1.4. LED Indicators:

Label
Power
LAN1
LAN2
Link/Act
Quality
Diagnosis
Not labeled
SFP
2020-01-08 | Technical improvements, changes in design, printing- and other errors expected.
ON
Powered by DC12V
Green = LAN1 port is active
Orange = LAN1 = 1Gbps.
Green = LAN2 RJ-45 port is active
Orange = LAN2 RJ-45 links at 1Gbps.
Diminished if LAN2 links at SFP
Data+RF port is active
Green = high EoC throughput
Orange = medium EoC throughput
Red = low EoC throughput
EoC 20-01 is diagnosing EoC
connection toward/from EP
Forcing to default settings via reset
button.
SFP port is active
Status
Flashing
N/A
Data traffic active
Data traffic active
Data traffic active
Bootloader mode
