Using Your Vacuum - Shark Navigator SWIVEL PLUS NV40 Series Instructions Manual

USING YOUR VACUUM

WHAT DOES THE
BRUSHROLL INDICATOR
LIGHT MEAN?
Solid Green
The brushroll is on and
working as it should.
Solid Red
There is a jam in the
brushroll area. Turn your
vacuum off and remove
the blockage.
No Light
The vacuum is off. To turn
it on, press the POWER
button and put in either
carpet or hard floor mode.
1 Plug power cord into outlet. Place foot on floor
nozzle and tilt handle back.
9 1-800-798-7398
STEP 1
= Carpet Cleaning
= Bare Floor/Tool
= OFF
BRUSHROLL ON/OFF:
1 Press the ON/OFF switch at the top of the
canister to the I position to vacuum bare
floors (straight suction only) or use
Lift-Away® mode. To vacuum carpets and
rugs, set the switch to the II position to
engage the motorized brushroll.
STEP 2
2 Press the floor nozzle down with your foot
and tilt the handle back towards you to
engage the brushroll.
s h a r kc l e a n . c o m 10
