olympia electronics GR-736/21L Manual

GR-736/21L SELF-TESTING MAINTAINED EMERGENCY LUMINAIRE WITH WHITE LED's
OPERATION VOLTAGE
MAXIMUM POWER CONSUMPTION
BATTERIES (Ni-Cd)
BATTERY PROTECTION
INDICATIONS - CONTROLS
CHARGING TIME
MINIMUM AUTONOMOUS DURATION
ILLUMINATION SOURCE
ILLUMINATION (MAINS/EMERG.)
DEGREES OF COVER PROTECTION
PRODUCED IN ACCORDANCE WITH
OPERATION TEMPERATURE RANGE
RELATIVE HUMIDITY
CONSTRUCTION MATERIALS
EXTERNAL DIMENSIONS
TYPICAL WEIGHT
GUARANTEE
Thank you for purchasing this product of Olympia
Electronics. A European manufacturer.

GENERAL

These luminaires are used indoors (ta 40 C)
where emergency light is needed.
Each luminaire must be permanently connected
to mains power supply.
In normal operation the led strip lights and the
battery is charging.
In case of a mains power supply failure the
luminaire will light the led strip automatically in
emergency mode (powered by
When the mains power supply is restored the
device turns to normal operation.
Installation
To install the luminaire follow the installation
instructions on page 4.

Battery Cut-off

The luminaire enters in this operation when the
mains power supply fails and battery has lost its
energy. During this operation the luminaire
enters the idle state and battery consumption is
negligible, in order to be protected from deep
discharge.

Battery charging

The battery charging is completely controlled. In
this case, the best possible battery maintenance
is achieved, as well as the elongation of its
duration. When the battery has completely
charged, it charges with a maintenance current.

Manual Test

The manual test can be conducted only if the
main power supply and the battery is connected.
By pressing the test button (use a pointy tool with
diameter of 2mm max.) briefly an operation test
Page 1 from 3
High Quality European based Manufacturers

TECHNICAL CHARACTERISTICS

Charge LED, Lamp LED, Fault LED, TEST button
EN 60598-1, EN 60598-2-22, ΕΝ 55015, ΕΝ 61547, ΕΝ 61000-3-2, ΕΝ 61000-3-3
Bayblend FR3010, transparent polycarbonate
is initiated. During this test period all indication
LEDs are OFF.

Automatic test

o
This test includes all the operations that provide
the manual test and is conducted automatically
every 15 days. In order to be performed, the
main power supply and the battery should be
connected.

Automatic Autonomous Test

The Automatic autonomous Test is conducted
and measures the luminaire`s back up operation.
This test is conducted automatically every six
its battery).
months. In order to be performed, the main
power supply and the battery should be
connected (the battery should be charged). If the
battery is not charged, the test is postponed until
the battery is completely charged. If during the
Automatic Autonomous Test the luminaire's
duration is lower than the named, then the
battery must be replaced.

Back Up Operation

The autonomous duration of battery during
emergency mode is at least the one that is
stated in the technical characteristics. During
emergency mode, a LED strip test is also
performed.

Resetting Errors

Push the Test button (use a pointy tool with
diameter of 2mm max.) for 5 seconds, to
extinguish all the indicated LED errors. Then the
luminaire enters regular operation mode.
Indication Led Status (with connected mains
power supply).

AC Charge

On:
220-240V AC/50-60Hz
3.5W/7VA
3.6V/1.5Ah
From overcharge and full discharge
24h
180min
White LED's
150lm / 150lm
IP 20
o
0 to 40 C
Up to 95%
350 x 127 x 85 mm
720gr.
3 years (1 year for the battery)
Good charge current.
923736021_09_007
