4K@60 4×1 Switcher with
2×50W Audio Amplifier
VER 1.0
Thank you for purchasing this product
For optimum performance and safety, please read these instructions carefully
before connecting, operating or adjusting this product. Please keep this manual
for future reference.
Surge protection device recommended
This product contains sensitive electrical components that may be damaged
by electrical spikes, surges, electric shock, lighting strikes, etc. Use of surge
protection systems is highly recommended in order to protect and extend the
life of your equipment.
Advertisement
Table of Contents
Related Manuals for BZB Gear HDS-B41PA100
Summary of Contents for BZB Gear HDS-B41PA100
- Page 1 4K@60 4×1 Switcher with 2×50W Audio Amplifier VER 1.0 Thank you for purchasing this product For optimum performance and safety, please read these instructions carefully before connecting, operating or adjusting this product. Please keep this manual for future reference. Surge protection device recommended This product contains sensitive electrical components that may be damaged by electrical spikes, surges, electric shock, lighting strikes, etc.
-
Page 2: Table Of Contents
Table of Contents 1. Introduction 2. Features 4 3. Package Contents 4. Specifications 5 5. Operation Controls and Functions 5.1 Front Panel 5.2 Rear Panel 6. Remote Control 7. Application Example 9 1. Introduction The high performance 4K60Hz 4×1 Switcher supports four HDMI high definition inputs and one HDMI output, the highest resolution is up to 4K60Hz YCbCr 4:4:4, HDCP 2.2. -
Page 3: Package Contents
3. Package Contents ① 1× 4K@60Hz 4×1 HDMI Switcher ② 1× 24V/3.75A Locking Power Adapter ③ 1× Remote Control ④ 1× Phoenix Connector (3-pin, male) ⑤ 1× Phoenix Connector (4-pin, male) ⑥ 1× User Manual 4. Specifications Technical HDMI Compliance HDMI 2.0 HDCP Compliance HDCP 2.2 and HDCP 1.4... -
Page 4: Operation Controls And Functions
Aluminum Enclosure Color Champagne Gold Dimensions 192.5mm(W)×160mm(D)×40mm(H) Weight 838g Power Supply Input: AC100~240V 50/60Hz Output : DC24V/3.75A (US/EU standards，CE/FCC/UL certified) Output power 2x50W @4Ω Power Consumption Operating Temperature 0°C ~ 40°C / 32°F ~ 104°F Storage Temperature -20°C ~ 60°C / -4°F ~ 140°F Relative Humidity 20~90% RH (non-condensing) 5. -
Page 5: Rear Panel
5.2 Rear Panel Number Name Function description INPUT ports ▪ 1~4 HDMI ports: Connect to HDMI source device such as DVD or PS4 player with an HDMI cable. ▪ 5 LINE port: Connect to external audio input such as MP3 or DVD. OUTPUT ports ▪... -
Page 6: Application Example
BZB Gear catalog. You’ll notice comparably lower prices with BZB Gear solutions, but the quality of the products is on par with the top brands in the industry. The unparalleled support from our team is our way of showing we care... -
Page 7: Warranty Information
Warranty Information BZB Gear | Second Year Assurance BZB Gear wants to assure you peace of mind. We're so confident in the quality of our products that along with the manufacturer's one-year limited warranty, we are offering free second-year warranty coverage upon registration*! Taking advantage of this program is simple, just follow the steps below: 1.
