Read this manual carefully before operating this vehicle.
OWNER'S MANUAL
GPD150-A
2DP-F8199-E0

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the NMAX GPD150-A and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Yamaha NMAX GPD150-A

Summary of Contents for Yamaha NMAX GPD150-A

  • Page 1 Read this manual carefully before operating this vehicle. OWNER’S MANUAL GPD150-A 2DP-F8199-E0...
  • Page 2 EAU46091 Read this manual carefully before operating this vehicle. This manual should stay with this vehicle if it is sold.
  • Page 3 EAU10114 Welcome to the Yamaha world of motorcycling! As the owner of the GPD150-A, you are benefiting from Yamaha’s vast experience and newest technology regarding the design and manufacture of high-quality products, which have earned Yamaha a reputation for dependability.
  • Page 4 Important manual information EAU10134 Particularly important information is distinguished in this manual by the following notations: This is the safety alert symbol. It is used to alert you to potential personal injury hazards. Obey all safety messages that follow this symbol to avoid possible injury or death.
  • Page 5 Important manual information EAUN0430 GPD150-A OWNER’S MANUAL ©2015 PT Yamaha Indonesia Motor Manufacturing 1st edition, September 2015 All rights reserved. Any reprinting or unauthorized use without the written permission of PT Yamaha Indonesia Motor Manufac- turing is expressly prohibited. Printed in Indonesia.

  • Page 6: Table Of Contents

    Table of contents Location of important labels... 1-1 For your safety – pre-operation Checking the throttle grip checks ..........5-1 free play........7-17 Safety information......2-1 Valve clearance......7-17 Further safe-riding points ....2-5 Operation and important riding Tires ..........7-18 points ..........6-1 Cast wheels ........
  • Page 7 Table of contents Replacing a front turn signal light bulb ........7-33 Replacing a rear turn signal light bulb ........7-33 Troubleshooting ......7-35 Troubleshooting charts ....7-36 Scooter care and storage ....8-1 Matte color caution ......8-1 Care ..........8-1 Storage ..........8-3 Specifications........9-1 Consumer information ....10-1 Identification numbers....10-1 Index ..........11-1...

  • Page 8: Location Of Important Labels

    Read and understand all of the labels on your vehicle. They contain important information for safe and proper operation of your vehicle. Never remove any labels from your vehicle. If a label becomes difficult to read or comes off, a replacement label is available from your Yamaha dealer.
  • Page 9 Location of important labels WARNING Before you operate 100kPa=1bar kPa, psi kPa, psi this vehicle, read 150, 22 250, 36 this owner’s manual. LOAD LIMIT 150, 22 250, 36 Front Box : 1,5 kg 2DP-F1668-00 Seat Box : 5 kg 2DP-F1568-20...

  • Page 10: Safety Information

    Safety information  Never operate a scooter without EAU1026B conspicuous appears to be very proper training or instruction. Take effective in reducing the chance of training course. Beginners this type of accident. Be a Responsible Owner should receive training from a cer- Therefore: As the vehicle’s owner, you are re- tified instructor.
  • Page 11 Safety information  Many accidents involve inexperi- • Always signal before turning or Protective Apparel enced operators. In fact, many op- changing lanes. Make sure that The majority of fatalities from scooter erators who have been involved in other motorists can see you. accidents are the result of head inju- ...
  • Page 12 Safety information  Do not run engine outdoors where  Cargo and accessory weight Avoid Carbon Monoxide Poisoning All engine exhaust contains carbon engine exhaust can be drawn into should be kept as low and close to monoxide, a deadly gas. Breathing a building through openings such the scooter as possible.
  • Page 13 Yamaha accessories, which are avail- characteristics can put you and others effects. Wind may attempt to lift able only from a Yamaha dealer, have at greater risk of serious injury or the scooter, or the scooter may been designed, tested, and approved death.

  • Page 14: Further Safe-Riding Points

    Safety information Aftermarket Tires and Rims cation for the straps carefully so EAU57600 Further safe-riding points The tires and rims that came with your the straps will not rub against  Be sure to signal clearly when scooter were designed to match the painted surfaces during transport.
  • Page 15 Safety information  Always wear a helmet, gloves, trousers (tapered around the cuff and ankle so they do not flap), and a brightly colored jacket.  Do not carry too much luggage on the scooter. An overloaded scoot- er is unstable. Use a strong cord to secure any luggage to the carri- er (if equipped).

  • Page 16: Description

    Description EAU10411 Left view 1. Front storage compartment (page 4-15) 9. Engine oil drain bolt B (page 7-10) 2. Fuel tank cap (page 4-11) 10.V-belt case air filter element (page 7-15) 3. Owner’s tool kit (page 7-1) 4. Rear storage compartment (page 4-15) 5.

  • Page 17: Right View

    Description EAU10421 Right view 1. Tail/brake light (page 7-30) 2. Battery (page 7-26) 3. Fuse box (page 7-28) 4. Headlight (page 7-29) 5. Coolant reservoir (page 7-13) 6. Spark plug (page 7-8) 7. Engine oil filler cap (page 7-10)

  • Page 18: Controls And Instruments

    Description EAU10431 Controls and instruments 1. Rear brake lever (page 4-10) 9. Main switch/steering lock (page 4-1) 2. Left handlebar switches (page 4-9) 3. Rear brake fluid reservoir (page 7-21) 4. Multi-function meter unit (page 4-4) 5. Front brake fluid reservoir (page 7-21) 6.

  • Page 19: Instrument And Control Functions

    Instrument and control functions EAUN0263 EAU60600 EAU10686 Main switch/steering lock LOCK All electrical circuits are supplied with The steering is locked and all electrical power; the meter lighting, taillight and systems are off. The key can be re- auxiliary lights come on, and the en- moved.

  • Page 20: Keyhole Shutter

    Instrument and control functions EAUN0352 EAU49398 Keyhole shutter Indicator lights and warning If the steering will not lock, try turning lights the handlebars back to the right slight- To unlock the steering 1. “PUSH SHUT” button 2. Key head 1. Right turn signal indicator light “ ”...
  • Page 21 If this occurs,  comes on or flashes while riding gine overheats. If this occurs, stop the have a Yamaha dealer check the self-  does not go off after traveling at a engine immediately and allow the en- diagnosis system.

  • Page 22: Multi-Function Meter Unit

     a speedometer ble wheel lock during emergency EAU67262 Multi-function meter unit  a clock braking. Have a Yamaha dealer  a fuel meter check the brake system and electri-  an instantaneous fuel consump- cal circuits as soon as possible.
  • Page 23 “ ” flash eight times, then go Depending on the display setting se- Fuel meter off for approximately 3 seconds. If this lected for the instantaneous fuel con- occurs, have a Yamaha dealer check sumption mode “F/ECO”, the electrical circuit.
  • Page 24 Instrument and control functions  a V-belt replacement indicator Multi-function display ter, instantaneous fuel consumption  an error code display and average fuel consumption modes Push the “SELECT” button to switch in the following order: the display between the odometer TRIP F →...
  • Page 25 Instrument and control functions Instantaneous fuel consumption To switch between the average fuel mode consumption display settings, push If traveling at speeds under 10 km/h (6 the “SELECT” button for one second. mi/h), “_ _._” is displayed. To reset the average fuel consumption, push the “RESET”...
  • Page 26 Instrument and control functions The oil change indicator “OIL” will flash V-belt replacement tripmeter mode “RESET” button for three seconds. The at the initial 1000 km (600 mi), then at V-belt replacement indicator will be re- 4000 km (2500 mi) and every 4000 km set.

  • Page 27: Handlebar Switches

    If the display indicates any error codes, EAU12461 note the code number, and then have Turn signal switch “ ” a Yamaha dealer check the vehicle. To signal a right-hand turn, push this ECA11591 switch to “ ”. To signal a left-hand NOTICE turn, push this switch to “...

  • Page 28: Front Brake Lever

    EAU12902 EAU12952 EAU66680 Front brake lever Rear brake lever The Yamaha ABS (Anti-lock Brake System) features a dual electronic con- trol system, which acts on the front and rear brakes independently. Operate the brakes with ABS as you would conventional brakes. If the ABS is activated, a pulsating sensation may be felt at the brake levers.

  • Page 29: Fuel Tank Cap

    ABS is operating. How- sert the key into the lock, and then turn ever, special tools are required, so it 1/4 turn clockwise. The lock will be please consult your Yamaha deal- released and the fuel tank cap can be removed. ECA20100 1.

  • Page 30: Fuel

    Instrument and control functions EAU13213 Fuel Make sure there is sufficient gasoline in the tank. EWA10882 WARNING Gasoline and gasoline vapors are extremely flammable. To avoid fires and explosions and to reduce the risk of injury when refueling, follow 1. “ ”...

  • Page 31: Fuel Tank Overflow Hose

    Instrument and control functions ately. If gasoline spills on your skin, recommended by Yamaha because it EAU58301 Fuel tank overflow hose wash with soap and water. If gaso- can cause damage to the fuel system line spills on your clothing, change or vehicle performance problems.

  • Page 32: Catalytic Converter

    Instrument and control functions EAU13434 ECA10702 EAU60620 Catalytic converter Seat NOTICE This model is equipped with a catalytic Use only unleaded gasoline. The use converter in the exhaust system. To open the seat of leaded gasoline will cause unre- EWA10863 1.

  • Page 33: Storage Compartments

    Instrument and control functions 2. Remove the key. EAU57081 Rear storage compartment Storage compartments The rear storage compartment is locat- ed under the seat. Use this compart- Make sure that the seat is properly se- Front storage compartment ment for large items. (See page 4-14.) cured before riding.

  • Page 34: Sidestand

    EAU15306 this system regularly and have a Sidestand accumulates heat when ex- Yamaha dealer repair it if it does not The sidestand is located on the left posed to the sun and/or the en- function properly. side of the frame. Raise the sidestand...

  • Page 35: Ignition Circuit Cut-Off System

    Instrument and control functions EAUT1096 Ignition circuit cut-off system Check the operation of the sidestand switch according to the following pro- cedure. 4-17...
  • Page 36 The vehicle must be placed on the center- stand during this inspection. Put the sidestand up. • If a malfunction is noted, have a Yamaha dealer check the system before riding. Push the start switch while applying either of the brake levers. The engine will start.

  • Page 37: For Your Safety - Pre-Operation Checks

    • If necessary, add recommended coolant to specified level. 7-13 • Check cooling system for leakage. • Check operation. • If soft or spongy, have Yamaha dealer bleed hydraulic system. • Check brake pads for wear. • Replace if necessary. 7-20, 7-20, 7-21 Front brake •...
  • Page 38 • Make sure that operation is smooth. • Check throttle grip free play. Throttle grip 7-17, 7-23 • If necessary, have Yamaha dealer adjust throttle grip free play and lubricate ca- ble and grip housing. • Make sure that operation is smooth. Control cables 7-23 •...

  • Page 39: Operation And Important Riding Points

    Do not ride through deep water, oth- See page 6-3 for engine break-in in- understand, ask your Yamaha dealer. erwise the engine may be damaged. structions prior to operating the ve-...

  • Page 40: Starting Off

    Operation and important riding points The ABS warning light should EAU45093 EAU16782 Starting off Acceleration and deceleration come on when the main switch is 1. While pulling the rear brake lever turned to “ON” and then go off af- with your left hand and holding the ter traveling at a speed of 10 km/h grab bar with your right hand, (6 mi/h) or higher.

  • Page 41: Braking

    Operation and important riding points EAU16794 EAU16821 EAU16842 Braking Tips for reducing fuel con- Engine break-in sumption There is never a more important period EWA10301 WARNING in the life of your engine than the period Fuel consumption depends largely on ...

  • Page 42: Parking

    If any engine trouble should occur WARNING during the engine break-in period,  Since the engine and exhaust immediately have a Yamaha dealer system can become very hot, check the vehicle. park in a place where pedestri- ans or children are not likely to touch them and be burned.

  • Page 43: General Note

    Much can be gained from the correct use and maintenance of a motorcycle. 1. THE CUSTOMERS CAN USE THE FULLEST 2. A MOTORCYCLE CAN KEEP ITS PERFORMANCE POTENTIAL OF YAMAHA MOTORCYCLES CAPABILITY FOR A LONGER TIME Comparison of wear on engine parts (piston, piston ring, cylinder, etc.)
  • Page 44 Operation and important riding points 3. FUEL COST AND REPAIR EXPENSES CAN BE 4. A MOTORCYCLE CAN DEMAND A HIGH PRICE KEPT TO A MINIMUM WHEN IT IS TRADED IN AS A USED PRODUCT Fuel consumption With maintenance 100% Without maintenance Distance covered (km) Customer’s running cost...

  • Page 45: Periodic Maintenance And Adjustment

    If If you do not have the tools or experi- you are not familiar with vehicle ser- ence required for a particular job, have vice, have a Yamaha dealer perform a Yamaha dealer perform it for you. service.

  • Page 46: Periodic Maintenance Chart For The Emission Control System

     From 20000 km (12000 mi), repeat the maintenance intervals starting from 4000 km (2400 mi).  Items marked with an asterisk should be performed by a Yamaha dealer as they require special tools, data and tech- nical skills.

  • Page 47: General Maintenance And Lubrication Chart

    Periodic maintenance and adjustment EAU62100 General maintenance and lubrication chart ODOMETER READING ANNUAL ITEM CHECK OR MAINTENANCE JOB 1000 km 4000 km 8000 km 12000 km 16000 km CHECK (600 mi) (2400 mi) (4800 mi) (7200 mi) (9600 mi) Air filter element •...
  • Page 48 Periodic maintenance and adjustment ODOMETER READING ANNUAL ITEM CHECK OR MAINTENANCE JOB 1000 km 4000 km 8000 km 12000 km 16000 km CHECK (600 mi) (2400 mi) (4800 mi) (7200 mi) (9600 mi) • Check bearings for looseness or √ √...
  • Page 49 Periodic maintenance and adjustment ODOMETER READING ANNUAL ITEM CHECK OR MAINTENANCE JOB 1000 km 4000 km 8000 km 12000 km 16000 km CHECK (600 mi) (2400 mi) (4800 mi) (7200 mi) (9600 mi) • Check coolant level and vehicle √ √...
  • Page 50 Periodic maintenance and adjustment • The air filter element needs to be replaced more frequently when riding in unusually wet or dusty areas.  V-belt case air filter • The air filter needs more frequent service if you are riding in unusually wet or dusty areas. ...

  • Page 51: Removing And Installing Panels

    Periodic maintenance and adjustment EAU18773 2. Retract the right passenger foot- Removing and installing pan- rest to its original position. The panels shown need to be removed Panel B to perform some of the maintenance jobs described in this chapter. Refer to To remove the panel this section each time a panel needs to 1.

  • Page 52: Checking The Spark Plug

    Periodic maintenance and adjustment EAU67161 Checking the spark plug The spark plug is an important engine component, which is easy to check. Since heat and deposits will cause any spark plug to slowly erode, the spark plug should be removed and checked in accordance with the periodic main- tenance and lubrication chart.
  • Page 53 0.8–0.9 mm (0.031–0.035 in) ating improperly. Do not attempt to positioned as shown in the illustration and the spark plug lead does not con- diagnose such problems yourself. In- tact any surrounding parts. stead, have a Yamaha dealer check the vehicle.

  • Page 54: Engine Oil And Oil Strainer

    Periodic maintenance and adjustment EAU66991 Engine oil and oil strainer The engine oil should be between the The engine oil level should be checked tip of the dipstick and the maximum before each ride. In addition, the oil level mark. must be changed and the oil strainer cleaned at the intervals specified in the periodic maintenance and lubrication...
  • Page 55 Periodic maintenance and adjustment To change the engine oil and clean 6. Install engine oil drain bolt A and the oil strainer its new gasket, and then tighten 1. Start the engine, warm it up for both drain bolts to their specified several minutes, and then turn it torques.

  • Page 56: Final Transmission Oil

    In ride. If any leakage is found, have a addition, do not use oils labeled Yamaha dealer check and repair the “ENERGY CONSERVING II” or scooter. In addition, the final transmis- higher.

  • Page 57: Coolant

    Periodic maintenance and adjustment 6. Install the final transmission oil EAU20071 Coolant drain bolt and its new gasket, and The coolant level should be checked then tighten the bolt to the speci- before each ride. In addition, the cool- fied torque. ant must be changed at the intervals specified in the periodic maintenance Tightening torque:...
  • Page 58 The coolant must be changed at the in- added to the coolant, have a tervals specified in the periodic main- Yamaha dealer check the anti- tenance and lubrication chart. Have a freeze content of the coolant as Yamaha dealer change the coolant.

  • Page 59: Air Filter And V-Belt Case Air Filter Elements

    Periodic maintenance and adjustment EAU67171 be operated without the air filter Air filter and V-belt case air fil- element installed, otherwise the ter elements piston(s) and/or cylinder(s) may The air filter element should be re- become excessively worn. placed and the V-belt case air filter el- [ECA10482] ement should be cleaned at the 5.
  • Page 60 [ECA10522] 2. Remove the screws, and then pull Recommended oil: the V-belt case air filter element Yamaha foam air filter oil or other cover outward and away from the quality foam air filter oil V-belt case. 5. Insert the element into the V-belt case.

  • Page 61: Checking The Throttle Grip Free Play

    To prevent this from occurring, the valve clearance must be adjusted by a Yamaha dealer at the intervals specified in the periodic maintenance and lubrication chart. 1. Throttle grip free play The throttle grip free play should mea- sure 3.0–5.0 mm (0.12–0.20 in) at the...

  • Page 62: Tires

    EWA10512 vere injury or death from loss of Yamaha dealer immediately and have WARNING the tire replaced. control. Never overload your vehicle. Opera- ...

  • Page 63: Cast Wheels

    When a tire tread EWA10462 note the following points regarding the WARNING begins to show crosswise lines, specified wheels. have a Yamaha dealer replace The front and rear tires should be of  The wheel rims should the tire immediately.

  • Page 64: Checking The Front And Rear

    Checking the front and rear brake lever ends. If there is free play, brake lever free play brake pads have a Yamaha dealer inspect the The front and rear brake pads must be brake system. Front checked for wear at the intervals spec-...

  • Page 65: Checking The Brake Fluid Level

    EAU60680 Rear brake Checking the brake fluid level peared, have a Yamaha dealer replace Before riding, check that the brake fluid the brake pads as a set. is above the minimum level mark. Check the brake fluid level with the top...

  • Page 66: Changing The Brake Fluid

    EAU22733 Changing the brake fluid id; otherwise, the rubber seals Yamaha dealer check the cause before Have a Yamaha dealer change the may deteriorate, causing leak- further riding. brake fluid at the intervals specified in age.

  • Page 67: Checking The V-Belt

    Checking and lubricating the Checking and lubricating the The V-belt must be checked and re- cables throttle grip and cable placed by a Yamaha dealer at the inter- The operation of all control cables and The operation of the throttle grip vals specified...

  • Page 68: Lubricating The Front And Rear Brake Levers

    EWA10742 WARNING If the centerstand or sidestand does not move up and down smoothly, have a Yamaha dealer check or re- pair it. Otherwise, the centerstand or sidestand could contact the ground The pivoting points of the front and rear...

  • Page 69: Checking The Front Fork

    If any damage is found or the front face and hold it in an upright posi- fork does not operate smoothly, tion. WARNING! To avoid injury, have a Yamaha dealer check or re- securely support the vehicle so pair it. there is no danger of it falling over.

  • Page 70: Checking The Steering

    If any free (See page 4-14.) hub or if the wheel does not turn play can be felt, have a Yamaha This model is equipped with a VRLA smoothly, have a Yamaha dealer dealer check or repair the steer- (Valve Regulated Lead Acid) battery.
  • Page 71 To charge the battery charge it if necessary. Have a Yamaha dealer charge the bat- 3. Fully charge the battery before in- stallation. NOTICE: When install- tery as soon as possible if it seems to have discharged.

  • Page 72: Replacing The Fuses

    Periodic maintenance and adjustment EAU66790 Replacing the fuses 1 2 3 4 5 6 The fuse boxes, which contain the fus- es for the individual circuits, are locat- ed under the seat. (See page 4-14.) 1. Main fuse 1 1. Battery cover 2.

  • Page 73: Headlight

    If a headlight does not come on, have 7.5 A iary lights. If an auxiliary light bulb Taillight fuse: a Yamaha dealer check its electrical burns out, replace it as follows. 7.5 A circuit. 1. Remove the windshield by remov-...

  • Page 74: Brake Light

    Brake light This model is equipped with an LED- type brake light. If the brake light does not come on, have a Yamaha dealer check it. 1. Headlight cover 1. Auxiliary light bulb 2. Bolt 5. Insert a new bulb into the socket.

  • Page 75: Replacing The Taillight Bulb

    Periodic maintenance and adjustment EAU67310 Replacing the taillight bulb 1. Open the seat. (See page 4-14.) 2. Remove the grab bar by removing the bolts. 1. Taillight cover 1. Screw 2. Screw 2. Quick fastener 4. Remove the quick fasteners and screws.
  • Page 76 Periodic maintenance and adjustment 12. Install the grab bar by installing the bolts, and then tightening them to the specified torque. Tightening torque: Grab bar bolt: 17 Nm (1.7 m·kgf, 12 ft·lbf) 13. Close the seat. 1. Taillight unit 1. Taillight bulb 2.

  • Page 77: Replacing A Front Turn Signal Light Bulb

    Periodic maintenance and adjustment EAU43054 EAU67320 Replacing a front turn signal Replacing a rear turn signal light bulb light bulb 1. Place the vehicle on the center- 1. Open the seat. (See page 4-14.) stand. 2. Remove the grab bar by removing 2.
  • Page 78 Periodic maintenance and adjustment Tightening torque: Grab bar bolt: 17 Nm (1.7 m·kgf, 12 ft·lbf) 10. Close the seat. 1. Taillight cover 1. Turn signal light bulb 2. Screw 6. Insert a new bulb into the socket. 4. Remove the turn signal light bulb 7.

  • Page 79: Troubleshooting

    However, should your scooter re- quire any repair, take it to a Yamaha dealer, whose skilled technicians have the necessary tools, experience, and know-how to service the scooter prop- erly.

  • Page 80: Troubleshooting Charts

    Remove the spark plug and check the electrodes. The engine does not start. Have a Yamaha dealer check the vehicle. Check the compression. 4. Compression The engine does not start. There is compression.
  • Page 81 Start the engine. If the engine overheats again, have a The coolant level Yamaha dealer check and repair the cooling system. is OK. If coolant is not available, tap water can be temporarily used instead, provided that it is changed to the recommended cool- ant as soon as possible.

  • Page 82: Scooter Care And Storage

    Be ECA10784 NOTICE high-quality components are used. A sure to consult a Yamaha dealer for rusty exhaust pipe may go unnoticed advice on what products to use be-  Avoid using strong acidic wheel on a car, however, it detracts from the fore cleaning the vehicle.
  • Page 83 For and then rinse thoroughly with clean  Do not use high-pressure wash- additional cleaning, use Yamaha Wind- water. Use a toothbrush or bottlebrush shield Cleaner or other quality cleaner. ers or steam-jet cleaners since for hard-to-reach areas.

  • Page 84: Storage

    Contaminants on the brakes or tires damp cellars, stables (because can cause loss of control.  Consult a Yamaha dealer for ad- of the presence of ammonia)  Make sure that there is no oil or vice on what products to use.
  • Page 85 Scooter care and storage 2. Fill up the fuel tank and add fuel 4. Lubricate all control cables and stabilizer (if available) to prevent the pivoting points of all levers and the fuel tank from rusting and the pedals as well as of the side- fuel from deteriorating.

  • Page 86: Specifications

    Specifications Dimensions: Starting system: Fuel tank capacity: Electric starter 6.6 L (1.7 US gal, 1.5 Imp.gal) Overall length: Lubrication system: Fuel reserve amount: 1955 mm (77.0 in) Wet sump 1.4 L (0.37 US gal, 0.31 Imp.gal) Overall width: Engine oil: Fuel injection: 740 mm (29.1 in) Overall height:...
  • Page 87 Type: Type: Battery: Tubeless Hydraulic single disc brake Size: Specified brake fluid: Model: 130/70-13M/C 63P YAMAHA GENUINE BRAKE FLUID (DOT 4) YTZ7V Manufacturer/model: Rear brake: Voltage, capacity: IRC/SS-560R 12 V, 6.0 Ah (10 HR) Type: Bulb wattage × quantity: Loading:...
  • Page 88 Specifications Coolant temperature warning light: Engine trouble warning light: ABS warning light: Fuse(s): Main fuse: 15.0 A Main fuse 2: 7.5 A Taillight fuse: 7.5 A Signaling system fuse: 7.5 A ABS control unit fuse: 7.5 A ABS motor fuse: 30.0 A ABS solenoid fuse: 15.0 A...

  • Page 89: Consumer Information

    Record the vehicle identification num- ber and the engine serial number in the spaces provided below for assistance when ordering spare parts from a Yamaha dealer or for reference in case the vehicle is stolen. VEHICLE IDENTIFICATION NUMBER: 1. Vehicle identification number 1.

  • Page 90: Index

    Index Front and rear brake lever free play, Part locations ..........3-1 checking..........7-20 ABS............4-10 Front and rear brake pads, checking ... 7-20 ABS warning light ........4-3 Safe-riding points........2-5 Front fork, checking ......7-25 Acceleration and deceleration ....6-2 Safety information........2-1 Fuel............4-12 Air filter and V-belt case air filter Seat............4-14 Fuel consumption, tips for reducing ..
  • Page 91 Index Wheel bearings, checking ....7-26 Wheels..........7-19 11-2...
  • Page 92 PRINTED IN INDONESIA 2015.09-*.*×1 CR...
