USER'S MANUAL
Thank you for purchasing PIVOT product.
Please read this manual carefully and keep it for future reference.
●If this product is given to another
user, make sure to include this
User's Manual.
Contents
Features .......................................... 2
Part Names of Monitor ........................ 2
Connecting The Connectors ............... 2
Installing The Product ........................ 3
Operation ....................................... 5 ~6
Display Items and Range .................. 7
Troubleshooting ................................. 8
(Self-Adjusting Brightness) .................. 8
WARNING
● This product cannot be installed in non-compatible car models.
● Make sure to keep car stopped while working and be aware of the ventilation, such as exhaust emission.
● Do not operate while driving to prevent an accident.
● Do not crush the cable, nor nipped by metals or something.
● Please securely fasten the product not to fall the product while driving.
CAUTION
● The display will not be proper if the ECU being used is not the standard one or if a sub-computer is
being used, even in compatible car models.
● Cannot be used in combination with other company's products that use Diagnostic Monitoring
Connectors.
● For details about using in combination with other PIVOT products that use Diagnostic Monitoring
Connectors please see our Web Site at https://pivotjp.com/obd- e/
(
Product Number :
OBM
＋
Product
Please check the contents of the package
Monitor
Zip Ties
(Large) × 2
(Small) × 2
Improper use or disregard of these warnings may result in the injury or death of people.
Improper use or disregard of these warnings may cause injury to persons, damage the product and other things.
)
OBD MULTI MONITOR with OLED DISPLAY
Unit
OBD Cable
with fuse 3A
Cut
Double-sided
Connector
Tapes
[45 ×14 mm] × 2
[25 × 35 mm] × 1
[14×14 mm] × 1
(OBM As of October, 2019 No.4)
OB MONITOR
IGN Cable
L-shaped
with fuse 3A
Fastener
User's
Compatibility
Manual
List
(This Book)
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the OB MONITOR and is the answer not in the manual?

Questions and answers

Related Manuals for Pivot OB MONITOR

Summary of Contents for Pivot OB MONITOR

  • Page 1: Table Of Contents

    ● Cannot be used in combination with other company’s products that use Diagnostic Monitoring Connectors. ● For details about using in combination with other PIVOT products that use Diagnostic Monitoring Connectors please see our Web Site at https://pivotjp.com/obd- e/...

  • Page 2: Features

    Features Compact Easy-to-read Next-generation OBD Multi-Monitor ■ Compact and Easy-to-read Size [Unit： mm] Our special scale design coupled with the high contrast and wider field of view offered by organic EL brings you an easy-to-read compact multi monitor that won't interfere with the Monitor standard built-in meters or look like it was just added onto the dashboard.

  • Page 3: Installing The Product

    Installing the Product Installing the Monitor Install t o a position which is easy to see and which allows for easy operation. (Example of Installation) ● Directly mounting Clean to remove oil and dust. Affix with double-sided tape to the mounting side of the monitor.

  • Page 4: Setting Communication System

    Must be set after mounting product Setting Communication System 【Before setting】 Find proper setting on Compatibility List Check the Communication-system of installing car on included Compatibility list. (” 通信方式 means Communication-system on the chart.) Compat- Compat- ibility List ibility List e.g.) TOYOTA Isis (from Oct.

  • Page 5: Operation

    Operation Switch the Display mode Switch between Single-display and Multi-display Press the MODE switch Single-display and Single-display example Multi-display example during display Multi-display will change with each pressing of the MODE switch Switch Display Items on the Single-display Display Items will change with each pressing of the UP / DOWN switch. Change Setting Complete Display...
  • Page 6 Switch Display Items on the Multi-display マルチ表⽰の場合 Each display will change with following operation during Multi-display Change display item of by each pressing Change display item of by each pressing Change display item of by pressing for 3 seconds Display example After pressing for 3 seconds, change display item by each pressing of the UP / DOWN switch during display blinking.

  • Page 7: Display Items And Range

    Display Item and Range Multi-display Single-display Display Range Communi- cation Display Item Analog Digital system Water Temperature 50 to 110 °C -35 to 150 °C -35 to 150 °C Voltage 8.0 to 16.0 V 8.0 to 18.0 V 8.0 to 18.0 V Engine RPM 0 to 8000 rpm 0 to 9900 rpm...

  • Page 8: Troubleshooting

    • We plan in the near future to take all possible legal measures to protect against unfair competition from look-alike products using similar designs, regulating characteristics, circuitry and circuitry layout. • We strictly prohibit the unlicensed use of the PIVOT trademark and the unauthorized use of PIVOT User’ s Manual. PIVOT CORPORATION...
