Fault Fault
code description
0x5114 Drive failure
(hardware)
0x5115 Drive failure
(hardware)
0x5401 Drive failure
(hardware)
0x5402 Drive failure
(hardware)
0x6101 Drive failure
(hardware)
0x6102 Drive failure
(hardware)
0x6103 Drive failure
(hardware)
0x6104 Drive failure
(hardware)
0x6105 Drive failure
(hardware)
0x6106 Drive failure
(hardware)
0x6107 Drive failure
(hardware)
0x6108 Drive failure
(hardware)
0x6109 Drive failure
(hardware)
0x610A Drive failure
(hardware)
0x610B Drive failure
(hardware)
0x610C Drive failure
(hardware)
0x610D Drive failure
(hardware)
0x610E Drive failure
(hardware)
0x610F Drive failure
(hardware)
0x6110 Drive failure
(hardware)
112
Cause
Internal power supply tripped
Internal power supply tripped
General fault detected in power
section
General fault detected in power
section
Eeprom read failed
Time-out communication
Failed temperature reading of power
board
Time-out communication at
initialization
General fault detected
Internal checksum error detected
Internal communication timeout
Internal checksum error detected
Internal communication timeout
Internal communication timeout
Internal checksum error detected
Internal communication overload
Internal control overload
CAN communication time-out
Firmware not compatible
Not able to identify power board
Not able to identify IGBT module
Power board not compatible with IGBT
modules
Instruction book
Actions
Try to reset the error.
If error returns, contact Atlas Copco.
Check CAN-cable connection
between Elektronikon and converter.
Check position of the CAN
termination switch at both sides of the
CAN cable. Both should be OFF.
Try to reset the error.
If error returns, contact Atlas Copco.
