Summary of Contents for Clarke CSN-1D
- Page 1 AIR STAPLE/NAIL GUN MODEL NO: CSN-1D PART NO: 3110387 OPERATION & MAINTENANCE INSTRUCTIONS LS0113...
- Page 2 Faulty goods should be returned to their place of purchase, no product can be returned to us without prior permission. This guarantee does not effect your statutory rights. CONSUMABLES The following Consumables are available from your local Clarke Dealer NAILS - 1.25MM CROWN (18 GAUGE) STAPLES - 5.5MM CROWN Length...
-
Page 3: Safety Warnings
SAFETY WARNINGS SAFETY OF THE STAPLE/NAIL GUN 1. Check prior to use that the safety and triggering mechanism is functioning properly and that all nuts and bolts are tight. 2. Do not carry out any modifications to the staple/nail gun. 3. -
Page 4: Safety Symbols
SAFETY SYMBOLS Read manual Wear ear defenders before use Wear suitable eye Do not use on protection scaffolding or ladders May only be used with an effective safety yoke PREPARING THE STAPLE/NAIL GUN FOR USE CAUTION: READ AND OBSERVE THESE OPERATING INSTRUCTION BEFORE USING THE STAPLE/NAIL GUN. -
Page 5: Filling The Magazine
RECOMMENDED CONNECTION CONFIGURATION TIPS • Drain the compressor air tank daily. Water in the air line will damage the nail/staple gun and will invalidate your warranty. • Clean air inlet filter on the staple/nail gun weekly. • Line pressure should be increased to compensate for unusually long air hoses (over 8m). -
Page 6: Handling The Staple/Nail Gun
HANDLING THE STAPLE/NAIL GUN ay attention to the SAFETY WARNINGS in these operating instructions. 2. Set the operating pressure to between 60-100psi, depending upon the size of nail used and type of material being worked. 3. Having checked that the staple/nail gun is functioning correctly, press the staple/nail gun against the work piece at a right angle and pull the trigger. -
Page 7: Maintenance
3. If an air system oiler is not being used, lubricate the staple/nail gun daily with a few drops of air line oil, dripped into the air inlet before use. Clarke Air Line Oil is available from your CLARKE dealer part no. 3050825. -
Page 8: Maintenance Notes
CLARKE dealer. • The use of parts other than CLARKE replacement parts may result in safely hazards, decreased tool performance and will invalidate your warranty. -
Page 9: Declaration Of Conformity
DECLARATION OF CONFORMITY Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com... -
Page 10: Exploded Diagram
EXPLODED DIAGRAM Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com... -
Page 11: Spare Parts List
SPARE PARTS LIST Description Part No Description Part No Hex. Skt Hd Screw HTCSN1D01 Compression Spring HTCSN1D42 Compression Spring HTCSN1D02 Roll Pin 2.5x16 HTCSN1D43 Air Deflector HTCSN1D03 Safety Plate HTCSN1D44 Cap Screw M5x20 HTCSN1D04 Trigger HTCSN1D45 Lock Washer 5mm HTCSN1D05 Cap Screw M4x10 HTCSN1D46 Cylinder Cover...
