3. Configuration

This chapter describes the configuration procedure.
3.1. NMU and Devices (Master & EP) Configuration
The EoC 20-01 Master is used to manage all connected EoC 20-2 Endpoints.
Each EP is identified by its built-in EoC MAC address. The EoC MAC exists only in EoC (coax) domain, and is
unaware for any EP end-user in Ethernet domain.
System manager needs NMU IP address and NMU Ethernet MAC address to access EOC 20-01. Each EOC 20-
01 device should be stamped with both NMU Ethernet MAC and EoC Master MAC for identification.

3.1.1. Firmware/EoC/WiFi Driver Files

EOC 20-01 flash ROM is capable of storing the following files:
•
System bootcode (NMU bootloader)
•
System firmware (NMU firmware)
•
EoC Master driver (resides at EOC 20-01)
•
EoC EP driver
•
EP WiFi driver
Upgrade NMU firmware
'Upload' the new firmware file onto EOC 20-01 Upload Area, it will take effect after EOC 20-01 reboot.
