Johnson Controls NS8000 Series Installation Instructions Manual

NS8000 Series
Vertical Wallbox-Mounted or Surface-Mounted NS Series Network Sensors
Installation Instructions
Important (USA, Canada)
The NS Series Network Sensor is intended to provide an input to equipment under normal operating conditions. Where failure or
malfunction of the network sensor could lead to personal injury or property damage to the controlled equipment or other property,
additional precautions must be designed into the control system. Incorporate and maintain other devices, such as supervisory or
alarm systems or safety or limit controls, intended to warn of or protect against failure or malfunction of the network sensor.
Le NS Series Network Sensor est destiné à transmettre des données entrantes à un équipement dans des conditions normales
de fonctionnement. Lorsqu'une défaillance ou un dysfonctionnement du network sensor risque de provoquer des blessures ou
d'endommager l'équipement contrôlé ou un autre équipement, la conception du système de contrôle doit intégrer des dispositifs
de protection supplémentaires. Veiller dans ce cas à intégrer de façon permanente d'autres dispositifs, tels que des systèmes de
supervision ou d'alarme, ou des dispositifs de sécurité ou de limitation, ayant une fonction d'avertissement ou de protection en
cas de défaillance ou de dysfonctionnement du network sensor.
Software terms
Use of the software that is in (or constitutes) this product or access to the cloud or hosted services applicable to this product,
if any, is subject to applicable terms set forth at www.johnsoncontrols.com/techterms. Your use of this product constitutes an
agreement to such terms. If you do not agree to be bound by such terms, you may return the unused product
to your place of purchase.
North American Emissions Compliance
United States
This equipment has been tested and found to comply with the limits for a Class B digital device pursuant to Part 15 of the FCC
Rules. These limits are designed to provide reasonable protection against harmful interference when this equipment is operated
in a commercial environment. This equipment generates, uses, and can radiate radio frequency energy and, if not installed
and used in accordance with the instruction manual, may cause harmful interference to radio communications. Operation of
this equipment in a residential area may cause harmful interference, in which case the users will be required to correct the
interference at their own expense.
Canada
This Class (A) digital apparatus meets all the requirements of the Canadian Interference-Causing Equipment Regulations.
Cet appareil numérique de la Classe (A) respecte toutes les exigences du Règlement sur le matériel brouilleur du Canada.
Mounting
Note: • The NS Series Network Sensor can be surface mounted or wallbox mounted. For wallbox-mounted installations,
mount the NS Series Network Sensor on a vertically roughed-in wallbox only. Do not attempt to mount the sensor on a
horizontally roughed-in wallbox.
• Johnson Controls does not supply the required hardware for mounting.
*241125600007Rev-*
1
Part No. 24-11256-00007, Rev. —
Issue Date February 2019
Part No. 24-11256-00007, Rev. —
