MAINTENANCE

To keep your vacuum's
suction power optimal,
follow these instructions.
Make sure unit is off and
cord is unplugged.
IMPORTANT:
DO NOT use soap when

cleaning the filters.

RECOMMENDED
FILTER CLEANING
SCHEDULE:
Pre-Motor Filter Kit
(Foam & Felt)
XFF600
Clean every 3 months.
Post-Motor Filter
(HEPA)
XHF600
Clean once a year.

EMPTYING THE DUST CUP

1
Lift the dust cup off
the pod by pulling up
on the release latches
on the sides of the
Dust Cup handle.
13 1-800-798-7398
STEP 1 STEP 2
2 Hold dust cup over
a trash bin and press
the bottom Dust Cup
Release latch.
STEP 3
CLEANING THE FILTERS
3 or Allergy Sufferers:
1 Pre-Motor
Wrap a trash bag
(foam and felt):
around the Dust Cup
With the dust cup
leaving space at the
removed, take out the
bottom for the door to
foam and felt filters,
swing open.
and rinse with water.
Tap loose dirt off
filters between washes
as needed. Allow filters
to air-dry completely
before reinstalling.
Pre-Motor
Pre-Motor
Foam Filter
Felt Filter
(Felt Side Up)
Filter Filter Frame
Frame
(Underside)
Post Motor
Filter
2 Post-Motor (HEPA):
To access the HEPA
filter, reach under the
grill, pull the latch
forward, and pull the
grill away from the
vacuum. Remove
and rinse the HEPA
filter with water only.
Allow filter to air-dry
completely before
reinstalling.
s h a r kc l e a n . c o m 14
