- Page 1 AIR NAIL GUN MODEL NO: CNG1C PART NO: 3110390 OPERATING & MAINTENANCE INSTRUCTIONS ORIGINAL INSTRUCTIONS GC1219 - ISS 2...
-
Page 2: Specifications
101 dB(A) Please note that the details and specifications contained herein are correct at the time of going to print. However CLARKE International reserve the right to change specifications at any time without prior notice. Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com... -
Page 3: General Safety Rules
GENERAL SAFETY RULES CAUTION: FAILURE TO FOLLOW THESE PRECAUTIONS COULD RESULT IN PERSONAL INJURY, AND/OR DAMAGE TO PROPERTY. THE WORK ENVIRONMENT 1. ALWAYS keep the work area clean and tidy. 2. ALWAYS dress appropriately - Do not wear loose clothing or jewellery. Tie long hair out of the way. -
Page 4: Limitations Of Use
• The tool is not in use. • The tool will be left unattended. • Moving to another work area. 15. NEVER use the tool if it is defective or operating abnormally. 16. Avoid damaging the tool by applying excessive force. 17. -
Page 5: Compressed Air Requirements
COMPRESSED AIR REQUIREMENTS WARNING: COMPRESSED AIR CAN BE DANGEROUS. ENSURE THAT YOU ARE FAMILIAR WITH ALL PRECAUTIONS RELATING TO THE USE OF COMPRESSORS AND COMPRESSED AIR SUPPLY. A typical air line layout is shown below. If an automatic in-line filter/regulator is used it will keep the tool in good condition, but should be regularly checked and topped up with oil. - Page 6 When opening the carton for the first time, check that all the items are present and in good condition. Any damage or deficiency should be reported to your CLARKE dealer immediately. Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com...
-
Page 7: Before Use
1. Remove the plastic blanking plug from the air inlet connection. 2. Pour 2-3 drops of CLARKE airline oil into the inlet port. This should be done regardless of whether or not a lubricated air supply is to be used. -
Page 8: Assembly And Operation
If the tool is to be stored, or is idle for longer than 24 hours, run a few drops of CLARKE air line oil into the air inlet, and run the tool for 5 seconds in order to lubricate the internal parts. -
Page 9: Troubleshooting
Tool will not shut off. 1. Throttle O-rings 1. Return to CLARKE dealer damaged or ill-fitting for repair. in seat. Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com... -
Page 10: Maintenance
3. You may prefer to take the tool to your CLARKE dealer if internal maintenance is required. Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com... - Page 11 (5 to 50 metres) etc. Contact your CLARKE dealer for further information or CLARKE International Service Department. CLARKE Air Line Oil (part no. 3050825) is available from your CLARKE dealer. CONSUMABLES Nails - 18 Gauge - 1.25mm crown.
-
Page 12: Parts List
PARTS LIST Hex Socket Head Bolt Bearing plate Deflector Spring Pin 2.5 x 16 Air Deflector Bracket Bolt M5x50 Pusher spring Spring Washer Safety element Cylinder Head Spacer O-Ring 3.7x2.4 Pin 4 x 20 Sealing Washer Clasp Compression Spring Quick release handle Piston Nose cover O-Ring 31.2x2.5... -
Page 13: Component Parts Diagram
COMPONENT PARTS DIAGRAM Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com... -
Page 14: Declaration Of Conformity
DECLARATION OF CONFORMITY Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com... - Page 15 GUARANTEE This product is guaranteed against faulty manufacture for a period of 12 months from the date of purchase. Please keep your receipt which will be required as proof of purchase. This guarantee is invalid if the product is found to have been abused or tampered with in any way, or not used for the purpose for which it was intended.
