Di-LOG DL6507 Operating Manual

Ac leakage current clamp meter

Advertisement

Quick Links

operating manual

DL6507
AC LEAKAGE CURRENT
CLAMP METER
EN
61010-1
CAT II
600V

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DL6507 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Di-LOG DL6507

  • Page 1: Operating Manual

    DL6507 AC LEAKAGE CURRENT CLAMP METER 61010-1 CAT II 600V...
  • Page 2 • Integral memory for readings • Evaluates MIN/MAX values • Zero-setting • Relative value function The Clamp Meter DL6507 is supplied complete with leads. After unpacking, check that the instrument is complete, and that all accessories are present. Scope of supply: 1 pce Clamp Meter DL6507 2 pce.
  • Page 3: Safety Information

    Safety Information References marked on instrument or in instruction manual: Warning of a potential danger, comply with instruction manual. Reference. Please use upmost attention. Caution! Dangerous voltage. Danger of electrical shock. Symbol for the marketing of electrical and electronic equipment (WEEE Directive 2002/96/EC).
  • Page 4 2 hours is required prior to instrument operation. Safety The Clamp Meter DL6507 has been manufactured and tested to comply with the safety regulations for electronic measuring equipment contained in DIN VDE 0411 and EN 61010, and left our works in a safe condition.
  • Page 5 Safety Information Before each measurement make sure that the test leads and the instrument are undamaged. Only handle test leads and probes on the grips provided. Avoid touching probes under any circumstances. The relevant safety regulations for electrical plant and equipment must be observed during all operations.
  • Page 6: Controls And Inputs

    Controls and Inputs Controls and Connections Induction coil (clamp) 2. Selector switch, for type of measurement 3. Data hold button, to memorise reading 4. MIN/MAX value 5. Zero setting / relative value function 6. Frequency range select switch 7. Digital display 8.
  • Page 7 Controls and Inputs...
  • Page 8 Operating Instructions Preparation and safety measures Fitting the battery Before using the instrument, the battery must be fitted. This is carried out as follows: • Separate the instrument from any circuit, and remove the test leads. • Open the housing by removing the screw on the rear face.
  • Page 9 Operating Instructions Use the instrument only if the specified ranges. Before making measurements, verify that the instrument is functioning properly, for example by testing on a known voltage or current. Make sure that the test leads are undamaged. Current Measurements Never measure currents in uninsulated conductors carrying more than 250 V! Only handle test leads and probes on the grips...
  • Page 10 Operating Instructions Voltage measurements Do not connect more than 600 V AC / DC to the input sockets. Exceeding these values can endanger the operator, and may result in damage to the instrument. Before switching to a new function, disconnect the probes from the circuit.
  • Page 11: Resistance Measurements

    Operating Instructions Resistance measurements Disconnect the circuit from all sources of supply and check that it is at zero voltage. • Turn selector switch (2) to “V ” Ω • Plug the black test lead into the “COM” socket and the red lead into the “+”...
  • Page 12 If the symbol for Battery appears in the upper left corner of the display, the battery must be changed. This is carried out as follows: • Remove the DL6507 from any circuit, and remove the test leads. • Switch the instrument off •...
  • Page 13: Maintenance

    Maintenance PLEASE CONSIDER YOUR ENVIRONMENT WHEN YOU DISPOSE OF YOUR BATTERIES. THEY BELONG IN A RUBBISH DUMP FOR HAZARDOUS WASTE. If an instrument is not used over an extended time period, the batteries must be removed. Should the instrument be contaminated by leaking battery cells, the instrument has to be returned for cleaning and inspection to the factory.
  • Page 14: Technical Data

    Technical Data Technical data (at 23° C % 5° C, max. 75 % rel. humidity) Display: 3¾, LCD incl. functions and symbols Bargraph: 40 segments Range Selection: manual/ frequency: automatic. Auto-Power-Off: approx. 30 min. The device can be turned on after ca. 10 seconds. Overload Indication: The left digit is blinking Measuring rate:...
  • Page 15 Technical Data Operation temperature: -10° C … 50° C Storage temperature: 20° C … 60° C Humidity: < 75 % relative humidity Dimension: 183 x 63,6 x 35,6 mm Weight: ca. 190g Current AC Range Resolution Accuracy 50 Hz/60 Hz 40 Hz …...
  • Page 16: Warranty & Maintenance

    Warranty & Maintenance 24 Month Warranty Di-Log instruments are subject to stringent quality controls. If in the course of normal daily use a fault occurs we will provide a 24 month warranty (only valid with invoice). Faults in manufacture and materials defect will be rectified by us free of charge, provided the instrument has not been tampered with and returned to us unopened.
