Topcon DRI OCT Triton Quick Reference Manual page 7

E&
Position the Patient.
3. Once the Patient is
Place the Patient's chin on the chinrest. Keep their chin and forehead stable.
fixated correctly, you can
Be sure to adjust the chinrest height to align the eye marker and the
adjust the OCT scan to
corner of the eye.
ensure it is appearing
centrally in the box by
moving this Z Tab.
2. Patient Fixation
Use the arrow keys on the
base of the machine to
move the Patient's Fixation
in the direction required.
Choose Scan Type.
4
Once the Patient is reminded to fixate on the target and not to blink, press the trigger on the
joystick to capture.
5
Check OCT quality after capture.
Immediately after capture,
the Shadowgram will appear
to ensure there are no fixation
losses or blinks.
You may need to use the
[Small Pupil] setting for Patients
with small pupils or turn the
require the fundus photo.
6
Images will then automatically be saved for you to view in the Imagenet 6 software.
7
Topcon (Great Britain) Medical Limited 7 Topcon (Great Britain) Medical Limited
Capturing OCT
Adjust the Patient's height using the
and [Down]
the joystick on the machine.
Once Scan Type is selected, the machine
will automatically go into capture mode.
[Small Pupil] button
| DRI OCT Triton | Quick Reference Guide | | DRI OCT Triton | Quick Reference Guide |
[Up]
chinrest buttons found next to
[On]/[Off]
If poor quality, press
and repeat capture process.
Capturing OCT
1. If the Patient Fixation
needs adjusting, this
little blue cross is the
green internal fixation
cross.
[Delete]
Capturing OCT
