figure 10).

  • Page 17: Party Line Communication

    Pub. 42004-788L2A SP2 POE Handset/Speaker Amplifier Station Page 15 of 19 4. After the short preannouncement tone is heard (if configured), speak directly into the microphone to broadcast your page announcement. : SP2 stations incorporate a noise-canceling microphone to reduce transmitted ambient noise. This requires the user to place the microphone as close as possible to their mouth.

  • Page 18: Alternate-Page Destination Switch Use

    Pub. 42004-788L2A SP2 POE Handset/Speaker Amplifier Station Page 16 of 19 Alternate-Page Destination Switch Use Use the A option selector switch to page one of five alternate destinations that have been programed for the station (see Figure 12). Alternate page destinations must be software configured for the SP2 station.

  • Page 19: Maintenance

    Pub. 42004-788L2A SP2 POE Handset/Speaker Amplifier Station Page 17 of 19 Maintenance Troubleshooting The following table is provided to aid qualified service personnel in troubleshooting problems with the SP2 Station. Problem Solution • check wiring and cable terminations station not functional •...

  • Page 20: Service

    Pub. 42004-788L2A SP2 POE Handset/Speaker Amplifier Station Page 18 of 19 Service Contact a regional service center for a return authorization number (RA#) if the equipment requires service. Equipment must be shipped prepaid to GAI-Tronics with a return authorization number and a purchase order number.

  • Page 21: Approvals

    Pub. 42004-788L2A SP2 POE Handset/Speaker Amplifier Station Page 19 of 19 Speaker Amplifier Maximum output: 8-ohm speaker* POE Plus......14 W +/−1.0 dB into 8-Ω load with −6 dBFs data signal, default: 4 W @ 8 Ω POE ........6 W +/−1.0 dB into 8-Ω load with -6 dBFs data signal, default 4 W @ 8 Ω 16-ohm speaker ...............................

  • Page 22: Return Policy

    Warranty Equipment. GAI-Tronics warrants for a period of one (1) year from the date of shipment, that any GAI-Tronics equipment supplied hereunder shall be free of defects in material and workmanship, shall comply with the then-current product specifications and product literature, and if applicable, shall be fit for the purpose specified in the agreed-upon quotation or proposal document.
