Technical Specifications

NS Series Flush-Mount Network Sensors
Supply Voltage 9.8 to 16.5 VDC; 15 VDC Nominal (From SA Bus)
Current 12 mA Maximum (Non-transmitting) per Flush-Mount Network Sensor
Consumption
Terminations Screw Terminal Block
Note: Wire leads are field supplied and are not tinned.
Sensor DIP Switch Set from 200 to 203; Factory Set at 203
Addressing
Wire Size 18 to 22 AWG (1.0 to 0.6 mm Diameter); 22 AWG (0.6 mm Diameter) Recommended;
10 ft (304.8 cm) Wiring Lead Included with the Unit
Communication Auto-Detect: 9.6k, 19.2k, 38.4k, or 76.8k bps
Rate
Temperature 32.0°F/0.0°C to 104.0°F/40.0°C
Measurement
Range
Temperature Local 1k ohm Platinum Resistance Temperature Detector (RTD); Class A per IEC 60751
Sensor Type
Temperature NS Series Flush Mount Network Sensor: ±1.0F°/±0.6C°
Accuracy
Temperature Element Only: 0.35F° at 70°F (0.19C° at 21°C)
Ambient Operating: 32 to 104°F (0 to 40°C); 10 to 90% RH, Noncondensing; 85°F (29°C) Maximum Dew Point
Conditions
Storage: -40 to 158°F (-40 to 70°C); 5 to 95% RH, Noncondensing
Compliance BACnet International:
BACnet Testing Laboratories™ (BTL) 135-2004 Listed BACnet Smart Sensor (B-SS)
United States:
UL Listed, File E107041, CCN PAZX, Under UL 916, Energy Management Equipment;
FCC Compliant to CFR 47, Part 15, Subpart B, Class A
Canada:
UL Listed, File E107041, CCN PAZX7, Under CAN/CSA C22.2 No. 205, Signal Equipment;
Industry Canada, ICES-003
Europe:
CE Mark – Johnson Controls, Inc. declares that this product is in compliance with the essential
requirements and other relevant provisions of the EMC Directive.
Australia and New Zealand:
RCM Mark, Australia/NZ Emissions Compliant
Shipping Weight 0.25 lb (0.11 kg)
The performance specifications are nominal and conform to acceptable industry standards. For application at conditions beyond these
specifications, consult the local Johnson Controls office. Johnson Controls, Inc. shall not be liable for damage resulting from misapplication or
misuse of its products.
