mikroElektronika RTC click Quick Start Manual page 2

5. RTC click Board Schematics
VCC
R2
220
PWR
VCC
C3
100nF
J1
+3V3
AN PWM
RST INT
CS RX
SCK TX
SCL
MISO
SDA
MOSI
+3.3V +5V
GND GND
MikroElektronika assumes no responsibility or liability for any errors or inaccuracies that may appear in the present document.
Specification and information contained in the present schematic are subject to change at any time without notice. Copyright © 2012 MikroElektronika. All rights reserved.
Vrtc
R1 56
D1 BAT43
C1
100nF
+5V
Vrtc
INT
C2
22pF
SCL
SDA X1
32.768KHz
D2 BAT43
VCC
BAT1
3V/230mA
Vrtc VCC
U1
R3 R4
1 8
4K7 4K7
OSCI VCC
2 7
OSCO INT
3 6
A0 SCL
4 5
GND SDA
PCF8583P
6. Power supply selection
by default. In order to use RTC click with
5V development system, it is necessary to
resolder this jumper to 5V position.
7. Code Examples
Once you have done all the necessary
preparations, it's time to get your click
board up and running. We have provided
the examples for mikroC, mikroBasic and
mikroPascal compilers on our
website. Just download them and you are
ready to start.
R5
4K7
INT
SCL
SDA
8. Support
MikroElektronika offers
(www.mikroe.com/esupport)
end of product lifetime, so if something goes
wrong, we are ready and willing to help!
On-board PWR SEL zero-
ohm resistor (SMD jumper) is
used to determine whether
5V or 3.3V power supply
is used. This resistor is
provided in 3.3V position
Libstock
.com
Free Tech Support
until the
