- Page 1 STREET WRAP™ INSTALLATION GUIDE P-LED.com 325.227.4577 warranty...
-
Page 2: Table Of Contents
Note: If job measurements do not correspond to provided drawing, call Principal LED immediately at 325-227-4577. Remember: No more than 90 modules per 60W Power Supply. -
Page 3: Street Wrap Mounting Bracket Layout
182.52 3.38 Install mounting brackets. Spacing will be no greater than 17.75”. Length for Standard, Mix-n-Match and Specialty Street Wrap™ is 106.5”, RGB is 104”. Use pre-drilled wire hole mounting brackets at transformer locations. Note: This is correct bracket orientation. -
Page 4: Installing Street Wrap Into Mounting Brackets
Insert the top edge into the top bracket latch. Push the track housing in and roll top track housing into mounting bracket bottom point. See Figure 1. Bring Street Wrap™ sections close together by pushing sections together until LED modules come together, but leave a 3/16" approximate expansion gap between plastic track sections. -
Page 5: Custom Cut To Fit End Of Runs & Corners
Remove LEDs before cutting track by sliding one or two modules out. Measure, mark and cut Street Wrap™ to required length. Use a fine blade. Add drain holes in the center, of the cut piece of track, before reinstalling the LED. -
Page 6: Mounting Street Wrap On An Incline
MOUNTING STREET WRAP™ ON AN INCLINE When mounting Street Wrap™ on an incline or vertically, two things must be prevented. First the Street Wrap™ must be kept from sliding down, while still allowing for expansion/contraction with temperature changes. Second, water must be sealed out since it will run down the top of the Street Wrap™. -
Page 7: Frame Border Installation
SEC. 6 FRAME BORDER INSTALLATION EXAMPLE: 104” x 196” 3 Brackets Per Street Wrap 3" 3" Mounting Cable Hole Screw Mounting Bracket End caps Always ensure attach with drain holes are Low Voltage Cable Silicone. on bottom side. Angle Brackets... - Page 8 Transformers Fascia Insert low voltage wire into the hole and connect to LED. Fill hole with silicone sealant. LEDs ARE to LEDs 12VDC ONLY! Note: Three 106.5” Street Wrap™ Border per 60W Power Cable 12VDC Strain Relief Power Supply. Fitting...
-
Page 9: Testing Each Section
TESTING EACH SECTION SEC. 8 IMPORTANT: DO NOT SKIP THIS STEP. ALWAYS CHECK ALL LED LIGHTS BEFORE CONTINUING. Using the installed trasformers, supply power to the LED light chains by connecting a temporary 120V connection to the black and white wires on the transformer to power the LED lights. REMEMBER: BLACK AND WHITE WIRES ARE FOR 120V POWER IN, RED AND BLACK ARE FOR LOW-VOLTAGE POWER OUT. - Page 10 P-LED.com 325.227.4577 REV20190806...
-
Page 11: How To Wire Rgb Street Wrap
HOW TO WIRE RGB STREET WRAP SEC. 3 POWER AMPLIFIER FIGURE NOTE: For RGB, use a maximum of 84 mods (three 104” units)/60W PS). Watch our RGB installation and troubleshooting videos at YouTube.com/PLEDSanAngelo: How to Wire in the 60W and 120W into the T35A Control System with Amplifiers...
