Johnson Controls NS Series Installation Instructions

NS Series Flush-Mount Network Sensors

Installation Instructions

NS-FTN7003-0, NS-FTN7003-2
Applications
The NS Series Flush-Mount Network Sensors are
wall-mounted temperature sensors designed for use
with Johnson Controls® digital controllers in Heating,
Ventilating, and Air Conditioning (HVAC) systems.
Models in this series monitor the space temperature,
typically in a room, and transmit this data to a Field
Equipment Controller (FEC), a Variable Air Volume
(VAV) Modular Assembly (VMA) 16, or a Network
Control Engine (NCE) on the Sensor Actuator (SA)
Bus. The wires connecting the network sensor to the
controller must be terminated using the screw terminal
block on the flush-mount sensor module.
The wall sensors include DIP switches for applications
requiring multiple flush-mount sensors, each with a
unique DIP switch address.
IMPORTANT: The NS Series Flush-Mount Network
Sensor is intended to provide an input to equipment
under normal operating conditions. Where failure or
malfunction of the flush-mount sensor could lead to
personal injury or property damage to the controlled
equipment or other property, additional precautions
must be designed into the control system.
Incorporate and maintain other devices, such as
supervisory or alarm systems or safety or limit
controls, intended to warn of or protect against
failure or malfunction of the flush-mount sensor.
IMPORTANT : Le NS Series Flush-Mount Network
Sensor est destiné à transmettre des données
entrantes à un équipement dans des conditions
normales de fonctionnement. Lorsqu'une défaillance
ou un dysfonctionnement du flush-mount sensor
risque de provoquer des blessures ou
d'endommager l'équipement contrôlé ou un autre
équipement, la conception du système de contrôle
doit intégrer des dispositifs de protection
supplémentaires. Veiller dans ce cas à intégrer de
façon permanente d'autres dispositifs, tels que des
systèmes de supervision ou d'alarme, ou des
dispositifs de sécurité ou de limitation, ayant une
fonction d'avertissement ou de protection en cas de
défaillance ou de dysfonctionnement du flush-mount
sensor.
