Instrument and control functions
Multi-function display
4
1
1. Multi-function display
The multi-function display is equipped
with the following:
an odometer
two tripmeters (which show the
distance traveled since they were
last set to zero)
a fuel reserve tripmeter (which
shows the distance traveled since
the last segment of the fuel meter
started flashing)
an instantaneous fuel consumption
display
an average fuel
display
an oil change tripmeter
a V-belt replacement tripmeter
an oil change indicator
a V-belt replacement indicator
an error code display
Push the "SELECT" button to switch
the display between the odometer
mode "ODO", tripmeter modes "TRIP1"
and "TRIP 2", oil change tripmeter
mode "OIL TRIP", V-belt replacement
tripmeter
instantaneous fuel consumption mode
"F/ECO" (km/L or L/100 km) and
average fuel
"AVEF/ECO" (km/L or L/100 km) in the
following order:
ODO TRIP 1
V-BELT TRIP
F/ECO ODO
If the fuel level warning indicator " "
and last segment of the fuel meter start
flashing, the display automatically
changes to the fuel reserve tripmeter
mode "TRIP F" and starts counting the
distance traveled from that point. In
consumption
that case, push the "SELECT" button
to switch the display between the vari-
ous tripmeter, odometer, oil change
tripmeter, V-belt replacement tripme-
mode "V-BELT TRIP",
consumption mode
TRIP 2 OIL TRIP
F/ECO AVE
4-6
ter, instantaneous fuel consumption
and average fuel consumption modes
in the following order:
TRIP F TRIP 1 TRIP 2
TRIP V-BELT TRIP
AVEF/ECO ODO TRIP F
To reset a tripmeter, select it by
pushing the "SELECT" button, and
then push the "RESET" button for at
least one second.
TIP
If you do not reset the fuel reserve
tripmeter manually, it will reset
automatically and disappear from
the display after refueling and
traveling 5 km (3 mi).
If you do not reset tripmeters 1and 2,
they will reset to 0 and continue
counting after 9999.9 has been
reached.
The odometer will lock at 999999
and cannot be reset.
