Pub. 42004-719L2C G A I - T R O N I C S ® A H U B B E L L C O M P A N Y 701-904 SmartSeries Handset/Speaker ® Amplifier with Auxiliary Jack A B L E O F O N T E N T S Confidentiality Notice ........................1 General Information ........................1... - Page 2 Table of Contents Pub. 42004-719L2C SmartVolume™............................. 14 Handset Amplifier ..........................14 Mechanical ............................. 14 Environmental ............................15 Approvals ............................15 GAI-TRONICS 3030 KUTZTOWN RD. READING, PA 19605 USA 610-777-1374 ◼ 800-492-1212 ◼ Fax: 610-796-5954 ISIT WWW TRONICS COM FOR PRODUCT LITERATURE AND MANUALS...
-
Page 3: 701-904 Smartseries
Pub. 42004-719L2C G A I - T R O N I C S ® A H U B B E L L C O M P A N Y 701-904 SmartSeries Handset/Speaker ® Amplifier with Auxiliary Jack Confidentiality Notice This manual is provided solely as an installation, operation, and maintenance guide and contains sensitive business and technical information that is confidential and proprietary to GAI-Tronics. -
Page 4: Features And Options
Pub. 42004-719L2C ® 701-904 SmartSeries Handset/Speaker Amplifier with Auxiliary Jack Page 2 of 15 Features and Options • • page and party line communication from the *optional SmartSeries station RTU with integral handset or an auxiliary headset supervision of input and output devices •... -
Page 5: Internal Components
Pub. 42004-719L2C ® 701-904 SmartSeries Handset/Speaker Amplifier with Auxiliary Jack Page 3 of 15 Internal Components The assembly contains the following internal components or subassemblies (see Figure 2): • chassis • front panel attached to the front of the chassis •... -
Page 6: Interfaces
Pub. 42004-719L2C ® 701-904 SmartSeries Handset/Speaker Amplifier with Auxiliary Jack Page 4 of 15 Figure 3. Block Diagram Interfaces The assembly connects to the system cable, an external loudspeaker, and any auxiliary devices via the 16- pin connector, P1, located on the speaker amplifier/power supply PCBA. Connector J2, on the bottom of the speaker amplifier/power supply PCBA connects to optional devices such as the SmartSeries RTU (remote terminal unit) installed in specially designed enclosures. -
Page 7: Operation
Pub. 42004-719L2C ® 701-904 SmartSeries Handset/Speaker Amplifier with Auxiliary Jack Page 5 of 15 This is required when these amplifiers are installed in a SmartSeries enclosure. : Do not damage the protruding latch wings of connector J2 located on the bottom edge of the amplifier during installation. -
Page 8: Party-Line Conversation
Pub. 42004-719L2C ® 701-904 SmartSeries Handset/Speaker Amplifier with Auxiliary Jack Page 6 of 15 Party-Line Conversation To conduct a party-line conversation perform the following steps: 1. For a multi-party enclosure select the appropriate party line. 2. Lift the handset from the cradle. 3. -
Page 9: Optional Features
Pub. 42004-719L2C ® 701-904 SmartSeries Handset/Speaker Amplifier with Auxiliary Jack Page 7 of 15 Optional Features The following features are available as options to the standard configuration of a station used in an ADVANCE system and installed in a standard SmartSeries or a custom enclosure. These features can be configured. -
Page 10: External Adjustments
Pub. 42004-719L2C ® 701-904 SmartSeries Handset/Speaker Amplifier with Auxiliary Jack Page 8 of 15 External Adjustments The user level adjustment control is located on the front panel behind the GAI-Tronics nameplate (see Figure 1). 1. Loosen the two screws on the GAI-Tronics nameplate and rotate it counterclockwise to access the adjustment hole. -
Page 11: Vlc (Volume Level Control) Adjustment (Advance Systems Only)
Pub. 42004-719L2C ® 701-904 SmartSeries Handset/Speaker Amplifier with Auxiliary Jack Page 9 of 15 the tone is activated. Use the test tone as a reference to adjust the speaker amplifier offset level to the desired volume. 5. Turn the adjustment potentiometer counterclockwise to the desired output level. The test tone automatically shuts off 5 seconds after the last adjustment. -
Page 12: Handset Receiver And Sidetone Volume Adjustments
Pub. 42004-719L2C ® 701-904 SmartSeries Handset/Speaker Amplifier with Auxiliary Jack Page 10 of 15 Handset Receiver and Sidetone Volume Adjustments The handset receiver volume and sidetone volume levels are set internally. : The following level adjustments are not typically required. It is necessary to remove the assembly from its enclosure and make a temporary connection between the assembly and the enclosure to make an adjustment (see Figure 2 for the reference numbers and locations of the adjustment controls). -
Page 13: Troubleshooting
Pub. 42004-719L2C ® 701-904 SmartSeries Handset/Speaker Amplifier with Auxiliary Jack Page 11 of 15 Troubleshooting The following table lists some hints to aid technicians in troubleshooting: Problem Possible Solution Any problem with Remove the assembly from the enclosure and examine it carefully for station performance obvious faults such as unconnected plugs, loose connections where the wires from the handset and hookswitch connect to the Handset/FSK/P PCBA, and... -
Page 14: How To Diagnose Assembly Faults
Pub. 42004-719L2C ® 701-904 SmartSeries Handset/Speaker Amplifier with Auxiliary Jack Page 12 of 15 How to Diagnose Assembly Faults When the assembly is in an ADVANCE system that includes a vacuum fluorescent display (VFD), faults may be automatically detected, transmitted to the MCU in data messages, and displayed or printed. Fault messages and possible solutions for their causes are described in the table below. - Page 15 Pub. 42004-719L2C ® 701-904 SmartSeries Handset/Speaker Amplifier with Auxiliary Jack Page 13 of 15 Fault Message Cause and Effect Possible Solution • Verify that the speaker Supervised Audio Cause—The station is detecting no ambient wire is connected and noise at the speaker or is detecting an ambient Path intact.
-
Page 16: Replacement Parts
Pub. 42004-719L2C ® 701-904 SmartSeries Handset/Speaker Amplifier with Auxiliary Jack Page 14 of 15 Replacement Parts Model No Description 10112-201 Handset Assembly, black 46101-012 Amplifier Enclosure Mounting Hardware 13204-001-00 Dynamic Transmitter and Cap, black 12523-001 GAI-Tronics Nameplate Kit 69383-003 Handset/FSK/P/Aux PCBA 69382-001 Speaker Amp/Power Supply PCBA 13204-001-002... -
Page 17: Environmental
Pub. 42004-719L2C ® 701-904 SmartSeries Handset/Speaker Amplifier with Auxiliary Jack Page 15 of 15 Environmental Temperature range ......... −22 °F to +158 °F (−30 °C to +70 °C), operating and storage Humidity ........................95%, non-condensing Approvals NRTL Listed for USA and Canada ............Class I, Div. 2, Groups A, B, C, D; when used with listed GAI-Tronics 702 and 703 series enclosures ........ -
Page 18: Return Policy
Warranty Equipment. GAI-Tronics warrants for a period of one (1) year from the date of shipment, that any GAI-Tronics equipment supplied hereunder shall be free of defects in material and workmanship, shall comply with the then-current product specifications and product literature, and if applicable, shall be fit for the purpose specified in the agreed upon quotation or proposal document.
