3.19 Programmable settings

Compressor/motor
Set-point 1 and 2, Workplace Full-Feature
compressors
Indirect stop level
Direct stop level
Proportional band
Integration time
Parameters
Minimum stop time
Power recovery time
Restart delay
Communication time-out
Fan motor starts per day (air-cooled
compressors)
Protections
Compressor element outlet temperature
(shut-down warning level)
Compressor element outlet temperature
(shut-down level)
Specific protections for Full-Feature compressors:
API480496
Minimum
setting
bar(e) 4
bar 0.1
bar 0.3
% 6
sec 5
Minimum
setting
sec 5
sec 10
sec 0
sec 10
1
Minimum
setting
˚C 50
˚C 111
Factory Maximum
setting setting
6.8 12.8
0.3 1
1 1.5
10 15
6 10
Factory Maximum
setting setting
5 30
10 3600
0 1200
30 60
240 240
Factory Maximum
setting setting
110 119
120 120
71
