MAINTENANCE
NOTE: Remove
dust cup, wand, and
floor nozzle and
check all Dust Cup
intake openings.
NOTE: Remove
the handle from the
wand and check
for blockages.
1 Dust Cup Air Duct:
• Stand vacuum into upright
position.
• Remove Dust Cup
Assembly and empty
Dust Cup if necessary.
• Disconnect the
Super Stretch Hose.
• Check Air Duct behind
Dust Cup for clogs;
clear before replacing
Dust Cup Assembly.
15 1-800-798-7398
1 1
4 4
3 3
2 Intake Opening behind
the Brushroll:
• Lay the vacuum flat to
expose brushroll.
• Check opening behind the
brushroll for clogs.
• Clear the opening.
• Clear the brushroll; use
scissors to carefully cut
away threads, hair or
other debris that might be
trapped in the bristles.
1
3 Floor Power Nozzle Hose Connector:
• Lay vacuum flat.
• Remove Nozzle Hose and check for clogs.
• Push the Hose Connector back onto the
Floor Power Nozzle.
4 Hose:
• Stand vacuum upright.
• Remove hose from both the unit and
Cleaning Wand ends.
• Inspect both ends and the length of the
hose for clogs
• Return the hose to the unit
4
To reset the Motor Thermostat:
Move the Power Button to the
"O" – Off position.
Unplug the vacuum.
Check for clogged hose or filter; unclog hose
and replace filter.
Wait 45 minutes for vacuum to cool; then plug
in the vacuum.
Turn the Power Switch to the
"I" – On position to start the vacuum.
s h a r kc l e a n . c o m 16
